Contents
1. Information before use ............................................................................................ 2
2. Description of the control box . ................................................................................. 4
3. Use .......................................................................................................................... 5
4. Program cleaning cycles for when you are away ...................................................... 7
(Vortex™ 3 4WD, Vortex™ 4 4WD) . .............................................................................. 7
5. Remote control (Vortex™ 4 4WD) ............................................................................ 9
6. Maintenance . ......................................................................................................... 10
7. Troubleshooting . .................................................................................................... 11
8. Product compliance ............................................................................................... 13
1. Information before use
1.1 Important
Check that your appliance has not been damaged during transport (shocks, broken parts, etc.). If you find any
problems don't hesitate to contact your reseller before using the cleaner.
1.2 Technical specifications
Control box power supply voltage
Robot power supply
Max absorbed power
Cable length
Cleaner size (L x W x h)
Package size (L x W x h)
Cleaner weight
Packaged weight
Theoretical cleaning width
Pump flow
Cycle duration
1.3 Recommendations for use
 The cleaner must operate in pool water having the following characteristics: Chlorine < 3 mg/l, pH between 6.8
and 7.6, temperature between 15°C and 35°C,
 Regular use of the cleaner means that your pool will always be clean and the filter less clogged,
 When the pool is dirty, especially when commissioning, remove the largest debris using a net in order to
optimise cleaner performance. Start by launching several bottom-only mode cleaning cycles.
 Remove any thermometers, toys and other objects that might damage the cleaner,
 Immerse the cleaner before launching a cleaning cycle,
 Do not leave the cleaner in the water permanently,
 Stow your cleaner on its caddy as soon as possible in order to avoid distorting the flexible edge at the filter
input.
 Do not leave the control box in direct sunlight after having used the cleaner,
 Never cover the control box while the cleaner is in operation,
 If part of the pool is not properly cleaned change the place where you immerse the cleaner until you find the
best spot,
H03839-00.B2 EN - 2013-09
220-240 VAC, 50 Hz
18 m or 21 m (Vortex™4 4WD)
43 x 48 x 27 cm
56 x 56 x 46 cm
Depending on the selected cycle
30 V DC
150 W
9 kg 500
19 kg
270 mm
16 m³/hr
2
