- Page 1 Peters House The Orbital Centre Icknield Way Letchworth Garden City Hertfordshire SG6 1ET Tel. +44 (0) 845 130 7757 PLA SMA SifWeld CUT 40 Digital Approved Operation Manual TSX1P40...
- Page 2 Type of Equipment Plasma cutter Brand name or trade mark SifWeld® Type designation etc. CUT 40 Digital Manufacturer or his authorised representative established within the EEA Name, address, telephone no, fax no Weldability Sif Peters House, The Orbital Centre Icknield Way, Letchworth...
- Page 3 Safety Guidelines These general safety guides cover both arc welding machines and plasma cutting machines unless otherwise noted. The equipment must only be used for the purpose it was designed for. Using it in any other way could result in damage or injury and in breach of the safety rules. Only suitably trained and competent persons should use the equipment.
- Page 4 Wear suitable protective flame resistant clothing. The sparks and spatter from welding, hot work pieces, and hot equipment can cause fires and burns. Welding on closed containers, such as tanks, drums, or pipes, can cause them to explode. Accidental contact of electrode to metal objects can cause arcs, explosion, overheating, or fire.
- Page 5 LF Declaration Consult the data plate on the equipment for the power supply requirements. Due to the elevated absorbency of the primary current from the power supply network, high power systems affect the quality of power provided by the network. Consequently, connection restrictions or maximum impedance requirements permitted by the network at the public network connection point must be applied to these systems.
-
Page 6: Table Of Contents
Contents Preface General Introduction Technical Specifications Overview Of Machines Installation Operation Maintenance Warranty TXP1P40... -
Page 7: Preface
This operating manual contains important information on the use, maintenance and safety of your SifWeld product. Please read the manual carefully before using the equipment for the first time. For your own safety and that of your working environment, pay particular attention to the safety instructions in the manual. -
Page 8: Introduction
The SifWeld Cut40 Digital can be used to efficiently cut mild and low-alloy steels, stainless, aluminium, copper, titanium and nickel alloys. -
Page 9: Technical Specifications
1.3 Technical Specifications SifWeld CUT40 Digital Power supply (V) 230V 10% Frequency (Hz) 50/60 Input power supply Rated input (KVA) Open circuit voltage Amperage range (A) 20 - 40 Rated Duty cycle (%) @ 40°C Efficiency Max cutting thickness (mm) 4.0 bar... -
Page 10: Overview Of Machines
Front & Rear Panel 1.4 Overview of Machine Front View Power source front panel layout 1. Alarm LED 2. Power LED 3. Over temperature LED 4. MCP knob 5. Cutting torch euro connector 6. Earth return 7. LCD display 8. Input power switch 9. -
Page 11: Installation
2. Installation Unpacking Check the packaging for any signs of damage. Carefully remove the machine and retain the packaging until the installation is complete. Positioning of the machine Place the machine on a firm, dry and level surface. Where possible, do not allow dust or other impurities to enter the machines cooling air flow. -
Page 12: Operation
3. Operation Before starting any plasma cutting activity ensure that you have suitable eye protection and protective clothing. Also take the necessary steps to protect any people within the area. 1. Check the connection of the work piece, earth cable, cutting torch, gas cylinder, regulator and hose. Make sure they are firm and reliable. -
Page 13: Maintenance
NOTE! Remember that the machine may be repaired only by an electrical contractor or installer trained and authorised to perform such operations. 5.3 Regular maintenance Authorised SifWeld service centres can perform regular preventative maintenance by agreement. Tasks included in regular maintenance: •... -
Page 14: Warranty
Weldability Sif or an Authorised SifWeld Service Centre, in order to maintain validity of the extended warranty. Service visits can be booked online at www.sifweld.com or by calling 0870 330 7757 and will be charged at an average of £65 net per hour of travel/ servicing time. - Page 15 Ordering information Description Part number TSX1P40 SifWeld Cut40 Digital package SifWeld Cut40 Digital 4m torch TSX1P4003 TSX1P4007 TSX1P4006 Electrode TSX1P4008 Shield cup TSX1P4009 Air diffuser TSX1P4004 Earth return TSX1P4005 Hi-flow air connector TXP1P40...
- Page 16 ® Peters House, The Orbital Centre, Icknield Way, Letchworth Garden City, Hertfordshire, SG6 1ET Tel. +44 (0) 845 130 7757 | Fax. +44 (0) 800 970 7757 | Email. sales@weldability-sif.com | www.sifweld.com www.sifweld.com...
