TNE1520-P and TNE1520-S
T1 Network Extenders Installation Instructions
Document Number TNE1-A2-GN12-20
September 2005
Contents
.................................................................................................. 14

Software and Firmware License Agreement

ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
................................................................................
.........................................................................................
.....................................................................................
..................................................................................
....................................................................................
............................................................................ 10
.............................................................................................. 12
......................................................................... 14
........................................................................ 17
.................................................
......................................
............................................................. 16
1
................................... 16
1
3
3
3
4
5
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TNE1520-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Paradyne TNE1520-P

  • Page 1: Table Of Contents

    TNE1520-P and TNE1520-S T1 Network Extenders Installation Instructions Document Number TNE1-A2-GN12-20 September 2005 Contents Software and Firmware License Agreement Product Documentation Warranty, Sales, Service, and Training Information Package Contents Connecting to Power Configure the T1 Ports Connect the T1 Lines...
  • Page 2 The terms and conditions of this License Agreement (the “Agreement”) will apply to the software and/or firmware (individually or collectively the “Software”) incorporated into the Paradyne product (the “Product”) purchased by you and any derivatives obtained from the Software, including any copy of either. If you have executed a separate written agreement covering the Software supplied to you under this purchase, such separate written agreement shall govern.
  • Page 3: Product Documentation

    7. The rights granted under this Agreement may not be assigned, sublicensed or otherwise transferred by the Licensee to any third party without the prior written consent of Paradyne. 8. This Agreement and the license granted under this Agreement shall be terminated in the event of breach by the Licensee of any provisions of this Agreement.
  • Page 4: Connecting To Power

    Connecting to Power Plug the power supply into the Power Adapter port on the back of the TNE1520 and connect it to your power source. Verify that the Power LED on the front of the TNE1520 is illuminated. Upon start up, the Ethernet link will remain disabled (as indicated by no illumination of the Ethernet 100, Act and Lnk LEDs) until at least one of the two T1 connections has been established.
  • Page 5: Configure The T1 Ports

    Configure the T1 Ports Configuration Switches for both T1 Port 1 and T1 Port 2 are numbered from left to right, 1–8. Table 1. TNE1520-P Provider Configuration Switches Switch Port 1 Speed Frame Type Line Code Line Attenuation Timing NOT USED Table 2.
  • Page 6 T1 lines require contiguous timeslots as indicated in the table below. Port 1 Configuration Switches 1 and 2 on the TNE1520-P work together to provide four timeslot/bandwidth options for the Port 1 T1 link. Port 2 Configuration Switches 1 and 2 on the TNE1520-P provide the timeslot/bandwidth options for the Port 2 T1 link.
  • Page 7 Alternate Mark Inversion – Alternate Mark Inversion (AMI) alternates positive and negative pulses. Port 1 Configuration Switch 4 on the TNE1520-P and the TNE1520-S controls the line code of both T1 links (Port 1 and Port 2); line code for the two links cannot be configured independently.
  • Page 8 Port 1 Configuration Switch #7 controls the timing of both T1 links (Port 1 and Port 2) on the TNE1520-P; timing for the two links cannot be configured independently. The TNE1520-S determines T1 timing via communication with its partner T1 provider unit.
  • Page 9: Connect The T1 Lines

    Single T1 Connection A single line connection can be established between a TNE1520-P and any of Paradyne's T1 subscriber units, regardless of loop bonding capability. Likewise, a single line connection can also be established between an TNE1520-S and any of Paradyne's T1 provider units, regardless of loop bonding capability.
  • Page 10: Connect The Ethernet Line

    Table 8. T1 RJ45 Pinouts Function Pin 1 Rx Ring Pin 2 Rx Tip Pin 3 Not used Pin 4 Tx Ring Pin 5 Tx Tip Pin 6 Not used Pin 7 Not used Pin 8 Not used Connect the Ethernet Line The 10/100 Ethernet Port auto-negotiates speed and duplex mode in accordance with the remote equipment to which it is connected;...
  • Page 11 Table 9. Ethernet Pinouts Function Pin 1 Pin 2 Rx– Pin 3 Pin 4 not used Pin 5 not used Pin 6 Tx– Pin 7 not used Pin 8 not used...
  • Page 12: Led Indicators

    LED Indicators This document describes units manufactured after 13 January 2005. See the prior version of this document for information about units manufactured on or before that date. Whenever both T1 connections lose link or experience a T1 Alarm, the Ethernet link is automatically be disabled (as indicated by no illumination of the Ethernet 100, Act and Lnk LEDs).
  • Page 13 Table 10. LEDs (2 of 2) STATE 10/100 Solid Green 100 Mbps Ethernet Ethernet Connection Illumination 10/100 Pulsing* Ethernet Amber Connection Solid Amber Illumination 10/100 Solid Green Ethernet connection is Ethernet Connection Illumination * A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more rapid, less constant rate.
  • Page 14: Emi Notices

    EMI Notices United States – EMI Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 15 A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. See installation instructions for details. If the network extender causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required.
  • Page 16: Supplier's Declaration Of Conformity

    Supplier's Declaration of Conformity Place of Issue: Paradyne Corporation 8545 126th Avenue North Largo, FL 33773-1502 Date of Issue: 3/31/2005 Paradyne Corporation, located at the above address, hereby certifies that the following models: TNE1500-X and TNE1520-X (X = P or S) bearing labeling identification number US:AW2DDNANTNE1500 complies with: the Federal Communications Commission's ("FCC") Rules and Regulations 47 CFR Part 68, and the Administrative Council on Terminal Attachments ("ACTA")-adopted technical criteria TIA-968-A,...
  • Page 17: Important Safety Instructions

    Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these slots and openings must not be blocked or covered.
  • Page 20 *TNE1-A2-GN12-20* *TNE1-A2-GN12-20*...
