Table of Contents
Advertisement
Quick Links
SNE2020G-P and SNE2020G-S
2-Port Network Extenders Installation Instructions
Document Number SNE2-A2-GN11-00
September 2004
Contents
.................................................................................................. 11
Software and Firmware License Agreement
ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
The terms and conditions of this License Agreement (the "Agreement") will apply to the
software and/or firmware (individually or collectively the "Software") incorporated into
the Paradyne product (the "Product") purchased by you and any derivatives obtained
from the Software, including any copy of either. If you have executed a separate written
agreement covering the Software supplied to you under this purchase, such separate
written agreement shall govern.
........................................................................................
....................................................................................
.............................................................................
.......................................................................
.......................................................................
..............................................................................................
..............................................................................................
........................................................................ 11
.................................................
..................................................................... 12
1
1
3
3
4
6
8
8
9
Advertisement
Table of Contents
Related Manuals for Paradyne SNE2020G-S
Summary of Contents for Paradyne SNE2020G-S
-
Page 1: Table Of Contents
The terms and conditions of this License Agreement (the “Agreement”) will apply to the software and/or firmware (individually or collectively the “Software”) incorporated into the Paradyne product (the “Product”) purchased by you and any derivatives obtained from the Software, including any copy of either. If you have executed a separate written agreement covering the Software supplied to you under this purchase, such separate written agreement shall govern. - Page 2 Paradyne or its authorized distributor or reseller under the following terms and conditions: 1. Ownership: The Software is the sole property of Paradyne and/or its licensors. The Licensee acquires no title, right or interest in the Software other than the license granted under this Agreement.
-
Page 3: Package Contents
9. Upon such termination, the Licensee shall refrain from any further use of the Software and destroy the original and all copies of the Software in the possession of Licensee together with all documentation and related materials. 10. This Agreement shall be governed by the laws of the State of Florida, without regard to its provisions concerning conflicts of laws. -
Page 4: Switchpack Configuration
The maximum reachable distance for a single line SNE2020G-P connection in Adaptive mode is 25,400 feet (at 144 kbps). Bandwidth cannot be configured on the SNE2020G-S. Subscriber units determine bandwidth via communication with their partner SHDSL provider unit. - Page 5 Ethernet Duplex Mode: Switch 4 The Ethernet link can be configured at either Full Duplex or Half Duplex mode. Although both ends of the ETHERNET connection must have the same duplex mode configuration, it is not necessary for partner providers and subscribers to be configured the same.
-
Page 6: Connecting The Shdsl Lines
Connecting the SHDSL Lines An SNE2020G-S must be connected via an SHDSL line to an SNE2020G-P, a Mini DSLAM, a Micro DSLAM, or a Broadband Access Concentrator (BAC) interface module. Neither a subscriber-to-subscriber nor a provider-to-provider connection will function. Loop Bonded Connection Using two SHDSL lines for one network connection (loop bonding) will yield twice the speed of a single SHDSL connection. - Page 7 RJ45 Port Cable and RJ45 Connector Table 3. SDSL RJ45 Port Connection not used not used not used Ring not used not used not used...
-
Page 8: Connecting The Ethernet Line
Connecting the Ethernet Line Plug the Ethernet cable into the Ethernet Connection RJ45 port on the back of the SNE2020G. Verify the connection: solid illumination of the Ethernet Connection Lnk LED on the front of the SNE2020G indicates a link has been established, if an SHDSL connection has already been made. -
Page 9: Led Indicators
LED Indicators Table 5. LEDs (1 of 2) State Indication Additional Information Power Solid Green SNE2020G is If the Power LED is not operational illuminated, it is unlikely the SNE2020G is receiving power. None of the LEDs will be illuminated. SDSL 1 &... - Page 10 Table 5. LEDs (2 of 2) State Indication Additional Information Ethernet Rx Flashing Ethernet activity The SNE2020G is receiving Amber* data from the Ethernet network. Solid Amber Heavy Rx traffic The SNE2020G is receiving large amounts of data from the Ethernet network.
-
Page 11: Emi Notices
The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne Corporation. If the equipment includes a ferrite choke or chokes, they must be installed per the installation instructions. -
Page 12: Product Documentation Online
Product Documentation Online Complete documentation for Paradyne products is available at www.paradyne.com. Select Support → Technical Manuals. To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 1-727-530-2000. '" " *SNE2-A2-GN11-00*...
