LST GD-55000-122 Specification Sheet

Thermal ROR Detector
GD-55000-122
• Addressable conventional technology
• Maximum temperature 57°C
• Individual detector addressing by
means of optional address module
• Optional connection of remote
indicator
• Sealed electronics
Description
The Thermal ROR Detector GD-55000-122 reacts to
temperature changes within defi ned periods of time,
up to a maximum temperature of 57°C. The intelligent
evaluation of these data allows the early detection of
spreading fi res. The detector complies with Class A1R
and can be used up to a room height of 7.5m.
Addressable conventional technology is used for alarm
transmission to the fi re detection control panel. By
Specifi cations
Operating voltage
Current consumption
Alarm temperature
Operating temperature
Ambient temperature
Relative humidity
Dimensions ø × H
Colour
Weight
Approval
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
means of the optional Address Module NG60-1, each
detector can be addressed individually. With that, the
activated detector can also be safely identifi ed directly
on the control panel.
The detector can be attached to various bases and it
can be protected against theft.
Supply through the detector line voltage
typ. 45µA (quiescent)
57°C (maximum-heat component)
max. +50°C
-20°C to +90°C (no condensation or icing)
0 – 95% (no condensation)
100 × 42 (mm)
white
80g
VdS G200059
242024
Thermal ROR Detector/Conv./65/Apo GD-55000-122
A
GD-55000-122_DBL_LST_EN_0804.PDF • PAGE 1
