Summary of Contents for Magmaweld MONOSTICK 200 PFC
- Page 1 MONOSTICK 200 PFC İ www.oerlikon.com.tr...
-
Page 2: Table Of Contents
İÇİNDEKİLER SAFETY RULES ............................... 2 1. TECHNICAL INFORMATION .........................6 1.1 GENERAL EXPLANATIONS ........................6 1.2 COMPONENTS OF THE MACHINE ....................6 1.3 DATA PLATE ............................7 1.4 TECHNICAL SPECIFICATIONS .......................7 1.5 ACCESSORRIES .............................7 2. INSTALLATION AND OPERATION ........................8 2.1 UPON RECEIPT AND CLAIMS ........................8 2.2 INSTALLING AND WORKING RECOMMENDATIONS ................8... -
Page 3: Safety Rules
SAFETY RULES OBEY ALL THE SAFETY RULES STATED IN THE MANUAL! IDENTIFYING SAFETY INFORMATION These symbols are being used to identify potential risks. Ÿ When seen a safety symbol in the manual, it must be understood that there is an injury risk and following Ÿ... - Page 4 SAFETY RULES BREATHING WELDING FUMES CAN BE HAZARDOUS TO YOUR HEALTH Inhaling fumes and gases over a long period of time, generated during welding is dangerous and forbidden . Irritation of the eyes, nose and throat are symptoms of inadequate ventilation. Take Ÿ...
- Page 5 SAFETY RULES NOISE CAN DAMAGE HEARING Noise from certain industrial processes or equipments can damage hearing. Ÿ Wear approved ear protection if noise level is high. Ÿ WORKING IN SMALL AND CONFINED PLACES CAN BE DANGEROUS While welding and cutting in small, confined places, always have a trained watchperson nearby Ÿ...
- Page 6 SAFETY RULES FALLING UNIT CAN CAUSE INJURY Wrong positioned power source or other equipment may cause serious injury to persons or damage to objects. While repositioning the power source always carry by using the lifting eye. Never pull cable, hose or torch. Ÿ...
-
Page 7: Technical Information
TECHNICAL INFORMATION 1. TECHNICAL INFORMATION 1.1 GENERAL EXPLANATIONS Monostick 200 PFC is an inverter type portable, mono-phase DC MMA welding machine designed to weld stick electrodes up to 4 mm. Even though the machine is mono-phase, due to the inverter technology it provides stable arc and good re-striking performance . -
Page 8: Data Plate
TECHNICAL INFORMATION 1.3 DATA PLATE Single Phase Static Frequency Converter Transformer Rectifier Manual Metal Arc Welding MONOSTICK 200i PFC Direct Current EN 60974-1 / EN 60974-10 Descending Characteristics 30A / 21.2V 200A / 28V 100% Line Input-1 Phase Alternating Current 200A 115A Appropriate To Operate In Dangerous Work Area... -
Page 9: Installation And Operation
INSTALLATION AND OPERATION 2. INSTALLATION 2.1 UPON RECEIPT AND CLAIMS Be sure that you have received all the items that Standard box contains: Ÿ Ÿ you have ordered. In case of any item is missing or Power Source ú damaged, contact your supplier immediately. Electrode older Cable ú... -
Page 10: Connections For Tig Welding
INSTALLATION AND OPERATION 2.4 CONNECTIONS FOR TIG WELDING Install the Argon gas regulator onto the Argon gas Ÿ Before plugging your machine to the cylinder. electrical line, check if the correct gas hose of the torch onnect the Ÿ voltage exists. regulator Adjust the desired current and the machine is Ÿ... -
Page 11: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING 3. MAINTENANCE AND TROUBLESHOOTING Strictly follow the instructions contained in safety rules while servicing the machine. Before removing any screw on the machine for maintenance, power supply must be disconnected from the electric lines and enough time should be allowed for capacitor discharging. -
Page 12: Appendix 1
APPENDIX 1 SPARE PARTS LIST DESIGNATION IN ELECTRICAL DIAGRAM MATERIAL CODE Electronic Card - Control Monostick 200i PFC - CNT K405000146 Electronic Card - Filter E203A-FLT K4050001 Electronic Card - E203A-PFC K405000143 Electronic Card - Power Monostick 200i PFC - PWR K40500014 Knob A229500001... -
Page 13: Appendix 2 Electrical Diagram
APPENDIX 2 ELECTRICAL DIAGRAM MONOSTICK 200i PFC... - Page 14 FACTORY Organize Sanayi Bölgesi 5.Kısım Yalçın Özaras Caddesi No:1 45030 MANİSA +90 236 226 27 00 +90 236 226 27 28 OWM 06.24.2013 Made in TÜRKİYE www.magmaweld.com...
