- Page 1 Peters House The Orbital Centre Icknield Way Letchworth Garden City Hertfordshire SG6 1ET Tel. +44 (0) 845 130 7757 SifWeld MTS300/400 Approved Operation Manual TSX1D300MTS TSX3D400MTS...
-
Page 2: Declaration Of Conformity
The RoSH Directive 2011/65/EC, entering into force 2 January 2013 Type of Equipment Welding power source for MIG/MAG, TIG/TAG, MMA welding Brand name or trade mark SifWeld® Type designation etc. MTS300/400 Manufacturer or his authorised representative established within the EEA... - Page 3 Safety Guidelines These general safety norms cover both arc welding machines and plasma cutting machines unless otherwise noted. The equipment must only be used for the purpose it was designed for. Using it in any other way could result in damage or injury and in breach of the safety rules. Only suitably trained and competent persons should use the equipment.
- Page 4 Wear suitable protective flame resistant clothing. The sparks and spatter from welding, hot work pieces, and hot equipment can cause fires and burns. Welding on closed containers, such as tanks, drums, or pipes, can cause them to explode. Accidental contact of electrode to metal objects can cause arcs, explosion, overheating, or fire.
- Page 5 LF Declaration Consult the data plate on the equipment for the power supply requirements. Due to the elevated absorbency of the primary current from the power supply network, high power systems affect the quality of power provided by the network. Consequently, connection restrictions or maximum impedance requirements permitted by the network at the public network connection point must be applied to these systems.
-
Page 6: Table Of Contents
Contents Preface General Introduction Technical Specifications Overview Of Machine Installation Operation Troubleshooting Maintenance Warranty... -
Page 7: Preface
For your own safety and that of your working environment, pay particular attention to the safety instructions in the manual. For more information on SifWeld products, contact an authorised SifWeld dealer, or visit the SifWeld web site at www.sifweld.com. The specifications presented in this manual are subject to change without prior notice. -
Page 8: Introduction
The SifWeld MTS300 and 400 are inverter-based welding machines with a separate wire feed unit with added MMA and TIG functions. These are industrial machine equipped with a separate 4-roll-gear-driven wire feed system and 5metre interconnecting cables. -
Page 9: Technical Specifications
1.3 Technical Specifications SifWeld MTS300 SifWeld MTS400 Power voltage (V) 1 ph 230/240v 3 ph 380/415v Rated duty cycle 300Amps @ 35% 400Amps @ 100% 175Amps @ 100% Rated power MIG 12.8 KVA 18.2 KVA I Max MIG 45.0Amps 34.0Amps I Max MMA 51.0Amps... -
Page 10: Overview Of Machine
1.4 Overview of Machine 1 2 3 4 Front View Power Source Front Panel Layout 1. Mains Power LED 2. Thermal Overload LED 3. Over Current LED 4. V.R.D LED 5. 2T - 4T Trigger Switch 6. Voltage Meter 7. Gas Check Switch 8. -
Page 11: Installation
2. Installation Unpacking Check the packaging for any signs of damage. Carefully remove the machine and retain the packaging until the installation is complete. Positioning of the machine Place the machine on a firm, dry and level surface. Where possible, do not allow dust or other impurities to enter the machines cooling air flow. - Page 12 MIG Welding Insert the welding torch into the MIG torch Euro connector output socket on the front panel of the wire feed unit, and tighten it. Install the wire spool on the spindle adapter of the wire feed unit. Connect the cylinder equipped with the gas regulator to the gas inlet of the interconnection cable set. Insert the cable plug with work clamp into the “-”...
- Page 13 TIG Welding Insert the cable plug with the work clamp into the “+” socket on the front panel of the welding machine, and tighten it clockwise. Insert the cables plug of the TIG torch into the “-” socket on the front panel of the machine and tighten clockwise.
-
Page 14: Operation
3. Operation Before starting any welding activity ensure that you have suitable eye protection and protective clothing. Also take the necessary steps to protect any persons within the area. After connecting the welding leads as detailed you will need to switch the power switch on the back panel to ‘ON’... - Page 15 Gas selection Metal inert gas welding (MIG): Uses Argon (Ar), Helium (He) or Ar-He mixtures as the shield gas, and is mainly used for welding aluminium and its alloys. Metal active gas welding (MAG): Uses Argon (Ar) mixed with a certain amount of CO2 / O2 as the shield gas, and is usually used on steels in short circuit transfer and spray transfer.
-
Page 16: Troubleshooting
4. Troubleshooting In the event of a failure of the machine, contact an authorised SifWeld service centre. The following operation requires sufficient professional knowledge on electric aspects and comprehensive safety knowledge. Make sure the input cable of the machine is disconnected from the electricity supply and wait for 5 minutes before removing the machine covers. -
Page 17: Maintenance
NOTE! Remember that the machine may be repaired only by an electrical contractor or installer trained and authorised to perform such operations. 5.3 Regular maintenance Authorised SifWeld service centres can perform regular preventative maintenance by agreement. Tasks included in regular maintenance: •... -
Page 18: Warranty
Weldability Sif or an Authorised SifWeld Service Centre, in order to maintain validity of the extended warranty. Service visits can be booked online at www.sifweld.com or by calling 0870 330 7757 and will be charged at an average of £65 net per hour of travel/ servicing time. - Page 19 Notes...
