LST ÜMM-55000-833 Specification Sheet

Mini Monitor Module
ÜMM-55000-833
• ADM loop technology with
Apollo/Discovery protocol
• One line-monitored input
• Integration of contact detectors into
the ADM loop
• Output for optional remote indicator
• Setting of module address by means
of address switch
• Small design
Description
The addressable Monitor Module ÜMM-55000-833
serves for the line-monitored integration of contact de-
tectors, such as manual call points, sprinkler system
contacts or supervising contacts, into the bidirectional
communication on the ADM loop with Apollo/Discovery
Specifi cations
Operating voltage
Current consumption
Ambient temperature
Dimensions L × W × H
Colour
Weight
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
protocol. The address is easily selected by means of an
integrated DIL switch, which is accessible through an
opening in the case. The module provides 6 wires for
establishing the desired connections. An optional remo-
te indicator can be connected to the module.
Supply through loop voltage
1mA (quiescent)
-20°C to +70°C
76 × 47 × 14 (mm)
white
46g
249061
Monitor Module/Anal./XP95/Apo ÜMM-55000-833
A
UMM-55000-833_DBL_LST_EN_0804.PDF • PAGE 1
