LST HT-11006 Specification Sheet

Thermal Max Detector
HT-11006
• Addressable conventional technology
• Alarm temperature 90°C
• Individual detector addressing by
means of optional address module
• Optional connection of remote
indicator
• Extremely fl at design
• Sealed electronics
Description
The Thermal Max Detector HT-11006 recognises a ma-
ximum temperature of 90°C as sign of fi re. It complies
with Class CS and can be used up to a room height of
6m.
Addressable conventional technology is used for alarm
transmission to the fi re detection control panel. By
means of the optional Address Module NG60-1, each
Specifi cations
Operating voltage
Current consumption
Alarm temperature
Operating temperature
Ambient temperature
Relative humidity
Dimensions ø × H
Colour
Weight
Approval
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
detector can be addressed individually, thus allowing to
display the detector address, as well as an assigned
element text, on a suitable fi re detection control panel.
A detector fault is indicated by a yellow fl ashing of the
multicoloured status LED.
The detector can be attached to various bases and it
can be protected against theft.
Supply through the detector line voltage
typ. 65µA (quiescent)
typ. 90°C
max. +80°C (continuous operation)
- 40°C to +90°C (no condensation or icing)
0 – 98% (no condensation)
100 × 36 (mm)
white
70g
VdS G204038
242035
Thermal Max Detector/Conv./ORBIS/Apo HT-11006
A
HT-11006_DBL_LST_EN_0804.PDF • PAGE 1
