- Page 1 Send SMS Text Message to your Mobile Phone when alarm occurrence! GSM Alarm System User Manual S3526 Ver 1.20 Date Issued: 2009-06-07 All rights reserved by King Pigeon Hi-Tech.Co.,Ltd. www.GSMalarmsystem.co m ...
-
Page 2: Table Of Contents
We recommend that the advice of a registered electrician be sought before any Installation work commences. King Pigeon Hi-Tech.Co., Ltd, its employees and distributors, accept no liability for any loss or damage including consequential damage due to reliance on any material contained in this handbook. -
Page 3: Brief Introduction
A Top Safety and Protection Solution In The Worldwide! 1. Brief introduction The GSM Alarm System S3526 is a new security protection solution special for home, house and office and other applications. It based on Wireless GSM Communication network. When any sensor activated, it will Call&Send SMS to owners telephone immediately. -
Page 4: Standard Packing List
4.1 Control Unit physical layout Power External 12VDC Power Status LED,power on will on. Arm Status LED,in armed mode, it flashs green, always Status green is disarmed. King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011... - Page 5 12VDC Power Output Source, can use it for any device or PIN 3 sensors that need 12VDC to work. Output relay negative electrode PIN 4 (Relate Voltage:2A/250VAC) Output relay positive electrode PIN 5 (Relate Voltage:2A/250VAC) King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011...
-
Page 6: Features
13) Supports wired and wireless siren; 14) Supports alert user by SMS when the remote control has been used to control the system; this function can enable or disable by user; King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2... -
Page 7: Settings
16) Based on the GSM communication network and Voice Operation Menu technology, apply to wide range situations. 6. Settings The S3526 designed for easiler setup, all the setup can be done by SMS commands. Also, you can setup it by call, the commands are the same as the SMS Commands. - Page 8 Inquire the preset Dial phone number. (Can’t inquire it by phone, only by SMS.) Set the dial phone number. Set the dial phone number. Set the dial phone number. Set the dial phone number. King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011...
- Page 9 1 name to door. Please help to setup the first SMS Alert Number firstly, so that you can receive all the confirmation SMS. King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011...
-
Page 10: Operating Instructions
There’re two way to operate it. Method 1: Send SMS to Arm or Disarm; 2: Call to the Control unit. In order to operate it easier, we designed simply commands, as below: King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011... -
Page 11: Installation
8. Installation King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011... - Page 12 In the backside of the control unit, please install the GSM SIM card 8.2 Install the Magnetic door/window sensors Magnetic door/window sensors signal the Control Unit when the two parts separate by more than between 1.5 to 3.0cm. King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011...
- Page 13 Installation: attach the larger half to the floor and attach (rivet or glue) the smaller half to the scroll steel door. An alarm is triggered when the halves King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2...
- Page 14 The PIR sensor will detect a person since human temperature is different to ambient temperature. When triggered, the PIR will signal the Control Unit. Apply the detection area illustration below when installing. Wireless curtain sensor, detection area illustration below: King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011...
- Page 15 AC adapter. 8.6 Install Siren Connect the Siren and the Speaker to the Control Unit and fix them in appropriate locations . Strobe Siren Siren Linght Siren King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011...
-
Page 16: Add Wireless Sensors
10) You can set many sensors in the same zone. Notice: After you restored the system to factory deflaut(By press the Reset Button), you should learn the wireless senors to the control units again. The method King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011... - Page 17 Wireless Zone Activated Zone 7 Wireless Zone Activated Zone 8 Emergency Alarm SOS Alarm Notice: All the Zone Names can be edited by user through SMS Commands; King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011...
-
Page 18: Technical Specifications
5) Have a secure connection to the main power supply. 6) This product was designed for the indoor use. 7) Opening the control unit cover will void the warranty. King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011... -
Page 19: Maintenance
The End! Any questions please help to contact us feel free. Email Us: Sales@Kingpigeon.com.cn Http://www.GSMalarmsystem.com Http://www.Kingpigeon.com.cn King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011... -
Page 20: Learning Wireless Sensor For S3526
A Top Safety and Protection Solution In The Worldwide! Learning Wireless Sensor For S3526 When you want to clear all settings, then you can reset the system. After reset it, all the sensors and remote controls can’t work with the mainframe. -
Page 21: King Pigeon Hi-Tech. Co., Ltd. Page Of 21 Ver 1.2 File No
A Top Safety and Protection Solution In The Worldwide! 6. Also, please note the 1.5M,3.3M,4.7M three DIP Switch you have choose the 4.7M. see below: King Pigeon Hi-Tech. Co., Ltd. Page of 21 Ver 1.2 File No.: 35260011...
