- Page 1 SERIAL EXTENDER RS-232 Serial Extender Up to 3300 Feet (1000 Meters) Instruction Guide RS232EXTC5 * Actual product may vary from photo The Professionals’ Source For Hard-to-Find Computer Parts...
- Page 2 FCC COMPLIANCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 3: Table Of Contents
Table of Contents Introduction ............2 Connecting Your RS-232 Serial Extender . -
Page 4: Introduction
Introduction Thank you for purchasing a StarTech.com RS-232 Serial Extender. You’ll be able to place your serial devices up to 3300 feet (1000m) away from your system, an incredible 65 times greater than normal RS-232 serial cable length restrictions. The Local and Remote units connect using standard Category 5 Ethernet Cable and there’s no need to buy... -
Page 5: Connecting Your Rs-232 Serial Extender
Connecting Your RS-232 Serial Extender The diagram below demonstrates how to connect the RS-232 Serial Extender to your devices. The kit contains two modules: the local unit (with a female RS-232 serial port) and the remote unit (with a male RS-232 serial port). The local unit connects to the source device that you wish to print or send information from (computer, point-of-sale terminal, etc.). - Page 6 Remote Unit Connections RS-232 DB9 Male RJ-45 Power Dimensions 2.95” x 1.77” x 0.98”(LxHxW) 75mm x 45mm x 25mm (LxHxW) Weight 4.23 oz. (120g) Power Supply 12v DC 2A from AC/DC adapter Operating Temp. 32-104° F. (0-40° C.) Humidity 80% non-condensing relative humidity DB9 Pin Assignment Pin 1: (unassigned)
-
Page 7: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 8 Revised: May 11, 2004...
