WIPER AND WASHER SYSTEM

2. Wiper and Washer System
A: WIRING DIAGRAM
1. WIPER AND WASHER (FRONT)
<Ref. to WI-264, WIRING DIAGRAM, Wiper and Washer System (Front).>
2. WIPER AND WASHER (REAR)
<Ref. to WI-265, WIRING DIAGRAM, Wiper and Washer System (Rear).>
B: INSPECTION
Wiper and washers do not operate.
Wipers do not operate in LO or HI.
Wipers do not operate in INT.
Washer motor does not operate.
Wipers do not operate when washer switch is ON.
Washer fluid spray does not operate.
Wiper and Washer System
Symptom
(1) Wiper fuse (F/B No. 14, 15)
(2) Combination switch
(3) Wiper motor
(4) Wiring harness
(1) Combination switch
(2) Wiper motor
(3) Wiring harness
(1) Combination switch
(2) Wiper motor
(3) Wiring harness
(1) Washer switch
(2) Washer motor
(3) Wiring harness
(1) Washer motor
(2) Wiring harness
(1) Washer motor
(2) Washer hose and nozzle
WW-6
Repair order
