6.2.4 Storing preferred frequencies
in your own frequency groups
It is possible to store up to 64 preferred frequencies
in your own six frequency groups.
1) Call up the following menu via the menu item
User Group
of the main menu:
1. Custom Group
2. Clear Group
3. Return
2) The first menu item is selected. Press the knob
PUSH / CONTROL to call up the following setup
menu:
Setup User Group
G:U1
CH:1
---.--- MHz
3) The group number is selected. Turn the knob
PUSH / CONTROL to select the group where the
frequency is to be stored.
4) Press the knob PUSH / CONTROL so that the
channel number is selected. Turn the knob to
select the channel number where the frequency
is to be stored.
5) Press the knob once again so that the digits
before the decimal point are selected. Turn the
knob to set the transmission frequency in steps
of 1 MHz.
6) For fine adjustment in steps of 0.025 MHz,
press the knob once again so that the digits
after the decimal point are highlighted. Then
turn the knob.
7) Press the button SETUP to store the frequency
selected.
8) To store further frequencies, repeat steps 2 – 7.
9) To exit all menus, press the button EXIT three
times.
Calling up a channel from one of your own
frequency groups
The channels from your own frequency groups are
called up via the menu item
see chapter 6.2.2. Your own frequency groups are
U
marked with a
before the group number. If you
turn the knob PUSH / CONTROL clockwise, they
will appear after group 12; if you turn it counter-
clockwise, they will appear before group 1.
Fig. 14
Fig. 15
Group/Channel
,
Deleting one of your own groups
1) Call up the following menu via the menu item
User Group
of the main menu:
1. Custom Group
2. Clear Group
3. Return
2) Turn the knob PUSH / CONTROL to select the
second menu item
the knob.
Group:
U1
Rotary to select
Push "Enter" to clear
Push "Exit" to return
3) Turn the knob to select the group to be deleted.
4) Press the knob. The following confirmation
prompt appears:
Group "U..." will be cleared
continue ?
Yes
5) To exit, press the knob or the button EXIT. To
delete the group, turn the knob so that
selected. Then press the knob.
6) To delete further groups, repeat steps 3 – 5; to
exit all menus, press the button EXIT three
times.
6.2.5 REMOSET
®
function
Setting the transmitter
to the same frequency
If the transmission frequency or the group and the
transmission channel have been set on the receiver,
simply press a button to activate the patented
REMOSET function which will synchronize the set-
tings of the transmitter and of the receiver. For the
REMOSET function, always make sure that:
1. no menu is called up on the receiver or on the
transmitter.
2. the transmitter is switched on and close to the
receiver (REMOSET transmission range: ap -
prox. 10 m).
3. the REMOSET function is not locked on the
transmitter (
instruction manual of the trans-
mitter).
4. the transmitter and the receiver are set to the
same identification number.
5. the receiver and the transmitter are not locked.
6. the transmitter is not muted.
Fig. 16
Clear Group
. Then press
Fig. 17
No
Fig. 18
Yes
is
17
