Controls

Rascal Vantage X shown.
Before driving your vehicle it is important to familiarise yourself with the controls. Do not attempt to drive the
vehicle before reading the rest of this Owner's Manual.
6
Dashboard Description
1. Battery Indicator: This indicator shows the level of charge in the batteries. When all segments are shown
the batteries are full. As the charge level of the batteries depletes, so the number of lit segments will drop.
Note: When the vehicle is climbing a steep incline or starting off, the level may drop momentarily; this is normal.
2. Speed Control: This controls the preset top speed of your scooter. When the knob is turned anticlockwise
to the left, this is its slowest speed, marked by a tortoise. As the knob is turned to the right the speed will
increase to a maximum, marked by a hare. Set the speed before you move off. Do not adjust the speed
control dial when the vehicle is moving.
3. Power On Indicator: When the ignition key is inserted into the scooter and turned to the "on" or "I"
position, the LED array will illuminate.
Tip: If an LED flashes , and persists, this may indicate a fault. A key to the fault codes can be found in the
"Scooter diagnostic functions" section of this manual. A common "fault" is that the scooter has been left in
freewheel mode. Turn the key to the "0" or off position, disengage the free-wheel mode and turn the key back
to the on or "I" position.
4. Horn: Press the button and the horn will sound.
8
1
3
8
10
7
9 11
Rascal Vantage and Vantage X Scooters Owner's Manual and Service Record
2
4
6
5
