Page 1 This manual describes the following vehicle types.* * The illustrated vehicle is one of the FORESTER series.
Page 3: Seat, Seatbelt And Srs Airbags
Warranties & Warranties for U.S.A. All SUBARU vehicles distributed by Subaru of America, Inc. and sold at retail by an authorized SUBARU dealer in the United States come with the following warranties: . SUBARU Limited Warranty . Emission Control Systems Warranty .
Page 4: Climate Control
This chapter informs you how to keep your SUBARU looking good. Chapter 11: Maintenance and service This chapter informs you when you need to take your SUBARU to the dealer for scheduled maintenance and informs you how to keep your SUBARU running properly.
Page 5: Vehicle Symbols
Vehicle symbols There are some of the symbols you may see on your vehicle. For warning and indicator lights, refer to “Warning and indicator lights” F18. Mark Name WARNING CAUTION Power door lock and unlock Passengers’ windows lock and unlock Fuel Front fog lights Hazard warning flasher...
Page 6 Mark Name Air recirculation Engine oil Washer Door lock (Transmitter) Door unlock (Transmitter) Rear gate (Transmitter) Safety precautions when driving & Seatbelt and SRS airbag WARNING . All persons in the vehicle should fasten their seatbelts BEFORE the vehicle starts to move. Other- wise, the possibility of serious injury becomes greater in the event of a sudden stop or acci-...
Page 7: Child Safety
& Child safety WARNING . Never hold a child on your lap or in your arms while the vehicle is moving. The passenger cannot protect the child from injury in a collision, because the child will be caught between the passen- ger and objects inside the vehi- cle.
Page 8: Drinking And Driving
gine exhaust system to prevent engine exhaust gas from enter- ing the vehicle. . Never run the engine in a closed space, such as a garage, except for the brief time needed to drive the vehicle in or out of it. .
Page 9: Driving With Pets
When possible, you should share the driving with others. & Modification of your vehicle CAUTION Your vehicle should not be modified other than with genuine SUBARU parts and accessories. Other types of modifications could affect its performance, safety or durability, and may even violate governmental regulations.
Page 10: Tire Pressures
& Tire pressures Check and, if necessary, adjust the pressure of each tire (including the spare) at least once a month and before any long journey. Check the tire pressure when the tires are cold. Use a pressure gauge to adjust the tire pressures to the values shown on the tire placard.
Page 11: Table Of Contents
Table of contents Seat, seatbelt and SRS airbags Keys and doors Instruments and controls Climate control Audio Interior equipment Starting and operating Driving tips In case of emergency Appearance care Maintenance and service Specifications Consumer information and Reporting safety defects Index...
Page 12 Illustrated index & Exterior Engine hood (page 11-5) Headlight switch (page 3-26) Replacing bulbs (page 11-47) Wiper switch (page 3-30) Moonroof (page 2-23) Roof rail (page 8-13) Door locks (page 2-4) Tire pressure (page 11-33) Flat tires (page 9-6) 10) Tire chains (page 8-11) 11) Front fog light switch (page 3-28) 12) Tie-down hooks (page 9-12) 13) Towing hook (page 9-12)
Page 13 Rear window defogger button (page 3-35) Fuel filler lid and cap (page 7-4) Child safety locks (page 2-19) Tie-down hook (page 9-13) Rear gate (page 2-22) Towing hook (page 9-13) – CONTINUED –...
Page 14 & Interior ! Passenger compartment area Lower anchorages for child restraint system (page 1-30) Seatbelt (page 1-11) Parking brake lever (page 7-33) Front seat (page 1-2) Rear seat (page 1-7)
Page 15 Center console (page 6-5) Cup holder (page 6-8) Front power supply socket (page 6-9) Glove box (page 6-5) – CONTINUED –...
Page 16 & Instrument panel Door locks (page 2-4) Outside mirror switch (page 3-34) Illumination brightness control (page 3-28) Light control lever (page 3-25) Combination meter (page 3-5) Wiper control lever (page 3-29) Hazard warning flasher switch (page 3-5) Audio (page 5-1) Shift lever (MT) (page 7-15)/ Selector lever (AT) (page 7-16) 10) Climate control (page 4-1)
Page 17 & Light control and wiper control levers/switches Windshield wiper (page 3-30) Mist (page 3-31) Windshield washer (page 3-31) Rear window wiper and washer switch (page 3-32) Wiper intermittent time control switch (page 3-31) Wiper control lever (page 3-29) Light control switch (page 3-25) Fog light switch (page 3-28) Headlight ON/OFF (page 3-26) 10) Headlight flasher High/Low beam...
