GSM/GPRS/3G/4G/Cloud
Temperature&Humidity&Analog
&Voltage&Power Status Alarm
Inquiry Onsite value with a FREE
Call or SMS!
High-Low Threshold alarm with
SMS text Message alert!
Interval Report Status to Your
Mobile Phone by SMS!
User Manual
Ver 2.4
RTU5023/6/7/8/9
Date Issued: 2019-11-30
All rights reserved by King
Pigeon Hi-Tech. Co., Ltd.
www.GPRS-M2M.com
Advertisement
Table of Contents
Related Manuals for King Pigeon RTU5023
Summary of Contents for King Pigeon RTU5023
- Page 1 High-Low Threshold alarm with SMS text Message alert! Interval Report Status to Your Mobile Phone by SMS! GSM/GPRS/3G/4G/Cloud Temperature&Humidity&Analog &Voltage&Power Status Alarm User Manual Ver 2.4 RTU5023/6/7/8/9 Date Issued: 2019-11-30 All rights reserved by King Pigeon Hi-Tech. Co., Ltd. www.GPRS-M2M.com...
-
Page 2: Table Of Contents
We recommend that the advice of a registered electrician be sought before any Installation work commences. King Pigeon Hi-Tech.Co., Ltd, its employees and distributors, accept no liability for any loss or damage including consequential damage due to reliance on any material contained in this handbook. -
Page 3: Brief Introduction
Modbus RTU Over TCP and Modbus TCP to connect to cloud platform,then monitor the current status in real time through GSM/3G/4G network. RTU5023/6/7/8/9 Monitor Alarm unit can be used for temperature,humidity,4~20mA/0~5V analog signal,DC voltage,3 phase power status,single phase power status monitoring and alarm, suitable for classrooms, public places, hospitals, stations, Food warehouses, offices, factories, libraries, laboratories, etc., and any place that... -
Page 4: Standard Packing List
Support Modbus RTU Over TCP and Modbus TCP, can be connected to cloud platform. 5. Technical specifications Item Reference Scope DC Power supply Standard adapter:12VDC，Range 9~36VDC Standby：20mA@12V；Working Max：150mA@12V Power consumption Page 4 of 14 King Pigeon Hi-Tech. Co., Ltd. Ver 2.4... -
Page 5: Physical Layout
70mm * 88mm * 30mm 6. Physical Layout 6.1 LED Indicator Instruction LED Indicator Instruction Cellular network indicator： 2G module,flashing quickly (flash per 0.8s) means searching for cellular or no network; Page 5 of 14 King Pigeon Hi-Tech. Co., Ltd. Ver 2.4... - Page 6 1.upgrade,press it and switch on the device will enter upgrade state;2.reset,press it then hold on 3 seconds in the state of power on will reset ) and card slot as below: Page 6 of 14 King Pigeon Hi-Tech. Co., Ltd. Ver 2.4...
-
Page 7: Reset The Unit
5. The PWD in the commands is means the password, when you use it, please in stand of it by the digital number; the capital letters PWD is the command letter, use PWD directly. Page 7 of 14 King Pigeon Hi-Tech. Co., Ltd. Ver 2.4... - Page 8 1234 to 4321 4) Armed or Disarmed Command Return SMS Example Armed stands for while alarm occurrence, will send SMS or dial Armed PWD+AA Armed to alert users. Page 8 of 14 King Pigeon Hi-Tech. Co., Ltd. Ver 2.4...
- Page 9 20 characters Voltage:y PWD+AIN123 Inquiry PWD+AINR+x+L+y+H+z+# y stands for low threshold value;z stands for high threshold value,if y=z,will not alarm RTU5023 valid temperature range:-400~800(stands for 40℃~80℃); Temperature/AIN: RTU5026 valid temperature range:-550~1250(stands for -55℃ low:y,High:z. ~125℃); Humidity valid range:0~100(stands for 0%RH~100%RH); Humidity: Voltage valid range:0~370(stands for 0V~37V);...
- Page 10 40 characters PWD+AINN Inquiry Setup 12V Output PWD+AOT+y 12V Output: y Seconds Time y=0~65535 seconds,default 120 seconds,0 stands for always Page 10 of 14 King Pigeon Hi-Tech. Co., Ltd. Ver 2.4...
- Page 11 AIN:Current Value,[Normal/Higher/Lower];(for RTU5027) Temp:xxxxC,[Normal/Higher/Lower];(for RTU5023/6) Humi:xxxxRH%,[Normal/Higher/Lower];(for RTU5023) Volt:xxxxVDC,[Normal/Higher/Lower];(for RTU5023/6/7) GSM Signal Value: IMEI: Model: Version: 10) Inquiry Historic Record (Only can inquiry the latest 100 alarm events.) Command Return SMS Example Page 11 of 14 King Pigeon Hi-Tech. Co., Ltd. Ver 2.4...
- Page 12 Server IP:x port. Port:y Inquiry PWD+IP Delete PWD+IPDEL 16) Setup GPRS Communication Protocol Command Return SMS PWD+GPRSON+x Setup GPRS/3G/4G:x x=1,2,3;1 stands for Modbus RTU Over TCP protocol,2 stands for Modbus Page 12 of 14 King Pigeon Hi-Tech. Co., Ltd. Ver 2.4...
- Page 13 Return SMS PWD+COFF# Not continue Once anyone answered, the device will not call next authorized Set successfully dialing (Default) number,if nobody answer will circular dialing for 3 times . Page 13 of 14 King Pigeon Hi-Tech. Co., Ltd. Ver 2.4...
-
Page 14: Data Communication Protocol
* or # will stop calling next authorize number 9. Data Communication Protocol The RTU5023/6/7/8/9 supports GPRS/3G/4G data transfer to cloud server,supports Modbus RTU Over TCP and Modbus TCP protocol. 5023、5026、5027 Modbus Address Instruction...
