ENE2044 and ENE2084
E1 Network Extenders Installation Instructions
Document Number ENE2-A2-GN11-10
March 2005
Contents
................................................................................................ 10
................................................................................................ 17
.................................................................................................. 18

Software and Firmware License Agreement

ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
.........................................................................................
...............................................................................
..............................................................................................
............................................................................... 13
........................................................................................... 15
........................................................................ 19
.................................................
.................................................
.....................................................................
..................................................................... 20
1
................................ 12
1
3
4
6
7
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENE2044 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paradyne ENE2044

Summary of Contents for Paradyne ENE2044

  • Page 1: Table Of Contents

    ENE2044 and ENE2084 E1 Network Extenders Installation Instructions Document Number ENE2-A2-GN11-10 March 2005 Contents Software and Firmware License Agreement Introduction to the ENE2044 and ENE2084 Package Contents Connecting the E1 Lines Connecting the Ethernet Lines LED Indicators Web Interface ... 10...
  • Page 2 The terms and conditions of this License Agreement (the “Agreement”) will apply to the software and/or firmware (individually or collectively the “Software”) incorporated into the Paradyne product (the “Product”) purchased by you and any derivatives obtained from the Software, including any copy of either. If you have executed a separate written agreement covering the Software supplied to you under this purchase, such separate written agreement shall govern.

  • Page 3: Introduction To The Ene2044 And Ene2084

    12000 and 4000 IP Broadband Access Concentrators that provide up to 8 Mbps (ENE2044) or 16 Mbps (ENE2084) of symmetrical bandwidth using E1 lines. The ENE2044 features four E1 ports and the ENE2084 eight E1 ports, each capable of up to 2.0 Mbps bandwidth. When used with any Paradyne loop bonding compatible product, up to eight ports may be used to deliver high-speed bandwidth at any given distance.

  • Page 4: Package Contents

    Package Contents Unpack and Inspect the network extender. If there is any visible damage, do not attempt to connect the device. Contact your sales or service provider. Powering Up the Network Extender The DC power terminal block on the network extender has five terminals: two positive, two negative, and one ground.
  • Page 5 5. Verify that the Power LED on the front of the network extender is illuminated.

  • Page 6: Connecting The E1 Lines

    Connecting the E1 Lines The primary feature of the network extender is loop bonding capability, although both the provider and subscriber units are able to function with a single E1 connection. Loop Bonded Connection Using multiple E1 lines for one network connection (loop bonding) multiplies the speed and data passing capability of the network extender.

  • Page 7: Connecting The Ethernet Lines

    Single E1 Connection A single line connection can be established between a subscriber unit and any Paradyne E1 provider unit, regardless of loop bonding capability. Likewise, a single line connection can also be established between a provider unit and any of Paradyne's E1 subscriber units, regardless of loop bonding capability.

  • Page 8: Led Indicators

    LED Indicators Table 2. LEDs (1 of 2) State 10/100 Pulsing Ethernet Green Connections Solid Lnk/Act Green Illuminated 10/100 Solid Ethernet Amber Connections Duplex/ Illuminated Collision Pulsing Amber 10/100 Solid Ethernet Green Connections Illuminated Indication Standard operation Ethernet connection is established No Ethernet connection Full duplex Ethernet...
  • Page 9 Table 2. LEDs (2 of 2) State Flashing Connections Green* Lnk/Alm Solid (Ports 1–4 Green or 1–8) Solid Amber Pulsing Amber Flashing Connections Amber (Ports 1–4 Illuminated or 1–8) Flashing Connections Amber (Ports 1–4 Illuminated or 1–8) Power Solid Green * A pulsing LED blinks steadily at a rate of once per second.

  • Page 10: Web Interface

    Web Interface The network extender’s integral Network Management System (NMS) lets you configure and monitor the network extender using a standard web browser. To manage a Provider unit using NMS, connect your PC to any Ethernet port of the Provider unit. By default, the Subscriber unit can be managed by NMS through an active E1 line from the Provider side of the network.
  • Page 11 5. Write down the current IP Address and Subnet Mask in the Internet Protocol (TCP/IP) Properties dialog box. When you are done using NMS, you will need to reconfigure your PC with these values. 6. In the Internet Protocol (TCP/IP) Properties dialog box, click in the radio button labeled “Use the following IP address”...

  • Page 12: Establishing An Arp Table Entry For A Subscriber Unit

    From this screen you can: Click on . . . Management Config. Advanced Config. HTTP Password SNMP Config. SNMP Community Ethernet Connections Lnk/Act LEDs Ethernet Duplex Mode and Speed E1 Connections Lnk/Alm LEDs Establishing an ARP Table Entry for a Subscriber Unit Inband management is turned on by default in the subscriber unit, but the unit will not respond to an ARP request containing the unit’s default IP address.

  • Page 13: Command Line Interface

    For security purposes you may want to turn off inband management of the unit to prevent a local PC from managing the unit from the Ethernet ports. Command Line Interface The network extender can be managed with a Command Line Interface (CLI) through either a direct PC to COM (Communication) Port connection or from a remote network connection via Telnet.
  • Page 14 Launching the Terminal Emulation Program Launch the terminal emulation program on your PC and configure the program settings. Actual configurations will depend upon the program being used, though settings should be modeled after the list below; most are standard defaults. Refer to your terminal emulation program’s user manual for further information.

  • Page 15: Pin Assignments

    Pin Assignments E1 RJ45 Pin Assignments If you are using a shielded E1 cable for your network connection, it must be grounded through pins 3, 6, 7 and 8. Table 3. E1 RJ45 Pin Assignments Function Pin 1 Rx Ring Pin 2 Rx Tip Pin 3...
  • Page 16 DB9 to RJ45 Adapter Pinouts To connect the COM port to the DB9 serial port of a PC, use an adapter wired as shown: Table 5. DB9 to RJ45 Adapter Pinouts RJ45 Port Transmit Data Data Set Ready Receive Data Ground Data Terminal Ready Pins not shown are unused.

  • Page 17: Specifications

    E1 Line Code: HDB3, AMI Up to 2.0 Mbps per E1 port ENE2044: Up to 8 Mbps using loop bonded E1 circuits ENE2084: Up to 16 Mbps using loop bonded E1 circuits EMC: FCC Part 15; ICES-003; EN 300 386-2; CE Marking Safety: UL1950, CSA C22.2 No.

  • Page 18: Emi Notices

    EMI Notices United States – EMI Notice: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 19: Important Safety Instructions

    Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Do not allow anything to rest on the power cord and do not locate the product where persons will walk on the power cord. 3.

  • Page 20: Product Documentation Online

    Product Documentation Online Complete documentation for Paradyne products is available at www.paradyne.com. Select Support → Technical Manuals. To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 1-727-530-2000. *ENE2-A2-GN11-10* *ENE2-A2-GN11-10* Copyright 2005 Paradyne Corporation. Printed in U.S.A.