Page 18 & Combination meter ! U.S.-spec. models Tachometer (page 3-8) Speedometer (page 3-6) Fuel gauge (page 3-8) Trip meter A/B selection and trip meter reset knob (page 3-6) Odometer/Trip meter (page 3-6) Selector lever and gear position indicator (AT models) (page 3-21) Coolant temperature low indicator light/ Coolant temperature high warning light (page 3-13)
Page 19 ! Except U.S.-spec. models Tachometer (page 3-8) Speedometer (page 3-6) Fuel gauge (page 3-8) Trip meter A/B selection and trip meter reset knob (page 3-6) Odometer/Trip meter (page 3-6) Selector lever and gear position indicator (AT models) (page 3-21) Coolant temperature low indicator light/ Coolant temperature high warning light (page 3-13) –...
Page 20 & Warning and indicator lights Mark Name Page Seatbelt warning light 3-10 Front passenger’s seat- 3-10 belt warning light SRS airbag system 3-11 warning light Front passenger’s fron- 3-12 tal airbag ON indicator Front passenger’s fron- 3-12 tal airbag OFF indicator CHECK ENGINE warning light/Malfunction 3-12...
Page 21 Function settings A SUBARU dealer can change the settings of the functions shown in the following table to meet your personal requirements. Contact the nearest SUBARU dealer for details. If your vehicle is equipped with the genuine SUBARU navigation system, the settings for some of these functions can be changed using the navigation monitor.
Page 22 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 23 1-11 Vehicles with SRS airbags and lap/shoulder 1-12 restraints for driver, front passenger, and window-side rear passengers... 1-12 SUBARU advanced frontal airbag system ... 1-12 SRS side airbag and SRS curtain airbag... 1-14 SRS airbag system monitors... 1-20 SRS airbag system servicing ...
Page 24: Front Seats
Seat, seatbelt and SRS airbags Front seats WARNING . Never adjust the seat while driv- ing to avoid the possibility of loss of vehicle control and of personal injury. . Before adjusting the seat, make sure the hands and feet of rear seat passengers and cargo are clear of the adjusting mechan- ism.
Page 25: Manual Seat
tions concerning child restraint sys- tems, refer to “Child restraint sys- tems” F1-23. & Manual seat ! Forward and backward adjustment Pull the lever upward and slide the seat to the desired position. Then release the lever and move the seat back and forth to make sure that it is securely locked into place.
Page 26: Power Seat (Driver's Seat - If Equipped)
Seat, seatbelt and SRS airbags ! Seat cushion height adjustment (driver’s seat) When the lever is pushed down, the seat is lowered. When the lever is pulled up, the seat rises. The height of the seat can be adjusted by moving the seat cushion adjustment lever up and down.
Page 27: Head Restraint Adjustment
WARNING To prevent the passenger from slid- ing under the seatbelt in the event of a collision, always put the seatback in the upright position while the vehicle is in motion. Also, do not place objects such as cushions between the passenger and the seatback.
Page 28: Seat Heater (If Equipped)
Seat, seatbelt and SRS airbags . If your vehicle is involved in a rear-end collision, have an authorized SUBARU dealer in- spect the active head restraints. . The active head restraints may not operate in the event the vehicle experiences only a slight impact in the rear.
Page 29: Rear Seats
Rear seats WARNING Seatbelts provide maximum re- straint when the occupant sits well back and upright in the seat. Do not put cushions or any other materials between occupants and seatbacks or seat cushions. If you do so, the risk of sliding under the lap belt and of the lap belt sliding up over the abdomen will increase, and both can result in serious internal injury or...
Page 30: Head Restraint Adjustment
Seat, seatbelt and SRS airbags & Head restraint adjustment WARNING Never drive the vehicle with the head restraints removed because they are designed to reduce the risk of serious neck injury in the event that the vehicle is struck from the rear.
