Page 1: Table Of Contents
TNE1544 and TNE1584 T1 Network Extenders Installation Instructions Document Number TNE1-A2-GN14-20 July 2005 Contents Software and Firmware License Agreement Introduction to the TNE1544 and TNE1584 Package Contents Release Notes Powering Up the Network Extender Connecting the T1 Lines Connecting the Ethernet Lines...
Page 2: Software And Firmware License Agreement
Software and Firmware License Agreement ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT. IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE...
Page 3 5. Except for the Product warranty contained in the manual, the Software is provided “AS IS” and in its present state and condition and Paradyne makes no other warranty whatsoever with respect to the Product purchased by you. THIS AGREEMENT EXPRESSLY EXCLUDES ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, OR ORAL OR WRITTEN, INCLUDING WITHOUT LIMITATION: Any warranty that the Software is error-free, will operate uninterrupted in your...
Page 4: Introduction To The Tne1544 And Tne1584
Introduction to the TNE1544 and TNE1584 Paradyne's TNE1544 and TNE1584 are loop bonding network extenders for Paradyne's 12000 and 4000 IP Broadband Loop Carriers that provide up to 6 Mbps (TNE1544) or 12 Mbps (TNE1584) of symmetrical bandwidth using T1 lines.
Page 5: Powering Up The Network Extender
Powering Up the Network Extender The DC power terminal block on the network extender has five terminals: two positive, two negative, and one ground. Only one positive terminal and one negative terminal pair need be connected for operational purposes. The second positive and negative terminal pair may be connected to a backup DC power supply for redundancy.
Page 6: Connecting The T1 Lines
Connecting the T1 Lines The primary feature of the network extender is loop bonding capability, although both the provider and subscriber units are able to function with a single T1 connection. Loop Bonded Connection Using multiple T1 lines for one network connection (loop bonding) multiplies the speed and data passing capability of the network extender.
Page 7: Connecting The Ethernet Lines
Single T1 Connection A single line connection can be established between a subscriber unit and any Paradyne T1 provider unit, regardless of loop bonding capability. Likewise, a single line connection can also be established between a provider unit and any of Paradyne's T1 subscriber units, regardless of loop bonding capability.
Page 8: Led Indicators
LED Indicators Table 2. LEDs (1 of 2) State 10/100 Pulsing Ethernet Green Connections Solid Lnk/Act Green Illuminated 10/100 Solid Ethernet Amber Connections Duplex/ Illuminated Collision Pulsing Amber 10/100 Solid Ethernet Green Connections Illuminated Indication Standard operation Ethernet connection is established No Ethernet connection Full duplex Ethernet...
Page 9 Table 2. LEDs (2 of 2) State Flashing Connections Green* Lnk/Alm Solid (Ports 1–4 Green or 1–8) Solid Amber Pulsing Amber Flashing Connections Amber (Ports 1–4 Illuminated or 1–8) Flashing Connections Amber (Ports 1–4 Illuminated or 1–8) Power Solid Green * A pulsing LED blinks steadily at a rate of once per second.
Page 10: Web Interface
Web Interface The network extender’s integral Network Management System (NMS) lets you configure and monitor the network extender using a standard web browser. To manage a Provider unit using NMS, connect your PC to any Ethernet port of the Provider unit. By default, the Subscriber unit can be managed by the NMS through its T1 and Ethernet ports, but you must first create a static entry for the unit in your PC’s ARP table.
Page 11 Web Interface System Requirements Web Browser – Required for running NMS. Compatible web browsers include, but are not limited to, Microsoft Internet Explorer (v4.0 or higher) and Netscape Navigator (v4.0 or higher). NMS is optimized for use with Internet Explorer. Use your browser's default settings when running NMS.
Page 12 10. Click on >> Next >>. The login dialog box appears. Log in using: Username: Password: The NMS home page appears. superuser Password...
Page 13 From this screen you can: Click on . . . Management Config. Advanced Config. HTTP Password SNMP Config. SNMP Community Ethernet Connections Lnk/Act LEDs Ethernet Duplex Mode and Speed T1 Connections Lnk/Alm LEDs To configure . . . IP Address, Subnet Mask, Default Gateway, Inband Management VLAN ID and Priority System Name and Location, Management IP Address Filter, TFTP and Telnet access...
Page 14: Command Line Interface
Command Line Interface The network extender can be managed with a Command Line Interface (CLI) through either a direct PC to COM (Communication) Port connection or from a remote network connection via Telnet. CLI System Requirements Straight-Through 8-Pin Modular Ethernet Cable – Required for establishing a direct connection from the COM port to a DB9 adapter.
Page 15: Resetting The Network Extender To Factory Defaults
Logging Into the CLI Once your terminal emulation program has been launched, device information is displayed, followed by a request for username and password. You must log in as a superuser in order to make configuration changes. Username: Password: After you have logged in, enter a question mark (?) to list the available commands. Using the CLI to Establish Inband Management CLI Set commands are used to establish inband management.
Page 16: Connector Pin Assignments
Connector Pin Assignments T1 RJ48C Pin Assignments Table 3. T1 RJ48C Pin Assignments Function Pin 1 Rx Ring Pin 2 Rx Tip Pin 3 not used Pin 4 Tx Ring Pin 5 Tx Tip Pin 6 not used Pin 7 not used Pin 8 not used...
Page 17 DB9 to 8-Pin Modular Adapter Pinouts To connect the COM port to the DB9 serial port of a PC, use an adapter wired as shown: Table 5. DB9 to 8-Pin Modular Adapter Pinouts 8-Pin Modular Port Transmit Data Data Set Ready Receive Data Ground Data Terminal Ready...
Page 18: Specifications
Criteria Up to 1.5 Mbps per T1 port TNE1544: Up to 6 Mbps using loop bonded T1 circuits TNE1584: Up to 12 Mbps using loop bonded T1 circuits 1.25" (3.2 cm) High x 8.5" (21.6 cm) Wide x 4.75" (12.1 cm)
Page 19: Emi Notices
EMI Notices United States – EMI Notice: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 20 A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. See installation instructions for details. If the network extender causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required.
Page 21: Supplier's Declaration Of Conformity
15 March 2005 Paradyne Corporation, located at the above address, hereby certifies that the following models: TNE1584-X and TNE1544-X (X = P or S) bearing labeling identification number US:AW2DDNANTNE1584 complies with: the Federal Communications Commission's ("FCC") Rules and Regulations 47 CFR Part 68, and the Administrative Council on Terminal Attachments ("ACTA")-adopted technical criteria TIA-968-A,...
Page 22: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Do not allow anything to rest on the power cord and do not locate the product where persons will walk on the power cord. 3.
Page 23: Product Documentation Online
Product Documentation Online Complete documentation for Paradyne products is available at www.paradyne.com. Select Support → Technical Manuals. To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 1-727-530-2000. Copyright 2005 Paradyne Corporation. Printed in U.S.A.
Page 24 *TNE1-A2-GN14-20* *TNE1-A2-GN14-20*...
