Master Chef E480 Assembly Manual
  1. Manuals
  2. Brands
  3. Master Chef Manuals
  4. Grill
  5. E480
  6. Assembly manual
Master Chef E480 Assembly Manual

Master Chef E480 Assembly Manual

E480 barbecue
Hide thumbs Also See for E480:

Advertisement

Quick Links

Download this manual
TM
MC
E480 Barbecue
Assembly Manual
85-3040-4 (G45306) Propane
85-3041-2 (G45307) Natural Gas
1 YEAR LIMITED WARRANTY
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
Assemble your grill immediately.
Missing or damaged parts claims must be submitted within 30 days of purchase date.
For product inquiries, parts, warranty and troubleshooting support,
please call 1-855-453-2150.
Manual Revision #: 12022013 PD
ANS Z21.58b-2012-CSA 1.6b-2012
ANS Z21.58b-2012-CSA 1.6b-2012
ANS Z21.58b-2012-CSA 1.6b-2012
