Rascal Vantage Owners Manual & Service Record page 9

5. Ignition Key: Remember to remove the key when not in use. Do
not leave the ignition on when not in use, especially when charging
the vehicle (Fig.1). Note: You may need to press the ignition key
gently inwards before it will allow itself to be turned.
6. Finger control: To operate, turn on the ignition. Pull the right hand
lever towards you and the machine moves forward. The more you
pull the lever the faster the scooter goes. To brake, release the lever.
Again the faster the lever is released the quicker you will stop. To
reverse, pull the left lever towards you. Do not pull both levers at
once. Note: The controls can be changed for customers with a
left-hand bias. Please contact your local dealer for information.
7. Lighting control: To switch on the scooter front and rear lighting press the lighting switch once, to turn it
off, press the switch a second time.
8. Hazard lights: In an emergency or during a break-down, the hazard lights should be switched on.
Press the hazard light button once to switch on - All turn indicators will flash together. Press the button for
a second time to switch the hazard lights off.
9. Indicator (left turn): Press the left hand side of the indicator button once to start the left turn indicator
flashing, to switch off, re-center the switch.
10. Half speed switch: This button is marked with a tortoise. When travelling in pedestrian areas (not on the
road) this switch can be pressed to limit the maximum scooter speed to 50% of the value pre-selected by
the speed control (2) knob. This means that the scooter will not be able to travel at more than 4mph. To
turn this function off, press the switch for a second time. Only featured on Vantage X model.
11. Indicator (right turn): Press the right hand side of the indicator button once to start the left turn indicator
flashing, to switch off, re-center the switch.
12. Battery cut-out: Your scooter is equipped with a battery cut-out
(Fig.2) that is designed to operate in the unlikely event of an electrical
or electromechanical overload and is located beneath the rear
removable "boot" panel of the scooter (Fig.3). If this activates, all
power will be cut from the batteries to the scooter. This device can
be re-set by pressing the button shown in the illustration. Should it
activate for a second time please seek advice from your dealer.
Charging Point: The charging point is situated on the left hand side
of the scooter tiller. See the Charging section for further instructions.
Note: The Rascal Vantage does not have all of the features shown above.
1
2
3
9
