Paradyne ENE2000-P Installation Instructions Manual

Hide thumbs Also See for ENE2000-P:

Advertisement

ENE2000-P and ENE2000-S
E1 Network Extenders Installation Instructions
Document Number ENE2-A2-GN12-00
April 2005
Contents
.................................................................................................. 11

Software and Firmware License Agreement

ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
The terms and conditions of this License Agreement (the "Agreement") will apply to the
software and/or firmware (individually or collectively the "Software") incorporated into
the Paradyne product (the "Product") purchased by you and any derivatives obtained
from the Software, including any copy of either. If you have executed a separate written
agreement covering the Software supplied to you under this purchase, such separate
written agreement shall govern.
.........................................................................................
...........................................................................
................................................................................
................................................................................
.......................................................................
..............................................................................................
.................................................................................. 10
........................................................................ 11
.................................................
..................................................................... 12
1
1
3
3
4
6
7
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENE2000-P and is the answer not in the manual?

Questions and answers

Summary of Contents for Paradyne ENE2000-P

  • Page 1: Table Of Contents

    The terms and conditions of this License Agreement (the “Agreement”) will apply to the software and/or firmware (individually or collectively the “Software”) incorporated into the Paradyne product (the “Product”) purchased by you and any derivatives obtained from the Software, including any copy of either. If you have executed a separate written agreement covering the Software supplied to you under this purchase, such separate written agreement shall govern.
  • Page 2 Paradyne or its authorized distributor or reseller under the following terms and conditions: 1. Ownership: The Software is the sole property of Paradyne and/or its licensors. The Licensee acquires no title, right or interest in the Software other than the license granted under this Agreement.
  • Page 3: Package Contents

    9. Upon such termination, the Licensee shall refrain from any further use of the Software and destroy the original and all copies of the Software in the possession of Licensee together with all documentation and related materials. 10. This Agreement shall be governed by the laws of the State of Florida, without regard to its provisions concerning conflicts of laws.
  • Page 4: Configuring The E1 Port

    Ports configured to operate as fractional E1 lines require contiguous timeslots as indicated in the table below. Port 1 configuration switches 1 and 2 on the ENE2000-P work together to provide four timeslot/bandwidth options for the Port 1 E1 link.
  • Page 5 1,024 1–8 Frame Type Switch 3 sets the Frame Type for the E1 port on both the ENE2000-P and the ENE2000-S. Frame type is the E1 data encapsulation method. A frame consists of 248 bits (8-bit samples of each of the 31 E1 data channels plus a synchronization bit) transmitted at a rate of 8,000 frames per second (1,984 kbps) across the E1 line.
  • Page 6: Connecting The E1 Line

    High Density Binary 3 Alternate Mark Inversion Timing Switch 7 sets the timing for the ENE2000-P (only). The ENE2000-S determines timing for its E1 link via communication with its partner E1 provider unit. Timing refers to the clock source for E1 transmission links.
  • Page 7: Connecting The Ethernet Line

    Connecting the Ethernet Line The 10/100BaseT Ethernet Port auto-negotiates speed and duplex mode in accordance with the remote equipment to which it is connected; Ethernet speed and duplex mode configurations cannot be configured on the ENE2000. For the best connection results, the remote device (PC, hub, or switch) should be set to auto-negotiate speed and duplex mode.
  • Page 8: Led Indicators

    LED Indicators Table 6. LEDs (1 of 2) State Indication Additional Information Flashing E1 connection is Traffic is flowing. Connection Green* established and active Solid Problematic E1 A connection exists but there Green connection is indication of a problem with the E1 line.
  • Page 9 Table 6. LEDs (2 of 2) State Indication Additional Information 10/100 Solid 100 Mbps Ethernet If the Ethernet 100 LED is Ethernet Green connection is illuminated, the Ethernet Lnk Connection established LED will also be illuminated.A solid green Ethernet 100 LED can also signify an E1 Alarm.
  • Page 10: Rj45 Pin Assignments

    RJ45 Pin Assignments E1 RJ45 Pin Assignments If you are using a shielded E1 cable for your network connection, it must be grounded through pins 3, 6, 7 and 8. Table 7. E1 RJ45 Pin Assignments Function Pin 1 Rx Ring Pin 2 Rx Tip Pin 3...
  • Page 11: Emi Notices

    The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne Corporation. If the equipment includes a ferrite choke or chokes, they must be installed per the installation instructions.
  • Page 12: Product Documentation Online

    — Do not use the telephone to report a gas leak in the vicinity of the leak. Product Documentation Online Complete documentation for Paradyne products is available at www.paradyne.com. Select Support → Technical Manuals. To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 1-727-530-2000. *ENE2-A2-GN12-00* *ENE2-A2-GN12-00*...