Page 31: Reclining The Seatback (If Equipped)
To raise the head restraint, pull it up while pressing the release button on the top of the seatback. To lower it, push the head restraint down while pressing the release button. When the rear-center seating position is occupied, raise the head restraint to an appropriate position depending on your sitting height.
Page 32: Folding Down The Rear Seatback
1-10 Seat, seatbelt and SRS airbags Then release the switch and make sure the seatback is securely locked into place. & Folding down the rear seat- back WARNING . After returning the rear seatback to its original position, be certain to place all of the seatbelts and the tab attached to the seat cushion above the seat cushion.
Page 33: Seatbelts
Seatbelts & Seatbelt safety tips WARNING . All persons in the vehicle should fasten their seatbelts BEFORE the vehicle starts to move. Other- wise, the possibility of serious injury becomes greater in the event of a sudden stop or acci- dent.
Page 34: Emergency Locking Retractor (Elr)
1-12 Seat, seatbelt and SRS airbags tions only) and then if necessary move the child closer to the belt buckle to help provide a good shoulder belt fit. Care must be taken to securely place the lap belt as low as possible on the hips and not on the child’s waist.
Page 35 For further details about canceling the warning operation, please contact your SUBARU dealer. If there is no passenger on the front passenger’s seat, the seatbelt warning device for the front passenger’s seat will be deactivated.
Page 36: Fastening The Seatbelt
If the seatbelt warning device for front passenger’s seat still does not function correctly after taking relevant corrective actions described above, immediately contact your SUBARU dealer for an inspection. & Fastening the seatbelt WARNING . Never use a belt that is twisted or reversed.
Page 37 CAUTION Metallic parts of the seatbelt can become very hot in a vehicle that has been closed up in sunny weath- er; they could burn an occupant. Do not touch such hot parts until they cool. ! Front seatbelts 1. Adjust the seat position according to the following procedure.
Page 38 1-16 Seat, seatbelt and SRS airbags WARNING When wearing the seatbelts, make sure the shoulder portion of the webbing does not pass over your neck. If it does, adjust the seatbelt anchor to a lower position. Placing the shoulder belt over the neck may result in neck injury during sudden braking or in a collision.
Page 39 Push the button on the buckle. Before closing the door, make sure that the belts are retracted properly to avoid catching the belt webbing in the door. ! Rear center seatbelt Center seatbelt tongue plate Connector (tongue) Connector (buckle) Center seatbelt buckle WARNING Fastening the seatbelt with the web- bing twisted can increase the risk or...
Page 40 1-18 Seat, seatbelt and SRS airbags The rear center seatbelt is stowed in a recessed compartment located in the ceiling above the cargo area. 1. Remove the tongue plate from the slot in the recessed compartment and pull out the seatbelt slowly. 2.
Page 41 6. Place the lap belt as low as possible on your hips, not on your waist. ! Unfastening the seatbelt Push the release button of the center seatbelt buckle (on the left-hand side) to unfasten the seatbelt. NOTE When the seatback is folded down for greater cargo area, it is necessary to disconnect the connector.
Page 42: Seatbelt Maintenance
In the event that a pretensioner is activated, both the driver’s and front passenger’s seatbelt retractor assemblies must be replaced only by an authorized SUBARU dealer. When replacing seat- belt retractor assemblies, use only genuine SUBARU parts.
Page 43: System Monitors
. If the front seatbelt retractor assem- bly or surrounding area has been damaged, contact your SUBARU dealer as soon as possible. . When you sell your vehicle, we urge you to explain to the buyer that it has seatbelt pretensioners by alerting him to the contents of this section.
Page 44: System Servicing
SRS airbag system. Immediately take your vehi- cle to your nearest SUBARU dealer to have the system checked. Unless checked and properly repaired, the seatbelt pretensioners and/or SRS...
Page 45: Precautions Against Vehicle Modification
SUBARU dealer as soon as possible. & Precautions against vehicle modification Always consult your SUBARU dealer if you want to install any accessory parts to your vehicle. CAUTION Do not perform any of the following modifications.
Page 46: Where To Place A Child Restraint System
& Where to place a child re- straint system The following are SUBARU’s recommen- dations on where to place a child restraint system in your vehicle. A: Front passenger’s seat You should not install a child restraint...
