- Page 1 A-44-IR V2/A-54 V2 Quick Start Guide...
-
Page 2: Regulatory Information
Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. About This Document This manual applies to the A-44-IR-V2, and A-54 V2 network cameras. This manual may contain technical inaccuracies or printing errors, and the content is subject to change without notice. - Page 3 used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
- Page 4 See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point.
-
Page 5: Safety Instruction
· A-44 V2/A-54 V2 Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected. - Page 6 · A-44 V2/A-54 V2 Quick Start Guide ● Do not connect multiple devices to one power adapter as adapter may overload causing over-heating or a fire hazard. ● Please make sure that the plug is firmly connected to the power socket.
- Page 7 · A-44 V2/A-54 V2 Quick Start Guide shall be -22°F ~ 140°F), or expose it to high electromagnetic radiation. ● To avoid heat accumulation, good ventilation is required for operating environment. ● Keep the camera away from liquid while in use. ●...
- Page 8 · A-44 V2/A-54 V2 Quick Start Guide Table of Contents 1 Appearance Description ..............9 2 Installation ..................12 3 Setting the Network Camera over the LAN ........18 4 Accessing via Web Browser ............23...
-
Page 9: Appearance Description
· A-44 V2/A-54 V2 Quick Start Guide 1 Appearance Description The overview of the A-44 IR-V2/ A-54-V2 dome camera is shown below: Overview (1) Figure 1-1 The overview of the components and the interface are shown below: Overview (2) Figure 1-2... - Page 10 · A-44 V2/A-54 V2 Quick Start Guide The interfaces on the rear panel are shown below: Overview (3) Figure 1-3...
- Page 11 · A-44 V2/A-54 V2 Quick Start Guide Overview (4) Figure 1-4 Description of Overview (2~3) Table 1-1 Description Description Black Liner Bubble Lens BNC Interface Reset Status Indicator Test Serial Port Micro SD Card Slot Adapter Plate Side Outlet Description of Overview (4) Table 1-2 Description LAN（PoE）...
-
Page 12: Installation
· A-44 V2/A-54 V2 Quick Start Guide Note: Press RESET for approximately 10 seconds when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. 2 Installation Before you start: ... - Page 13 · A-44 V2/A-54 V2 Quick Start Guide ● Dust or grease on the dome cover will cause IR reflection. Please do not remove the dome cover film until the installation is finished. If there is dust or grease on the dome cover, clean the dome cover with clean soft cloth and isopropyl alcohol.
- Page 14 · A-44 V2/A-54 V2 Quick Start Guide the part shown in the figure below, and you can route the cables from the side outlet. Side Outlet Side Outlet Figure 2-2 2. Attach the adapter ring to the ceiling with the supplied screws.
- Page 15 · A-44 V2/A-54 V2 Quick Start Guide Install the Adapter Plate Figure 2-3 3. Align the camera base with the adapter ring and rotate the camera base counter clockwise to lock it into the adapter ring, and then secure it by tightening the lock screw. Lock Screw Install Camera to Adapter Ring...
- Page 16 · A-44 V2/A-54 V2 Quick Start Guide 3-axis Adjustment Figure 2-5 5. Adjust the focus and zoom. This camera is equipped with an electronic lens. You can adjust the zoom and focus by logging into the web interface of the device, and adjusting it from the PTZ control interface found on the top header of the Live View Image.
- Page 17 · A-44 V2/A-54 V2 Quick Start Guide Complete the Installation Figure 2-8...
-
Page 18: Setting The Network Camera Over The Lan
To view and configure the camera via LAN (Local Area Network), you need to connect the network camera in the same subnet with your PC. Then, install the Advidia Camera Finder Software to search and change the IP of network camera. - Page 19 This search may take 30 seconds or more depending on network size. After searching it will show total number and information of the Advidia cameras found on the network. Device information including the device type, IP address, port number, gateway, etc.
-
Page 20: Modify Device Information
· A-44 V2/A-54 V2 Quick Start Guide Click the refresh icon to refresh the online device list manually. The newly discovered devices will be added to the list. Note: You can click on each column heading to order the information. ... - Page 21 · A-44 V2/A-54 V2 Quick Start Guide Login Manager Figure 3-4 Launch Edit Table Figure 3-5...
- Page 22 · A-44 V2/A-54 V2 Quick Start Guide Edit Table Figure 3-6 5) Enter the desired IP address (or range if changing the IP address of more than one device) of the network camera in the address field of the edit table and click Apply Network Changes. You can also select “Dynamic IP”...
-
Page 23: Accessing Via Web Browser
· A-44 V2/A-54 V2 Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version / Vista / Win7 / Server 2003 / Server 2008 32bits CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 6.0 and above version, Apple Safari... - Page 24 · A-44 V2/A-54 V2 Quick Start Guide Login Interface Figure 4-1 5) Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.
- Page 25 · A-44 V2/A-54 V2 Quick Start Guide Download Plug-in Figure 4-2 Install Plug-in Figure 4-3...
- Page 26 · A-44 V2/A-54 V2 Quick Start Guide Install Plug-in Figure 4-4 6) Reopen the web browser after the installation of the plug-in and repeat the above steps 2-4 to login. Note: For detailed instructions of further configuration, please refer to the camera’s user manual...
