FILE #E21609
S Series
Electric Toe Space Heaters
Without Built-in Thermostat
Installation & Maintenance Instructions
Dear Owner,
Congratulations! Thank you for purchasing this new heater manufactured by Marley Engineered
Products. You have made a wise investment selecting the highest quality product in the heating indus-
try. Please carefully read the installation and maintenance instructions shown in this manual. You
should enjoy years of efficient heating comfort with this product from Marley Engineered Products... the
industry's leader in design, manufacturing, quality and service.
Read Carefully -
These instructions are written to help
you prevent difficulties that might arise during installation
of heaters. Studying the instructions first may save you
considerable time and money later. Observe the following
procedures, and cut your installation time to a minimum.
To reduce risk of fire or electric shock:
1. To prevent electrical shock, disconnect all power coming to
heater at main service panel before wiring or servicing.
2. All wiring must be in accordance with the National and Local
Electrical Codes and the heater must be grounded as a pre-
caution against possible electric shock.
3. Verify the power supply voltage coming to heater matches the
ratings printed on the heater nameplate before energizing.
4. This heater is hot when in use. To avoid burns, do not let bare
skin touch hot surfaces.
5. DO NOT INSTALL THIS HEATER UNDER CABINETS
MADE OF VINYL OR COATED WITH VINYL.
WARNING
6. Do not insert or allow foreign objects to enter any ventilation
7. To prevent a possible fire, do not block air intakes or exhaust
8. A heater has hot and arcing or sparking parts inside. Do not
9. Use this heater only as described in this manual. Any other
10. This heater is not approved for use in corrosive atmospheres
SAVE THESE INSTRUCTIONS
1
... The Employees of
Marley Engineered Products
!
or exhaust opening as this may cause an electric shock,
fire,or damage to the heater.
in any manner. Keep combustible materials, such as crates,
drapes, etc., away from heater. Do not install behind
doors, furniture, towels, or boxes.
use it in areas where gasoline, paint or flammable liquids are
used or stored.
use not recommended by the manufacturer may cause fire,
electric shock, or injury to persons.
such as marine, green house or chemical storage areas.
