LST GI-55000-217 Specification Sheet

Ionisation Smoke Detector
GI-55000-217
• Addressable conventional technology
• Individual detector addressing by
means of optional address module
• Optional connection of remote
indicator
• Flat design
• Sealed electronics
Description
The Ionisation Smoke Detector GI-55000-217 was de-
veloped for the safe detection of a wide range of smoke
aerosols. The modern design of the ionisation chamber
allows to reliably evaluate the characteristics of fi re.
The dual chamber principle with measurement and refe-
rence chamber ensures the automatic compensation of
environmental impact.
Addressable conventional technology is used for alarm
Specifi cations
Operating voltage
Current consumption
Ambient temperature
Relative humidity
Radioactive compound
Dimensions ø × H
Colour
Weight
Approval
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
transmission to the fi re detection control panel. By
means of the optional Address Module NG60-1, each
detector can be addressed individually. With that, the
activated detector can also be safely identifi ed directly
on the control panel.
The detector can be attached to various bases and it
can be protected against theft.
Supply through the detector line voltage
typ. 28µA (quiescent)
-20°C to +60°C
0 – 95% (no condensation)
Am241
100 × 42 (mm)
white
102g
VdS G200075
240027
Ionisation Smoke Detector/Conv./65/Apo GI-55000-217
A
GI-55000-217_DBL_LST_EN_0804.PDF • PAGE 1
