www.sifweld.com
Peters House
The Orbital Centre
Icknield Way
Letchworth Garden City
Hertfordshire
SG6 1ET
Tel. +44 (0) 845 130 7757
TIG
MMA
SifWeld TS200AC/DC
Approved
Operation Manual
TSX1T200AC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SifWeld TS200AC/DC TSX1T200AC and is the answer not in the manual?

Questions and answers

Summary of Contents for SifWeld SifWeld TS200AC/DC TSX1T200AC

  • Page 1 Peters House The Orbital Centre Icknield Way Letchworth Garden City Hertfordshire SG6 1ET Tel. +44 (0) 845 130 7757 SifWeld TS200AC/DC Approved Operation Manual TSX1T200AC...
  • Page 2: Declaration Of Conformity

    The RoSH Directive 2011/65/EC, entering into force 2 January 2013 Type of Equipment Welding power source for TIG/TAG, MMA welding Brand name or trade mark SifWeld® Type designation etc. TS200ACDC Manufacturer or his authorised representative established within the EEA Name, address, telephone no, fax no...
  • Page 3 Safety Guidelines These general safety norms cover both arc welding machines and plasma cutting machines unless otherwise noted. The equipment must only be used for the purpose it was designed for. Using it in any other way could result in damage or injury and in breach of the safety rules. Only suitably trained and competent persons should use the equipment.
  • Page 4 Wear suitable protective flame resistant clothing. The sparks and spatter from welding, hot work pieces, and hot equipment can cause fires and burns. Welding on closed containers, such as tanks, drums, or pipes, can cause them to explode. Accidental contact of electrode to metal objects can cause arcs, explosion, overheating, or fire.
  • Page 5 LF Declaration Consult the data plate on the equipment for the power supply requirements. Due to the elevated absorbency of the primary current from the power supply network, high power systems affect the quality of power provided by the network. Consequently, connection restrictions or maximum impedance requirements permitted by the network at the public network connection point must be applied to these systems.
  • Page 6: Table Of Contents

    Contents Preface General Introduction Technical Specifications Volt-Ampere Characteristics Duty Cycle & Over Heat Installation Front Panel Layout Operation TIG Parameters Warranty...
  • Page 7: Preface

    For your own safety and that of your working environment, pay particular attention to the safety instructions in the manual. For more information on SifWeld products, consult an authorised SifWeld dealer, or visit the SifWeld web site at www.sifweld.com. The specifications presented in this manual are subject to change without prior notice.
  • Page 8: Introduction

    1.2 Introduction This welding machine adopts the latest pulse width modulation (PWM) technology and insulated gate bipolar transistor (IGBT) inverter technology whilst being portable, small in size, light weight, and with low consumption. The machine has excellent performance in TIG and MMA mode. In TIG mode the following can be controlled: pre flow time, start current, current up slope, welding current, base current, pulse frequency, pulse duty factor, down slope time, crater current, post flow time, and parameters can be adjusted;...
  • Page 9: Technical Specifications

    1.3 Technical Specifications SifWeld TS200 AC/DC Power voltage (V) 1ph 230V±10% Frequency (Hz) 50/60 Rated input current (A) l-1 max 40.6 Rated input power (kw) Rated current range (A) 5-200 5-200 Power factor 0.80 No load voltage (VRD) 74 (14) 74 (14) Duty cycle (%) 40˚C 10min...
  • Page 10: Volt-Ampere Characteristics

    1.4 Volt-Ampere Characteristics This welding machine has an excellent volt-ampere characteristic. The relation between the conventional rated loading voltage U2 the conventional welding current I2 is as follows: When I2≤600A, U2=10+0.04 I2 (V), When I2>600A, U2=34 (V) (V) Volt-ampere characteristic The relation between the conventional loading voltage and welding current...
  • Page 11: Installation

    2. Installation Unpacking Check the packaging for any signs of damage. Carefully remove the machine and retain the packaging until the installation is complete. Location The machine should be located in a suitable position and environment. Care should be taken to avoid moisture, dust, steam, oil or corrosive gases.
  • Page 12: Front Panel Layout

    2.1 Front Panel Layout Front View Power Source Front Panel Layout 1. VRD (Voltage Reduction Device) LED indicator 2. Power LED Indicator 3. Error LED Indicator 4. Control Knob (Turn & Click) 5. LCD Display 6. Welding Power Output Socket (-) 7.
  • Page 13 TIG Welding Insert the cable plug with the work clamp into the “+” socket on the front panel of the welding machine, and tighten it clockwise. Insert the cables plug of the TIG torch into the “-” socket on the front panel of the machine and tighten clockwise.
  • Page 14: Operation

    3. Operation Before starting any welding activity ensure that you have suitable eye protection and protective clothing. Also take the necessary steps to protect any personnel within the area. TIG Operation The TS200 AC/DC uses a ‘mono control-point’ single ‘ turn & click’ adjustment knob and a LCD menu display system to navigate, change and apply changes to your parameter settings.
  • Page 15 AC TIG Operation Mode continued 1. Pre Gas Time 10. Digital Display Current - Slope Down/ 2. Start Current Crater Current/Post Gas 3. Current Slope Up 11. Pulse Duty Factor 4. Welding Current 12. Pulse Frequency 5. Base Current 13. 2T or 4T Selection 6.
  • Page 16 MMA-Pro Operation Mode 1. Hot Start, 2. Hot Start Current Values, 3. Welding Current, 4. Welding Current Values, 5. Arc Force 6. Arc Force Display, 7. Actual Welding Current Values, 8. AC or DC Selection, 9. Back to Main Menu, 10.
  • Page 17: Tig Parameters

    3.1 TIG Parameters The selective range of Gas nozzle diameter and protective gas flow rate Welding current DC Positive Connection Alternating Current range/A Gas nozzle diameter /mm Gas flow rate /L•min-1 Gas nozzle diameter /mm Gas flow rate /L•min-1 10~100 4~9.5 8~9.5 101~150...
  • Page 18 Operating Environment • Operation temperature range -10°C~+40°C. • Relative humidity is below 90 % (20°C). • Protect the machine against heavy rain or in hot circumstance against direct sunshine. • The content of dust, acid or corrosive gas in the surrounding air or substances can not exceed normal standard.
  • Page 19: Warranty

    Weldability Sif or an Authorised SifWeld Service Centre, in order to maintain validity of the extended warranty. Service visits can be booked online at www.sifweld.com or by calling 0870 330 7757 and will be charged at an average of £65 net per hour of travel/ servicing time.
  • Page 20 ® Peters House, The Orbital Centre, Icknield Way, Letchworth Garden City, Hertfordshire, SG6 1ET Tel. +44 (0) 845 130 7757 | Fax. +44 (0) 800 970 7757 | Email. sales@weldability-sif.com | www.sifweld.com www.sifweld.com...
