LST GM-55000-137 Specification Sheet

Thermal Max Detector
GM-55000-137
• Addressable conventional technology
• Alarm temperature 90°C
• Individual detector addressing by
means of optional address module
• Optional connection of remote
indicator
• Sealed electronics
Description
The Thermal Max Detector GM-55000-137 recognises
a maximum temperature of 90°C as sign of fi re. It com-
plies with Class CS and can be used up to a room height
of 6m.
Addressable conventional technology is used for alarm
transmission to the fi re detection control panel. By
Specifi cations
Operating voltage
Current consumption
Alarm temperature
Operating temperature
Ambient temperature
Relative humidity
Dimensions ø × H
Colour
Weight
Approval
Order number
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
means of the optional Address Module NG60-1, each
detector can be addressed individually. With that, the
activated detector can also be safely identifi ed directly
on the control panel.
The detector can be attached to various bases and it
can be protected against theft.
Supply through the detector line voltage
typ. 45µA (quiescent)
typ. 90°C
max. +80°C (continuous operation)
-20°C to +90°C (no condensation or icing)
0 – 95% (no condensation)
100 × 42 (mm)
white
80g
VdS G200062
242027
Thermal Max Detector/Conv./65/Apo GM-55000-137
A
GM-55000-137_DBL_LST_EN_0804.PDF • PAGE 1
