- Page 1 2011 Consumer Electronics/ Bluetooth & Audio Technology ®...
- Page 4 Table of Contents Bluetooth Basics 2 - 3 Bluetooth without 4 - 7 Navigation System Bluetooth with Harmon Kardon Audio System 8 - 11 BlueConnect ® 12 - 13 Bluetooth with Navigation System 14 - 21 Media Hub 22 -24...
-
Page 5: Bluetooth Basics
Bluetooth Basics • The Hands-free system may not operate properly under the following conditions: o The cell phone is turned off. o The cell phone is not connected to the Hands-free system. o The cell phone is not in the phone call area. o The battery of the cell phone has run down. - Page 6 • Do not speak at the same time as the other party during a call. If you and the other party speak at the same time, it may be difficult for the other party to hear your voice and vice versa. This is normal. •...
- Page 7 Bluetooth without Navigation System (Impreza) Phone off Phone on Talk button hook button hook button Pairing Your Cell Phone Press the phone off hook button and listen to phone prompts. Press the talk button and name your phone.
- Page 8 Press the talk button and say “confirm.” Pass-key will be given audibly as well as be displayed on the radio display. Put your phone into Bluetooth pairing mode and pair your phone to the system using the pass-key provided. When phone is successfully paired you will hear “The phone is paired and ready for use.”...
-
Page 9: Making A Call
Making a Call Press phone off hook button. Press the talk button then say “Dial by number.” Press the talk button again and say the number. -
Page 10: Receiving A Call
Press the off hook button to dial or press the talk button to add more numbers. The phone will start dialing. To end the call, press the phone on hook button. Receiving a Call When a call comes in you will be notified. The audio system will mute and a voice prompt will inform you. -
Page 11: Bluetooth With Harmon Kardon
Bluetooth with Harmon Kardon Audio System (Legacy and Outback) Phone off Phone on Talk button hook button hook button Pairing Your Cell Phone Press the phone off hook button and listen to phone prompts. Press the talk button and name your phone. - Page 12 Press the talk button and say “confirm.” Pass-key will be given audibly as well as be displayed on the radio display. Put your phone into Bluetooth pairing mode and pair your phone to the system using the pass-key provided. When phone is successfully paired you will hear “The phone is paired and ready for use.”...
- Page 13 Making a Call Press phone off hook button. Press the talk button then say “Dial by number.” Press the talk button again and say the number.
- Page 14 The system will audibly repeat the number. If correct, press the off hook button to dial, or press the talk button to change, cancel or delete the number. The phone will start dialing. To end the call, press the phone on hook button. Receiving a Call When a call comes in you will be notified.
- Page 15 BlueConnect ® (Genuine Subaru accessory, standard on Tribeca 3.6R Limited and Touring models) Controls Location BlueConnect controls for the Legacy, Outback, Forester and Impreza are located in the center stack (Legacy shown). BlueConnect controls for the Tribeca are located in the overhead console.
- Page 16 Pairing Your Cell Phone • Press the phone button, the blue L.E.D. will glow and “Call” will be displayed. Listen to all options. • Say “setup”; then listen to all options. • Say “pairing options”; then listen to all options. •...
- Page 17 Bluetooth with Navigation System (Forester and Impreza) Microphone located in overhead console MENU button Pairing Your Cell Phone Press the MENU button; then touch the “Phone” soft key on the touch screen. Then touch “Bluetooth Settings.”...
- Page 18 Now touch “Register.” A pass-key number will appear on the screen. Put your phone into Bluetooth pairing mode and pair your phone to the system using the pass-key provided. When the phone is successfully paired the screen will show the phone’s name on the list.
- Page 19 Making a Call Press the MENU button; then touch the “Phone” soft key on the touch screen. Then touch “Bluetooth Phone”; a numeric keypad will be displayed. Touch the numbers for the phone number you wish to call. When complete, touch the green phone soft key.
- Page 20 A confirmation screen will appear, touch “Yes” to make the call. During a Call Mute – Touch this to mute the call. Speaker – Touch this to switch the phone conversation back to your cell phone. Red phone symbol – Touch this to end a call.
- Page 21 Bluetooth with Navigation System (Legacy and Outback) Microphone located next to the audio system MENU button Phone off Phone on Talk button hook button hook button...
- Page 22 Pairing Your Cell Phone Press the MENU button; then touch the “Phone” soft key on the touch screen. Then touch “Bluetooth Settings.” Now touch “Register.” A pass-key number will appear on the screen.
- Page 23 Put your phone into Bluetooth pairing mode and pair your phone to the system using the pass-key provided. When the phone is successfully paired the screen will show the phone’s name on the list. Making a Call Press the Talk button on the steering wheel; then say “Dial by number.” A numerical keypad will be displayed.
- Page 24 During a Call Mute – Touch this to mute the call. Speaker – Touch this to switch the phone conversation back to your cell phone. Red phone symbol – Touch this to end a call. 1 – 5 – Touch 1 through 5 to change the volume of the call.
-
Page 25: Media Hub
3. Activate the Bluetooth on the device. 4. Use the search for new device function on the device until the Media hub (“SUBARU”) is found. 5. Initiate pairing by the phone or device. 6. Enter the pas-key. -
Page 26: Ipod Operation
Accessing the Media Hub To access an item connected to the Media hub press the SAT button located on the audio system repeatedly until the correct Media hub mode is selected. iPod Operation Text Display Press the TEXT button located on the audio system repeatedly to cycle through the available text fields: •... -
Page 27: Usb Device Operation
USB Device Operation Text Display Press the TEXT button located on the audio system repeatedly to cycle through the available text fields: • TITLE – Song title • NAME – Artist - Album • CATEGORY – Displays the information related to the selected mode •... - Page 28 Quick Reference Guide was accurate at the time of publication. We reserve the right to change features, operation and/or functionality of any vehicle specification at any time. Your Subaru dealer is the best source for the most current information. For detailed operating and safety information, please consult your Owner’s Manual.
