Rear Wiper Arm - Subaru Forester Service Manual

WIPER AND WASHER SYSTEM

9. Rear Wiper Arm

A: REMOVAL
1) Remove the wiper arm cover (A).
2) Loosen the nut to remove wiper arm.
B: INSTALLATION
1) Install in the reverse order of removal.
2) Operate the rear wiper once.
3) Align the blade to the center of rear defogger
heat wire (A).
Tightening torque:
Refer to COMPONENT in General Descrip-
tion.
<Ref. to WW-3, REAR WIPER, COMPONENT,
General Description.>
Rear Wiper Arm
C: ADJUSTMENT
1) Operate the rear wiper once.
2) Align the blade to the center of rear defogger
heat wire (A).
WW-00191
WW-00192
WW-00200
WW-16
WW-00200
