SNE2040 Utilities and SNMP Management
Document Number SNE2-A2-GK41-00
November 2004

Overview

The SNE2040-P (Provider) and SNE2040-S (Subscriber) units support SNMP
management with firmware version 6.0.0 or greater. Paradyne also provides
command line utilities that can be used to configure and upgrade the SNE2040
without SNMP.

Command Line Utilities

Three command line utilities are available on the Paradyne website. (Click on
Support, then Tools.) They are:
The utilities do not have to be used with the SNE2040, but they are available for
use if an SNMP management tool is not available.
The following are requirements for using the utilities:
To run the utilities:
Procedure
SNE2-A2-GK41-00
pdynips.exe – Sets the IP address, subnet mask, and default gateway for an
SNE2040.
pdynncl.exe – Clears NVRAM (Non-Volatile Random Access Memory),
returning the SNE2040 to factory default settings.
pdynidl.exe – Replaces firmware on the SNE2040.
Your PC must be plugged directly to the Ethernet port of the SNE2040.
Your PC must be running Windows 2000 or Windows XP.
1. Close all other programs that are running on your PC.
2. Open a Command Prompt window:
— Click on Start, then Run.
— Type cmd in the Open: line and click on OK. A command prompt window
opens.
3. Type a command name and parameters and press Enter.
November 2004
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SNE2040G-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paradyne SNE2040G-P

Summary of Contents for Paradyne SNE2040G-P

  • Page 1 SNE2040 Utilities and SNMP Management Document Number SNE2-A2-GK41-00 November 2004 Overview The SNE2040-P (Provider) and SNE2040-S (Subscriber) units support SNMP management with firmware version 6.0.0 or greater. Paradyne also provides command line utilities that can be used to configure and upgrade the SNE2040 without SNMP.
  • Page 2 pdynips Format: pdynips.exe <IP Address> <Mask> <Gateway> Example: pdynips.exe 10.11.22.100 255.255.255.0 10.11.22.1 The program sets the IP Address, subnet mask, and the default gateway of the SNE2040. The SNE2040 will acknowledge the change if it is successful. pdynncl Format: pdynncl.exe nvram clear Example: pdynncl.exe nvram clear This program clears NVRAM on the SNE2040.
  • Page 3 SNMP Management Once you have IP access to the SNE2040 units you can use SNMP to manage the units. You must download the latest Paradyne MIBs to your SNMP platform before you can fully access the SNE2040 units. There are specific MIBs written for the SNE2040 that need to be compiled into your browser.
  • Page 4 2. Open a command prompt window (cmd.exe). 3. Type: ARP -s 192.168.254.250 xx-xx-xx-xx-xx-xx where the IP address is the default address of the SNE2040-P and xx-xx-xx-xx-xx-xx is the MAC address you obtained from the label on the bottom of the unit. Note: If you are working on more than one SNE2040, you must to change the static ARP table entry before you can contact each unit.
