TNE1520-P and TNE1520-S
T1 Network Extenders Installation Instructions
Document Number TNE1-A2-GN12-00
December 2004
Contents
.................................................................................................. 14
Software and Firmware License Agreement
ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
The terms and conditions of this License Agreement (the "Agreement") will apply to the
software and/or firmware (individually or collectively the "Software") incorporated into
the Paradyne product (the "Product") purchased by you and any derivatives obtained
........................................................................................
....................................................................................
..................................................................................
....................................................................................
............................................................................ 10
.............................................................................................. 12
........................................................................ 14
.................................................
.....................................................................
1
......................................
1
3
3
3
4
5
9
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Paradyne TNE1520-P
Summary of Contents for Paradyne TNE1520-P
-
Page 1: Table Of Contents
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT PURCHASED BY YOU. The terms and conditions of this License Agreement (the “Agreement”) will apply to the software and/or firmware (individually or collectively the “Software”) incorporated into the Paradyne product (the “Product”) purchased by you and any derivatives obtained... - Page 2 Paradyne or its authorized distributor or reseller under the following terms and conditions: 1. Ownership: The Software is the sole property of Paradyne and/or its licensors. The Licensee acquires no title, right or interest in the Software other than the license granted under this Agreement.
-
Page 3: Product Documentation Online
Product Documentation Online Complete documentation for Paradyne products is available at www.paradyne.com. Select Support → Technical Manuals. To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 1-727-530-2000. Warranty, Sales, Service, and Training Information Contact your local sales representative, service representative, or distributor directly for any help needed. -
Page 4: Connecting To Power
Connecting to Power Plug the power supply into the Power Adapter port on the back of the TNE1520 and connect it to your power source. 04-17608 Verify that the Power LED on the front of the TNE1520 is illuminated. 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 04-17581 Upon start up, the Ethernet link will remain disabled (as indicated by solid illumination of... -
Page 5: Configure The T1 Ports
Configure the T1 Ports Configuration Switches for both T1 Port 1 and T1 Port 2 are numbered from left to right, 1–8. Table 1. TNE1520-P Provider Configuration Switches Switch Port 1 Port 2 Speed Speed Frame Type NOT USED: Port 2 frame type is... - Page 6 T1 lines require contiguous timeslots as indicated in the table below. Port 1 Configuration Switches 1 and 2 on the TNE1520-P work together to provide four timeslot/bandwidth options for the Port 1 T1 link. Port 2 Configuration Switches 1 and 2 on the TNE1520-P provide the timeslot/bandwidth options for the Port 2 T1 link.
- Page 7 Alternate Mark Inversion – Alternate Mark Inversion (AMI) alternates positive and negative pulses. Port 1 Configuration Switch 4 on the TNE1520-P and the TNE1520-S controls the line code of both T1 links (Port 1 and Port 2); line code for the two links cannot be configured independently.
- Page 8 Port 1 Configuration Switch #7 controls the timing of BOTH T1 links (Port 1 and Port 2) on the TNE1520-P; timing for the two links cannot be configured independently. The TNE1520-S determines T1 timing via communication with its partner T1 provider unit.
-
Page 9: Connect The T1 Lines
Single T1 Connection A single line connection can be established between a TNE1520-P and any of Paradynet’s T1 subscriber units, regardless of loop bonding capability. Likewise, a single line connection can also be established between an TNE1520-S and any of Paradyne’s T1 provider units, regardless of loop bonding capability. -
Page 10: Connect The Ethernet Line
Table 8. T1 RJ45 Pinouts Function Pin 1 Rx Ring Pin 2 Rx Tip Pin 3 Not used Pin 4 Tx Ring Pin 5 Tx Tip Pin 6 Not used Pin 7 Not used Pin 8 Not used Connect the Ethernet Line The 10/100 Ethernet Port auto-negotiates speed and duplex mode in accordance with the remote equipment to which it is connected;... - Page 11 Table 9. Ethernet Pinouts Function Pin 1 Pin 2 Rx– Pin 3 Pin 4 not used Pin 5 not used Pin 6 Tx– Pin 7 not used Pin 8 not used...
-
Page 12: Led Indicators
LED Indicators Whenever both T1 connections lose link or experience a T1 Alarm, the Ethernet link is automatically be disabled (as indicated by solid illumination of the Ethernet 100, Act and Lnk LEDs). Upon reestablishment of at least one of the T1 connections, the Ethernet link is reinstated and the Ethernet LEDs reflect current Ethernet Status. - Page 13 Table 10. LEDs (2 of 2) ADDITIONAL STATE INDICATION INFORMATION 10/100 Solid Green 100 Mbps Ethernet If the Ethernet 100 LED is Ethernet connection is established illuminated, the Ethernet Connection Lnk LED will also be illuminated. A solid green Ethernet 100 LED can also signify a T1 Alarm.
-
Page 14: Emi Notices
The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne Corporation. If the equipment includes a ferrite choke or chokes, they must be installed per the installation instructions. - Page 15 — Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. — Do not use the telephone to report a gas leak in the vicinity of the leak. Copyright © 2004 Paradyne Corporation. Printed in U.S.A.
- Page 16 (" " *TNE1-A2-GN12-00*...