Page 47: Choosing A Child Restraint System
only a child restraint system that has a bottom base that fits snugly against the contours of the seat cushion and can be securely retained using the seatbelt. If it is unavoidable to install a child restraint system in the rear seat’s center seating position, lower the center head restraint to the lowest position and install the child restraint system by correctly...
Page 48: Installing Child Restraint Systems With A/Elr Seatbelt
1-26 Seat, seatbelt and SRS airbags & Installing child restraint sys- tems with A/ELR seatbelt WARNING . Child restraint systems and seat- belts can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child.
Page 49 6. Push and pull the child restraint system forward and from side to side to check if it is firmly secured. Sometimes a child restraint can be more firmly secured by pushing it down into the seat cushion and then tightening the seatbelt. 7.
Page 50 1-28 Seat, seatbelt and SRS airbags 4. Take up the slack in the lap belt. 5. Pull out the seatbelt fully from the retractor to change the retractor over from the Emergency Locking Retractor (ELR) to the Automatic Locking Retractor (ALR) function.
Page 51: Installing A Booster Seat
9. To remove the child restraint system, press the release button on the seatbelt buckle and allow the belt to retract completely. The belt will return to the ELR mode. NOTE When the child restraint system is no longer in use, remove it and restore the ELR function of the retractor.
Page 52: Installation Of Child Restraint Systems By Use Of Lower And Tether Anchorages (Latch)
1-30 Seat, seatbelt and SRS airbags WARNING . Never use a belt that is twisted or reversed. In an accident, this can increase the risk or severity of injury to the child. . Never place the shoulder belt under the child’s arm or behind the child’s back.
Page 53 Your vehicle is equipped with four lower anchorages (bars) and three upper an- chorages (tether anchorages) for accom- modating such child restraint systems. The lower anchorages (bars) are used for installing a child restraint system only on the rear seat window-side seating posi- tions.
Page 54 6. To remove the child restraint system, follow the reverse procedures of installa- tion. If you have any question concerning this type of child restraint system, ask your SUBARU dealer.
Page 55: Top Tether Anchorages
& Top tether anchorages Your vehicle is equipped with three top tether anchorages so that a child restraint system having a top tether can be installed in the rear seat. When installing a child restraint system using top tether, proceed as follows, while observing the instructions by the child restraint system manufacturer.
Page 56: Srs Airbag (Supplemental Restraint System Airbag)
3. Attach the child restraint top tether hook to the appropriate upper anchorage. 4. Tighten the top tether securely. Please contact your SUBARU dealer if you have any question regarding the installation of a child restraint system. CAUTION...
Page 57 senger, and window-side rear passen- gers) These SRS airbags are designed only as a supplement to the primary protec- tion provided by the seatbelt. The system also controls front seatbelt pretensioners. For operation instructions and precautions concerning the seatbelt pretensioner, refer to “Front seatbelt pre- tensioners”...
Page 58 1-36 Seat, seatbelt and SRS airbags WARNING . Put children aged 12 and under in the rear seat properly restrained at all times. The SRS airbag deploys with considerable speed and force and can injure or even kill children, especially if they are 12 years of age and under and are not restrained or improperly restrained.
Page 59 ! Components Airbag control module (including impact and rollover sensors) Frontal airbag module (driver’s side) Frontal airbag module (front passenger’s side) Front sub sensor (left-hand side) Front sub sensor (right-hand side) Side airbag module (driver’s side) Side airbag module (front passenger’s side) Side airbag sensor (center pillar left-hand side)
Page 60: Subaru Advanced Frontal Airbag System
1-38 Seat, seatbelt and SRS airbags & SUBARU advanced frontal airbag system Your vehicle is equipped with a SUBARU advanced frontal airbag system that com- plies with the new advanced frontal airbag requirements in the amended Federal Motor Vehicle Safety Standard (FMVSS) No.
Page 61 WARNING Never hold a child on your lap or in your arms. The SRS airbag deploys with considerable force and can injure or even kill the child. WARNING The SRS airbag deploys with con- siderable speed and force. Occu- pants who are out of proper position when the SRS airbag deploys could suffer very serious injuries.
Page 62 SRS frontal airbag even when the driver’s SRS frontal airbag deploys. This is normal. Observe the following precautions. Failure to do so may prevent the SUBARU advanced frontal airbag system from functioning correctly or cause the system to fail.
