SNE2020G-P and SNE2020G-S
2-Port Network Extenders Installation Instructions
Document Number SNE2-A2-GN11-10
July 2005
Contents
...................................................................................................
.................................................................................................. 13
................................................................................................... 15
................................................................................................. 15
.........................................................................................
.....................................................................................
.............................................................................
.......................................................................
....................................................................... 10
.............................................................................................. 10
.............................................................................................. 11
......................................................................... 13
........................................................................ 15
.................................................
.....................................................................
............................................................. 14
1
................................... 15
2
3
4
4
5
6
8

Advertisement

Table of Contents
loading

Related Manuals for Paradyne SNE2020G-P

Summary of Contents for Paradyne SNE2020G-P

  • Page 1: Table Of Contents

    SNE2020G-P and SNE2020G-S 2-Port Network Extenders Installation Instructions Document Number SNE2-A2-GN11-10 July 2005 Contents Software and Firmware License Agreement Product Documentation Online Introduction Package Contents Connecting to Power Switchpack Configuration Connecting the SHDSL Lines Connecting the Ethernet Line Ferrite Chokes ...

  • Page 2: Software And Firmware License Agreement

    Software and Firmware License Agreement ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT. IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE...

  • Page 3: Product Documentation Online

    ANY AND ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT. Some states or other jurisdictions do not allow the exclusion of implied warranties on limitations on how long an implied warranty lasts, so the above limitations may not apply to you.

  • Page 4: Introduction

    Introduction The family of EFM Based Network Extenders provide an extremely flexible and easy to use solution for providing Ethernet based services to subscribers throughout the service providers network. The SNE2020 is fully DSL The Easy Way™ compliant, so that configuration requirements are removed completely, allowing this device to be installed into the customer premises quickly.

  • Page 5: Connecting To Power

    Connecting to Power Plug the power supply into the Power Adapter port on the back of the SNE2020G and connect it to your power source. Verify that the Power LED on the front of the SNE2020G is illuminated. Upon start up, the Ethernet link will remain disabled (as indicated by solid illumination of the Ethernet Rx, Tx, and Lnk LEDs) until at least one of the two SHDSL connections has been established.

  • Page 6: Switchpack Configuration

    * Adaptive mode allows the SNE2020G-P to train up to the best possible speed supported by the SNE2020G-P, the remote modem to which it is connected, and the copper cable pair(s) connecting the two. The maximum reachable distance for a single line SNE2020G-P connection in Adaptive mode is 25,400 feet (at 144 kbps).
  • Page 7 Ethernet Duplex Mode: Switch 4 The Ethernet link can be configured at either Full Duplex or Half Duplex mode. Although both ends of the ETHERNET connection must have the same duplex mode configuration, it is not necessary for partner providers and subscribers to be configured the same.

  • Page 8: Connecting The Shdsl Lines

    Connecting the SHDSL Lines An SNE2020G-S must be connected via an SHDSL line to an SNE2020G-P, a Mini DSLAM, a Micro DSLAM, or a Broadband Access Concentrator (BAC) interface module. Neither a subscriber-to-subscriber nor a provider-to-provider connection will function. Loop Bonded Connection Using two SHDSL lines for one network connection (loop bonding) will yield twice the speed of a single SHDSL connection.
  • Page 9 RJ45 Port Table 3. SDSL RJ45 Port Connection not used not used not used Ring not used not used not used Cable and RJ45 Connector...

  • Page 10: Connecting The Ethernet Line

    Connecting the Ethernet Line Plug the Ethernet cable into the Ethernet Connection RJ45 port on the back of the SNE2020G. Verify the connection: solid illumination of the Ethernet Connection Lnk LED on the front of the SNE2020G indicates a link has been established, if an SHDSL connection has already been made.

  • Page 11: Led Indicators

    LED Indicators Table 5. LEDs (1 of 2) State Power Solid Green SDSL 1 & 2 Pulsing Green* Solid Green Illumination Ethernet Collision Illumination Flashing Red* Solid Red Indication Additional Information SNE2020G is If the Power LED is not operational illuminated, it is unlikely the SNE2020G is receiving power.
  • Page 12 Table 5. LEDs (2 of 2) State Ethernet Rx Flashing Amber* Solid Amber Illumination Ethernet Tx Flashing Amber* Solid Amber Illumination Ethernet Lnk Solid Green Illumination * A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more rapid, less constant rate.

  • Page 13: Emi Notices

    EMI Notices United States – EMI Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 14: Supplier's Declaration Of Conformity

    Date of Issue: 7/14/2005 Paradyne Corporation, located at the above address, hereby certifies that the Model SNE2020G-P, Model SNE2020G-S, Model SNE2000G-P, and Model SNE2000G-S bearing labeling identification number US:AW2DLNANSNE2020 complies with: the Federal Communications Commission's ("FCC") Rules and Regulations 47 CFR Part 68, and the Administrative Council on Terminal Attachments ("ACTA")-adopted technical...

  • Page 15: Notice To Users Of The Canadian Telephone Network

    Notice to Users of the Canadian Telephone Network NOTICE: This equipment meets the applicable Industry Canada Terminal Equipment Technical Specifications. This is confirmed by the registration number. The abbreviation IC before the registration number signifies that registration was performed based on a Declaration of Conformity indicating that Industry Canada technical specifications were met.
  • Page 16 3. Do not attempt to service this product yourself, as opening or removing covers may expose you to hazardous voltage or to other risks. Refer all servicing to qualified service personnel. 4. General purpose cables are used with this product for connection to the network. Special cables, which may be required by the regulatory inspection authority for the installation site, are the responsibility of the customer.
