HDMI® over Single Cat 5e/6 Extender w/
Power over Cable, Ethernet, IR - 1080p
ST121HDT4P
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 04/11/2013
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com ST121HDT4P
Summary of Contents for StarTech.com ST121HDT4P
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 04/11/2013...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Front View – Transmitter/Receiver Unit ..................... 2 Rear View – Transmitter/Receiver Unit ....................2 Installation ....................3 Preparing Your Site ........................... 3 Hardware Installation ..........................3 Specifications ..................5 Technical Support ..................6 Warranty Information ................6 Instruction Manual... -
Page 4: Introduction
Introduction The ST121HDT4P HDMI® over CAT5e/6 Video Extender kit lets you extend HDMI® video and audio up to 330 feet (100 Meters) over a single Cat5e cable. For added benefit both the Transmitter and Receiver are powered by the same power source, connected to the Transmitter and sent to the Receiver using Power Over Cable (POC). -
Page 5: Front View - Transmitter/Receiver Unit
Front View – Transmitter/Receiver Unit Transmitter Unit Receiver Unit 1. HDCP LED 1. HDCP LED 2. Link LED 2. Link LED 3. Mode LED 3. Mode LED 4. Power LED 4. Power LED 5. IR-RX Port 5. IR-RX Port 6. IR-TX Port 6. -
Page 6: Installation
Installation Preparing Your Site 1. Determine where the local video source (i.e. computer, Blu-ray Player) will be located and set up the device. 2. Determine where the remote display will be located and place/ mount the display appropriately. NOTE: This HDMI® extender kit features Power over cable, allowing both the transmitter and Receiver to be powered from a single power source that connects to the transmitter unit. - Page 7 2. Install RJ45 terminated Cat5e/6 Ethernet Cable a) Connect an RJ45 terminated Cat5e/6 Ethernet cable (not included) to the RJ45 connector on the Transmitter unit. NOTE: If you are using surface cabling, ensure you have enough Category 5e unshielded twisted pair (UTP) network cabling to connect the Host Unit to the Remote Unit’s location, and that each end is terminated with a RJ45 connector.
-
Page 8: Specifications
Specifications AV Input HDMI® AV Output HDMI® Cabling Cat 5e/6 UTP Audio 2x IrDA (Infrared; SIR/FIR) Local Unit Connectors 1x HDMI (19 pin) Female 3x RJ-45 Female 2x IrDA (Infrared; SIR/FIR) Remote Unit Connectors 1x HDMI (19 pin) Female 3x RJ-45 Female Max Distance 100 m / 330 ft Maximum Digital Resolutions... -
Page 9: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 10 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
