- Page 1 USER MANUAL DIVATOR LITE CYLINDERS...
-
Page 3: Safety Notice
Detailed instructions are not covered by this document. crackling sound The Divator Lite cylinder is a full composite cylinder containing many layers of glass and carbon fibres. These materials are expandable, when the cylinder is pressurized the layers move resulting... - Page 4 micro scratches The expansion of the pressurized vessel and the movement of fibres may cause micro scratches on the surface of the cylinder. These scratches can be seen if you carefully examine the cylinder surface. The scratches do not go deeper than the epoxy surface protecting the fibres. Like the crackling sound this is the materials normal behaviour and no action is required.
- Page 5 preparations before inspection carefully wash the cylinder. undertake examination assisted by a strong lamp. damage types and damage levels we will describe three levels of damages; level one is the only level of damage that is approved for continued use. The diver should use level 2 and 3 only as a reference for what is not allowed for continued use.
- Page 6 CuTS/SLASh WEAR/SCRATChES LEVEL 1 Acceptable No measurable effect on cylinder performance, approved for use. LEVEL 2 Inspection must be examined by an authorised inspector before continued use. LEVEL 3 Rejection The cylinder do not meet safety requirements and will be rendered unusable.
- Page 7 ImpACT mARkS ImpACT mARkS BuRN/fIRE cyLINDrIcAL pArT spherIcAL pArT...
