Electric/Hydronic
Baseboard Heaters
(Model D)
Installation & Maintenance Instructions
Dear Owner,
Congratulations! Thank you for purchasing this new heater manufactured by Marley Engineered
Products. You have made a wise investment selecting the highest quality product in the heating industry.
Please carefully read and follow the installation and maintenance directions shown in this manual. You
should enjoy years of efficient heating comfort with this product from Marley Engineered Products... the
industry's leader in design, manufacturing, quality and service.
Read Carefully - This instruction sheet contains vital infor-
mation for the proper installation, use and efficient opera-
tion of the heater. Carefully read the manual before instal-
lation, operation, or cleaning of the heater. Failure to
adhere to the instructions could result in fire, electric
shock, death, serious personal injury or property damage.
Save these instructions and review frequently for continu-
ing safe operation and instructing future users.
WARNING: HAZARD OF FIRE OR ELECTRICAL SHOCK.
1. Keep all electrical cords, foam filled articles, drapes,
bedding and other household furnishings away from
contact with heater. It is recommended all items be
kept a minimum of six (6") inches (152mm) from heater.
2. Do not install baseboard heater below electrical con-
venience receptacles (outlets).
3. Do not install baseboard heater against vinyl wallpa-
WARNING
!
SAVE THESE INSTRUCTIONS
1
... The Employees of
Marley Engineered Products
per, paperboard or low density fiberboard surface. Do
not install vinyl drapes or vinyl blinds above heater.
4. Do not recess heater in wall.
5. The installation must comply with applicable local, and
National Electrical Code and utility requirements.
6. Do not remove or by-pass thermal cutout.
7. To reduce the risk of fire, do not store or use gasoline
or other flammable vapors and liquids in the vicinity of
the heater.
8. Personal injury or death could result from electric
shock. Disconnect all power to heater at main panel
before attempting to install or service this heater.
9. Supply voltage must be the same as heater voltage.
Check heater nameplate and supply voltage before
energizing.
10. Supply wiring must be suitable for 90°C.
FILE #E37116
