ENE2000-P and ENE2000-S
E1 Network Extenders Installation Instructions
Document Number ENE2-A2-GN12-10
September 2005
Contents
.................................................................................................. 12
Software and Firmware License Agreement
ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS
TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED
INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU
SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS
LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS
ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE
LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE
LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU
WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT
PURCHASED BY YOU.
The terms and conditions of this License Agreement (the "Agreement") will apply to the
software and/or firmware (individually or collectively the "Software") incorporated into
the Paradyne product (the "Product") purchased by you and any derivatives obtained
................................................................................
.........................................................................................
...........................................................................
................................................................................
................................................................................
.......................................................................
..............................................................................................
.................................................................................. 11
........................................................................ 13
.................................................
......................................
1
1
3
3
3
4
5
8
8
9
Advertisement
Table of Contents
Related Manuals for Paradyne ENE2000-P
Summary of Contents for Paradyne ENE2000-P
-
Page 1: Table Of Contents
ENE2000-P and ENE2000-S E1 Network Extenders Installation Instructions Document Number ENE2-A2-GN12-10 September 2005 Contents Software and Firmware License Agreement Product Documentation Warranty, Sales, Service, and Training Information Package Contents Powering Up the ENE2000 Configuring the E1 Port Connecting the E1 Line... - Page 2 from the Software, including any copy of either. If you have executed a separate written agreement covering the Software supplied to you under this purchase, such separate written agreement shall govern. Paradyne Corporation (“Paradyne”) grants to you, and you (“Licensee”) agree to accept a personal, non-transferable, non-exclusive, right (without the right to sublicense) to use the Software, solely as it is intended and solely as incorporated in the Product purchased from Paradyne or its authorized distributor or reseller under the following...
-
Page 3: Product Documentation
8. This Agreement and the license granted under this Agreement shall be terminated in the event of breach by the Licensee of any provisions of this Agreement. 9. Upon such termination, the Licensee shall refrain from any further use of the Software and destroy the original and all copies of the Software in the possession of Licensee together with all documentation and related materials. -
Page 4: Powering Up The Ene2000
Powering Up the ENE2000 Plug the power supply into the power adapter port on the back of the ENE2000 and connect it to your power source. Verify that the Power LED on the front of the ENE2000 is illuminated. NOTE: Upon start up, the Ethernet link will remain disabled (as indicated by no illumination of the Ethernet 100, Act and Lnk LEDs) until the E1 connection has been established. -
Page 5: Configuring The E1 Port
Configuring the E1 Port Configuration Switches are numbered from left to right, 1–8. Table 1. Configuration Switch Settings ENE2000-P Provider Configuration Switches Switch Port 1 Speed Frame Type Line Code Not used Not used Timing Not used ENE2000-S Subscriber Configuration Switches Port 1 Not used. - Page 6 Down Down Frame Type Switch 3 sets the Frame Type for the E1 port on both the ENE2000-P and the ENE2000-S. Frame type is the E1 data encapsulation method. A frame consists of 248 bits (8-bit samples of each of the 31 E1 data channels plus a synchronization bit) transmitted at a rate of 8,000 frames per second (1,984 kbps) across the E1 line.
- Page 7 Line Code Switch 4 sets the Line Code for the E1 port on both the ENE2000-P and the ENE2000-S. Line code is the E1 mode of transmission. The two line code options outlined below fall within the International Telecommunication Union - Telecommunication Standardization Sector (ITU-T) G.703 Standards for Transmission Facilities.
-
Page 8: Connecting The E1 Line
Connecting the E1 Line To connect the E1 line: Procedure 1. Plug the E1 cable into the E1 RJ45 port on the back of the ENE2000. 2. Verify the connection: the E1 link LED on the front of the ENE2000 will pulse green to indicate the connection is established and operational. -
Page 9: Led Indicators
LED Indicators This document describes units manufactured after 14 March 2005. See the prior version of this document for information about units manufactured on or before that date. Whenever the E1 connection has lost link or has presented an E1 Alarm, the Ethernet link will automatically be disabled (as indicated by no illumination of the Ethernet 100, Act and Lnk LEDs). - Page 10 Table 6. LEDs (2 of 2) State 10/100 Solid Ethernet Green Connection Illumination 10/100 Pulsing* Ethernet Amber Connection Solid Amber Illumination 10/100 Solid Ethernet Green Connection Illumination * A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more rapid, less constant rate.
-
Page 11: Rj45 Pin Assignments
RJ45 Pin Assignments E1 RJ45 Pin Assignments If you are using a shielded E1 cable for your network connection, it must be grounded through pins 3, 6, 7 and 8. Table 7. E1 RJ45 Pin Assignments Function Pin 1 Rx Ring Pin 2 Rx Tip Pin 3... -
Page 12: Emi Notices
EMI Notices United States – EMI Notice: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 13: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Do not allow anything to rest on the power cord and do not locate the product where persons will walk on the power cord. 3. - Page 16 *ENE2-A2-GN12-10* *ENE2-A2-GN12-10*...