Page 63 SRS airbag system warning light will illuminate. Have the system inspected by your SUBARU deal- er immediately if the SRS airbag system warning light illuminates. If your vehicle has sustained impact, this may affect the proper function of the SUBARU advanced frontal airbag system.
Page 64 1-42 Seat, seatbelt and SRS airbags facing child restraint system and a small child is restrained with it. (See WARNING that follows.) . The seat is equipped with a booster seat and a small child is in the booster seat. (See WARNING that follows.) .
Page 65 OFF indicator turns off after taking relevant corrective actions de- scribed above, relocate the child restraint system to the rear seat and immediately contact your SUBARU dealer for an inspection. NOTE When a child who has outgrown a child restraint system or a small adult is seated in the front passenger’s seat,...
Page 66 Subaru of America, Inc. Customer Dealer Services Department P.O. Box 6000 Cherry Hill, NJ 08034-6000 1-800-SUBARU3 (1-800-782-2783) <Hawaii> Servco Subaru Inc., dba Subaru Hawaii 2850 Pukoloa Street, Suite 202, Honolulu, HI 96819 808-839-2273 <Guam> Shen’s Corporation dba Prestige Automo- bile...
Page 67 Seat, seatbelt and SRS airbags The SRS airbag can function only when the ignition switch is in the “ON” position. The SUBARU advanced frontal airbag system is designed to determine the activation or deactivation condition of the front passenger’s SRS frontal airbag depending on the total load on the front passenger’s seat monitored by the front...
Page 68 1-46 Seat, seatbelt and SRS airbags The two inflators of each airbag are triggered either sequentially or simulta- neously, depending on the severity of impact, in the case of the driver’s SRS frontal airbag and depending on the severity of impact and the total load on the seat in the case of the front passen- ger’s SRS frontal airbag.
Page 69 ! Examples of the types of accidents in which it is possible that the driver’s/driver’s and front passen- ger’s SRS frontal airbag(s) will de- ploy. Only the driver’s SRS frontal airbag or both driver’s and front passenger’s SRS frontal airbags may be activated when the vehicle sustains a hard impact in the undercarriage area from the road surface (such as when the vehicle plunges into a...
Page 70 1-48 Seat, seatbelt and SRS airbags ! Examples of the types of accidents in which deployment of the driver’s/driver’s and front passenger’s SRS frontal airbag(s) is unlikely to occur. The vehicle strikes an object, such as a telephone pole or sign pole. The vehicle slides under the load bed of a truck.
Page 71: Srs Side Airbag And Srs Curtain Airbag
! Examples of the types of accidents in which the driver’s/driver’s and front passenger’s SRS frontal airbag(s) will basically not deploy. The driver’s and front passenger’s SRS frontal airbags are designed basically not to deploy if the vehicle is struck from the side or from behind, or if it rolls onto its side or roof, or if it is involved in a low- speed frontal collision.
Page 72 1-50 Seat, seatbelt and SRS airbags WARNING The SRS side airbag and SRS curtain airbag are designed as only a supplement to the primary protec- tion provided by the seatbelt. They do not do away with the need to fasten seatbelts. It is also important to wear your seatbelt to help avoid injuries that can result when an occupant is not seated in a proper...
Page 73 WARNING . Never allow a child to kneel on the front passenger’s seat facing the side window or to wrap his/ her arms around the front seat seatback. In the event of an accident, the force of the SRS side airbag deployment could injure the child seriously be- cause his/her head or arms or other parts of the body are too...
Page 74 1-52 Seat, seatbelt and SRS airbags A hands-free microphone or other accessory in such a loca- tion could be propelled through the cabin with great force by the curtain airbag, or it could prevent correct deployment of the curtain airbag. In either case, the result could be serious injuries.
Page 75 vehicle, the control module inflates the curtain airbags. After the deployment, the SRS side airbag immediately starts to deflate. The time required from detection of an impact to deflation of an SRS side airbag after deployment is shorter than the blink of an eye.
Page 76 1-54 Seat, seatbelt and SRS airbags ! Examples of the types of accidents in which the SRS curtain airbag will most likely deploy. A severe side impact near the front seat or the rear seat activates the SRS curtain airbag. The vehicle rolls onto its side or the roof.
