Technical specification
Environmental conditions
Environment class 3K2, DIN IEC 721
Rated range of operation
Humidity
Limit range of operation
Humidity

VESA-DDC-compatible VGA interface

Your monitor is equipped with a VESA-DDC-compatible VGA interface. VESA-DDC (Video
Electronics Standard Association, Display Data Channel) is used as the communications
interface between the monitor and the computer. If the computer is equipped with a
VESA-DDC-compatible VGA interface, it can automatically read the data for ensuring
optimum operation from the monitor and select the appropriate settings.

Preset operating modes

The picture position and size have been set to optimum values at the factory for the
operating modes listed above. Depending on the display adapter used, it may be
necessary to adjust the display position or size. In this case, you can change and
save the settings (see chapter
For ergonomic reasons, a screen resolution of 2560 x 1440 pixels is recommended.
Because of the technology used (active matrix), an LCD monitor provides a
totally flicker-free picture, even with a refresh rate of 60 Hz.

Most frequent operating modes

Horizontal frequency
31.5 kHz
31.5 kHz
37.5 kHz
37.9 kHz
46.9 kHz
48.4 kHz
55.4 kHz
60.0 kHz
64.0 kHz
65.0 kHz
74.0 kHz
80.0 kHz
88.7 kHz
32
15 °C .... 35 °C
20 % .... 85 %
5 °C .... 35 °C
20 % .... 85 %
"Changing the monitor settings", Page
Refresh rate
70 Hz
60 Hz
75 Hz
60 Hz
75 Hz
60 Hz
60 Hz
75 Hz
60 Hz
60 Hz
60 Hz
75 Hz
60 Hz
20).
Screen resolution
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1440 x 900
1024 x 768
1280 x 1024
1680 x 1050
1920 x 1200
(only VGA, DVI, DP)
1280 x 1024
2560 x 1440 (only DVI, DP)
