Rascal Vantage Owners Manual & Service Record page 17

To fold the tiller:
1. Push the tiller release lever downwards as shown - this will allow the tiller to be put in the desired
position. Release the tiller lever and the tiller will be set in that position. (Fig.13)
Tip: Alternatively the seat and tiller can be folded towards each other to reduce overall height and facilitate
easier storage of the scooter (Fig.14)
12
Warning!
Do not attempt to lift any of the scooter components unless you are capable of doing so. The
weight for each component is shown in the Technical Specification (page 27)
Warning!
Do not attempt to lift the chassis un-assisted - back or other injury may result!
13 14
17
