Product Specs - M-Audio Audio Interface Conectiv User Manual

48kHz sampling rate, 16-bit unless otherwise stated
Mic Inputs (A/D)
Input Impedance
Maximum Input Level
SNR
Dynamic Range
THD+N
Frequency Response
Pre-amp Variable Gain
Phono Inputs (A/D)
Input Impedance
EQ
Gain
Line Inputs (A/D)
Input Impedance
Maximum Input Level at minimum gain +10 dBV (3.162 Vrms), unbalanced
Channel-to-Channel Crosstalk
SNR
Dynamic Range
THD+N
Frequency Response
Line Outputs (D/A)
Output Impedance
Maximum Output Level
Channel-to-Channel Crosstalk
SNR
Dynamic Range
THD+N
Frequency Response
Headphone Output
Maximum Output
Working Range
Digital Audio Interface Specifications
340KOhms
+4.1 dBu (1.243 Vrms) @ minimum gain
-98 dB, A-weighted
98 dB, A-weighted
0.00686 % (-83.3 dB) @ -1 dBFS, 1 kHz
20 Hz to 20 kHz, +/- 0.2 dB @ 48 kHz sample rate
>25 dB
48KOhms
RIAA curve
43 dB
48k Ohms
< -100 dB @ 1 Khz
-97 dB, A-weighted
97 dB, A-weighted
0.00557 % (-85.1 dB) @ -1 dBFS, 1 kHz
20 Hz to 20 kHz, +/- 0.2 dB @ 48 kHz sample rate
100 Ohms unbalanced
+11.4 dBV (3.711 Vrms), unbalanced
< -109 dB @ 1 Khz
-100 dB, A-weighted
95 dB, A-weighted
0.00390 % (-88.2 dB) @ -1 dBFS, 1 kHz
20 Hz to 20 kHz, +/- 0.1 dB @ 48 kHz sample rate
0 dBV (1 Vrms, 2.8 Vpp) into 30-ohms
16 to 80 ohms
