TNE1500-P and TNE1500-S
T1 Network Extenders Installation Instructions
Document Number TNE1-A2-GN10-10
September 2005
Contents
.................................................................................................. 12

Software and Firmware License Agreement

ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
................................................................................
.........................................................................................
.....................................................................................
.................................................................................
.....................................................................................
............................................................................
.............................................................................................. 10
......................................................................... 12
........................................................................ 15
.................................................
......................................
............................................................. 14
1
................................... 14
1
3
3
3
4
5
8
9

Advertisement

Table of Contents
loading

Summary of Contents for Paradyne TNE1500-P

  • Page 1: Table Of Contents

    TNE1500-P and TNE1500-S T1 Network Extenders Installation Instructions Document Number TNE1-A2-GN10-10 September 2005 Contents Software and Firmware License Agreement Product Documentation Warranty, Sales, Service, and Training Information Package Contents Connecting to Power Configuring the T1 Port Connect the T1 Line...
  • Page 2 The terms and conditions of this License Agreement (the “Agreement”) will apply to the software and/or firmware (individually or collectively the “Software”) incorporated into the Paradyne product (the “Product”) purchased by you and any derivatives obtained from the Software, including any copy of either. If you have executed a separate written agreement covering the Software supplied to you under this purchase, such separate written agreement shall govern.
  • Page 3: Product Documentation

    7. The rights granted under this Agreement may not be assigned, sublicensed or otherwise transferred by the Licensee to any third party without the prior written consent of Paradyne. 8. This Agreement and the license granted under this Agreement shall be terminated in the event of breach by the Licensee of any provisions of this Agreement.
  • Page 4: Connecting To Power

    Connecting to Power Plug the power supply into the Power Adapter port on the back of the TNE1500 and connect it to your power source. Verify that the Power LED on the front of the TNE1500 is illuminated. Upon start up, the Ethernet link will remain disabled (as indicated by no illumination of the Ethernet 100, Act, and Lnk LEDs) until the T1 connection has been established.
  • Page 5: Configuring The T1 Port

    Configuring the T1 Port Configuration Switches for the T1 port are numbered from left to right, 1–8. Table 1. TNE1500-P Provider Configuration Switches Switch Port 1 Speed Frame Type Line Code Line Attenuation Timing NOT USED Table 2. TNE1500-S Subscriber Configuration Switches...
  • Page 6 Ports configured to operate as fractional T1 lines require contiguous timeslots as indicated in the table below. Configuration Switches 1 and 2 on the TNE1500-P work together to provide four timeslot/bandwidth options for the T1 link. The TNE1500-S determines timeslot and bandwidth configurations for the T1 link via communication with its partner T1 provider unit.
  • Page 7 Line Code – Port 1 Only, Switch 4 Line code is the T1 mode of transmission. The two line code options fall within the International Telecommunication Union - Telecommunication Standardization Sector (ITU-T) G.703 Standards for Transmission Facilities: Bipolar with 8 Zero Substitution – Bipolar with 8 Zero Substitution (B8ZS) is used to accommodate the minimum ones density requirement in the North American public network.
  • Page 8: Connect The T1 Line

    Timing – Port 1 Only, Switch 7: TNE1500-P Only Timing refers to the clock source for T1 transmission links. Local – Local clock source refers to timing derived from an oscillator onboard the TNE1500-P. Loop – Loop clock source refers to timing derived from an intermediate device.
  • Page 9: Connect The Ethernet Line

    Connect the Ethernet Line The 10/100 Ethernet Port auto-negotiates speed and duplex mode in accordance with the remote equipment to which it is connected; Ethernet speed and duplex mode configurations cannot be set on the TNE1500. For the best connection results, the remote device (PC, hub, switch, etc.) should be set to auto-negotiate speed and duplex mode as well.
  • Page 10: Led Indicators

    LED Indicators This document describes units manufactured after 14 March 2005. See the prior version of this document for information about units manufactured on or before that date. Whenever the T1 connection loses link or experiences a T1 Alarm, the Ethernet link is automatically be disabled (as indicated by no illumination of the Ethernet 100, Act and Lnk LEDs).
  • Page 11 Table 10. LEDs (2 of 2) STATE 10/100 Solid Green 100 Mbps Ethernet Ethernet Connection Illumination 10/100 Pulsing* Ethernet Amber Connection Solid Amber Illumination 10/100 Solid Green Ethernet connection is Ethernet Connection Illumination * A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more rapid, less constant rate.
  • Page 12: Emi Notices

    EMI Notices United States – EMI Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 13 A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. See installation instructions for details. If the network extender causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required.
  • Page 14: Supplier's Declaration Of Conformity

    Supplier's Declaration of Conformity Place of Issue: Paradyne Corporation 8545 126th Avenue North Largo, FL 33773-1502 Date of Issue: 3/31/2005 Paradyne Corporation, located at the above address, hereby certifies that the following models: TNE1500-X and TNE1520-X (X = P or S) bearing labeling identification number US:AW2DDNANTNE1500 complies with: the Federal Communications Commission's ("FCC") Rules and Regulations 47 CFR Part 68, and the Administrative Council on Terminal Attachments ("ACTA")-adopted technical criteria TIA-968-A,...
  • Page 15: Important Safety Instructions

    Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.
  • Page 16 *TNE1-A2-GN10-10* *TNE1-A2-GN10-10*...
