Summary of Contents for Magmaweld Monostick 160i
-
Page 2: Table Of Contents
CONTENTS SAFETY RULES ............................... 2 1. TECHNICAL INFORMATION .........................6 1.1 GENERAL EXPLANATIONS ........................6 1.2 COMPONENTS OF MONOSTICK 160i ....................6 1.3 DATA PLATE ............................7 1.4 TECHNICAL SPECIFICATIONS .......................7 1.5 ACCESSORRIES .............................7 2. INSTALLATION AND OPERATION ........................8 2.1 UPON RECEIPT AND CLAIMS ........................8... -
Page 3: Safety Rules
Ÿ HOT PARTS CAN CAUSE SEVERE BURNS Do not touch hot parts Ÿ Allow cooling time before servicing Ÿ If needed to hold hot parts, use appropriate tool, insulating gloves and fireproof clothes. Ÿ MONOSTICK 160i... - Page 4 To prevent injuries wear appropriate safety glasses with side shields even under your welding helmet . Ÿ MOVING PARTS CAN CAUSE INJURY Keep away from moving parts Ÿ Keep all doors, panels, and guards closed and secured Ÿ Wear shoes with metal protection over the fingers. Ÿ MONOSTICK 160i...
- Page 5 Electrical devices should not be repaired by unqualified persons. Improper repairs can cause serious Ÿ injuries or even death during applications The components of the gas circuit works under pressure. The service given by unqualified persons may Ÿ cause explosions and operators can be injured seriously MONOSTICK 160i...
- Page 6 Choose appropriate welding method and welding machine for your work. Ÿ Choose appropriate welding current and welding voltage for the material and its thickness. Ÿ If you will have a long break after welding, turn off the machine after cooler fan cooled the machine. Ÿ MONOSTICK 160i...
-
Page 7: Technical Information
25% less than the magnetically controlled equipments. Monostick 160i proved well that it can work between 160 to 240 V 50/60 Hz line voltages. Therefore this machine is quite immune to mains voltage fluctuations and perfectly welds with generator-sets. -
Page 8: Data Plate
Cooling Method Dimensions L W H ( x x ) 160x312x405 Weight Standarts and Approvals CE, EN60974-1, EN60974-10 1.5 ACCESORRIES STANDARD ACCESORRIES PIECE PRODUCT CODE Electrode Holder and Cable (200A) A390000200 Earth Clamp and Cable (16mm² - 3mt) K301100203 MONOSTICK 160i... -
Page 9: Installation And Operation
SWITCH ON the machine via power switch Ÿ check if power LED lights up and cooler fan works. Diameter Rutile Basic Cellulosic 40-60 A 60-90 A 60-90 A 60-100 A 3.25 100-140 A 100-130 A 70-130 A 140-180 A 140-180 A 120-170 A MONOSTICK 160i... -
Page 10: Connections For Tig Welding
6 - 8 Install the Argon gas regulator onto the Argon gas Ÿ cylinder. gas hose of the torch onnect the Ÿ regulator Adjust the desired current and the machine is Ÿ ready to weld. Figure 2: TIG Welding Connections MONOSTICK 160i... -
Page 11: Maintenance And Troubleshooting
Ÿ for 1 minute then turn it on again and try to weld. If it still doesn't weld, contact to your authorized technical service. MONOSTICK 160i... -
Page 12: Appendix 1
Electronic Card E201B-02 K405000103 Underside Electronic Card E201B-01 K405000102 Current Adjustment Potentiometer Current 1K A410801001 A250200006 Filter Card E201B-FLT K405000101 Power LED - Green LED-Green Power A430801001 Thermic / Error LED - Red LED-Red TH-Err A430801002 Power Switch A310100008 MONOSTICK 160i... -
Page 13: Appendix 2 Electrical Diagram
APPENDIX 2 ELECTRICAL DIAGRAM MONOSTICK 160i... - Page 14 Organize Sanayi Bölgesi 5.Kısım 5503. Sokak No:1 MANİSA +90 236 226 27 00 +90 236 226 27 28 OWM 06.21.2011 Made in TÜRKİYE www.magmaweld.com...
