LST GO-55000-317 Specification Sheet

Optical Smoke Detector
GO-55000-317
• Addressable conventional technology
• Individual detector addressing by
means of optional address module
• Optional connection of remote
indicator
• Sealed electronics
Description
The Optical Smoke Detector GO-55000-317 uses the
scattered light principle and was developed for the de-
tection of smoke particles in a wide range of fi re de-
tection applications. The modern design of the sensing
chamber allows to reliably evaluate the characteristics
of fi re.
Addressable conventional technology is used for alarm
transmission to the fi re detection control panel. By
Specifi cations
Operating voltage
Current consumption
Ambient temperature
Relative humidity
Dimensions ø × H
Colour
Weight
Approval
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
means of the optional Address Module NG60-1, each
detector can be addressed individually. With that, the
activated detector can also be safely identifi ed directly
on the control panel.
The detector can be attached to various bases and it
can be protected against theft.
Supply through the detector line voltage
typ. 40µA (quiescent)
-20°C to +60°C (no condensation or icing)
0 – 95% (no condensation)
100 × 42 (mm)
white
100g
VdS G200017
241026
Optical Smoke Detector/Conv./65/Apo GO-55000-317
A
GO-55000-317_DBL_LST_EN_0804.PDF • PAGE 1
