- Page 1 4 x 4 USB DJ Audio Interface User Guide...
-
Page 2: Table Of Contents
Table of Contents Introduction ............. 3 What’s in the Box? . -
Page 3: Introduction
hank you for choosing the SynchroScience Conectiv USB audio interface. Conectiv takes advantage of the convenience and dependability of the Universal Serial Bus (USB) to provide you with a versatile interface that can be used both live on stage and in the studio. The interface’s sleek, lightweight, and portable design makes it the perfect travel companion for active computer-based DJs, musicians, and producers. -
Page 4: What's In The Box
Your Conectiv package contains the following: Conectiv USB audio interface < SynchroScience CD-ROM containing drivers, control panel software, documentation, and Torq DJ application < USB cable < Conectiv has the following features: 4-in/4-out audio streaming over a USB 1.1 connection <... -
Page 5: Minimum System Requirements
Operating Systems Windows Conectiv is supported under Windows XP with Service Pack 2 or later. It is not supported under Windows 2000, Windows 98, or Windows ME. Visit the Windows update web pages to make certain you have the most current updates and fixes supplied by Microsoft. -
Page 6: Software Installation
ou must install drivers in order for Conectiv to operate properly. Please consult the included Quick Start Guide for installation instructions. Once the drivers are installed, you may need to configure your audio software to route signals to and from Conectiv. Refer to your program’s user guide to learn how to do this. -
Page 7: Rear Panel
Rear Panel RCA Outputs (OUTPUT A, OUTPUT B) a DJ mixer, amplified speakers, or another destination. The audio source for these outputs is determined by the Mix knobs (7). RCA Inputs (INPUT A, INPUT B) input pairs accept stereo signals from a variety of devices including CD players and turntables. -
Page 8: Hardware Connections
ground Channel 1 Channel 2 DJ Mixer 1. Connect Conectiv’s RCA Outputs to your amplifier, powered monitors, or mixer. 2. Connect your stereo headphones to Conectiv’s front-panel Phones output. 3. Connect a microphone to the 1/4” Microphone input on the front panel of the interface. 4. -
Page 9: Using Conectiv
If you require additional help, check the M-Audio website for more tips, tutorials, and FAQs. Understanding Conectiv’s Audio Routing Conectiv’s flexible audio routing allows it to be used in a variety of different situations. -
Page 10: User Guide
Next, the signal is doubled and sent to two different destinations at the same time. The first part is routed through the USB port to your computer for recording or software processing; the other part of the signal is sent to Mix knob A (7). The function of this knob is covered in detail later in this chapter. -
Page 11: Headphone Monitoring
Headphone Monitoring Conectiv offers two different headphone (or “cue”) monitoring options for DJs, which are described below. Use the Split switch (3) to select which mode you’d like to use. Press the switch to activate Split mode or leave the switch in the Up position to remain in Normal monitoring mode. -
Page 12: Using Your Computer As An Effects Processor
Using Your Computer as an Effects Processor Conectiv’s ability to simultaneously send and receive four channels of audio over USB allows you to use your computer as a powerful effects processor. This is done by sending your audio sources (turntables or CD players) through Conectiv to software-based effects on your computer. -
Page 13: The Software Control Panel
For Mac users, the control panel simply displays version numbers of software components such as the audio driver and device firmware along with links to useful sections of the M-Audio website. Buffer size changes must be made through the host application on the Macintosh operating system. -
Page 14: Troubleshooting
Conectiv is a high-performance, professional-quality interface that has been tested under a wide variety of conditions. Despite our thorough testing, Conectiv can be used in limitless situations and certain scenarios may result in unexpected performance. This section will highlight some of the most common difficulties users may experience and provide tips to remedy these problems. First, we’ll cover issues that might arise when the interface is used in standalone mode. - Page 15 Make sure your audio software has been set up to use the interface. Open your application’s audio settings page < and verify that Conectiv’s ASIO, WDM, or Core Audio drivers have been selected. Ensure that each channel’s Mix knob is not turned fully counter-clockwise as that will mute the computer’s output. <...
-
Page 16: Product Specs
48kHz sampling rate, 16-bit unless otherwise stated Digital Audio Interface Specifications Mic Inputs (A/D) Input Impedance Maximum Input Level Dynamic Range THD+N Frequency Response Pre-amp Variable Gain Phono Inputs (A/D) Input Impedance Gain Line Inputs (A/D) Input Impedance Maximum Input Level at minimum gain +10 dBV (3.162 Vrms), unbalanced Channel-to-Channel Crosstalk Dynamic Range THD+N... -
Page 17: Warranty Terms And Registration
Warranty Registration Thank you for registering your new M-Audio product. Doing so immediately both entitles you to full warranty coverage and helps M-Audio develop and manufacture the finest quality products available. Register online at www.m-audio.com/register to receive FREE product updates and for the chance to win M-Audio giveaways. -
Page 18: Technical Support
M-Audio USA 5795 Martin Rd., Irwindale, CA 91706 Technical Support web: www.m-audio.com/tech tel (pro products): (626) 633-9055 tel (consumer products): (626) 633-9066 fax (shipping): (626) 633-9032 Sales e-mail: sales@m-audio.com tel: 1-866-657-6434 fax: (626) 633-9070 www.m-audio.com M-Audio U.K. Floor 6, Gresham House, 53 Clarenden Road, Watford...