Page 77: Seat, Seatbelt And Srs Airbags
! Examples of the types of accidents in which it is possible that the SRS side airbag and the SRS curtain airbag will deploy. 1-55 Seat, seatbelt and SRS airbags Hitting a curb, edge of pavement or hard surface Falling into or jumping over a deep hole Landing hard or vehicle falling It is possible that the SRS side and curtain airbags will deploy if a serious impact...
Page 78 1-56 Seat, seatbelt and SRS airbags ! Examples of the types of accidents in which the SRS side airbag is unlikely to deploy. The vehicle is involved in an oblique side-on impact. The vehicle is involved in a side-on impact in an area outside the vicinity of the passenger compartment.
Page 79 ! Examples of the types of accidents in which the SRS curtain airbag is unlikely to deploy. 1-57 Seat, seatbelt and SRS airbags The vehicle is involved in an oblique side-on impact. The vehicle is involved in a side-on impact in an area outside the vicinity of the passenger compartment.
Page 80 1-58 Seat, seatbelt and SRS airbags ! Examples of the types of accidents in which the SRS side airbag and SRS curtain airbag will basically not deploy. The vehicle is involved in frontal collision with another vehicle (moving or station- ary).
Page 81: Srs Airbag System Monitors
SRS airbag system. Immediately take your vehi- cle to your nearest SUBARU dealer to have the system checked. Unless checked and properly repaired, the seatbelt pretensioners and/or SRS...
Page 82: Precautions Against Vehicle Modification
CAUTION If you need service or repair in areas indicated in the following list, have the work performed by an author- ized SUBARU dealer. The SRS air- bag control module, impact sensors and airbag modules are stored in these areas.
Page 83 . Attachment of any equipment (side steps or side sill protectors, etc.) other than genuine SUBARU accessory parts to the side body. Always consult your SUBARU dealer if you want to install any accessory parts on your vehicle. 1-61 Seat, seatbelt and SRS airbags...
Page 84 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 85 Keys ... Key number plate ... Immobilizer ... Security ID plate... Security indicator light ... Key replacement ... Door locks ... Locking and unlocking from the outside ... Locking and unlocking from the inside ... Battery drainage prevention function ... Power door locking switches ...
Page 86: Keys And Doors
Keys and doors Keys Master key (black) Submaster key (black) Valet key (gray) Key number plate Security ID plate Three types of keys are provided for your vehicle: Master key, submaster key and valet key. The master key and submaster key fit all locks on your vehicle.
Page 87: Security Id Plate
If the security indicator light does not flash, the immobilizer system may be faulty. If this occurs, contact your SUBARU dealer as soon as possible. In case an unauthorized key is used (e.g. an imitation key), the security indicator light illuminates.
Page 88: Key Replacement
For information on replacement keys and on the registration of keys with your immo- bilizer system, contact your SUBARU dealer. NOTE A vehicle that is equipped with the...
Page 89: Battery Drainage Prevention Function
Rotate the lock lever rearward. Close the door. To lock the door from the outside without the key, rotate the lock lever rearward and then close the door. To lock the door from the outside using the power door locking switch, push the front side of the switch (“LOCK”...
Page 90: Power Door Locking Switches
The operational/non-operational setting of this function can be changed by a SUBARU dealer. Contact your SUBARU dealer to change the setting. NOTE . The factory setting (default setting) for this function is set as “operational”.
Page 91: Key Lock-In Prevention Function
The setting of this function to operational/ non-operational status can be changed by a SUBARU dealer. Contact a SUBARU dealer for details. NOTE When leaving the vehicle, make sure you are holding the key before locking the doors.
Page 92: Locking The Doors
Keys and doors to the following two conditions: (1) This device may not cause harmful inter- ference, and (2) this device must accept any interference received, in- cluding interference that may cause undesired operation. Changes or modifications not ex- pressly approved by the party respon- sible for compliance could void the user’s authority to operate the equip- ment.
Page 93: Unlocking The Doors
The dome light must be set to the DOOR position in order for this function to operate. A SUBARU dealer can change the illumi- Keys and doors nation period setting of the interior light in accordance with your preference. Contact the nearest SUBARU dealer for details.
Page 94: Sounding A Panic Alarm
5. The turn signal lights flash 3 times to indicate completion of the setting. You may have the above settings done by your SUBARU dealer. & Replacing the battery CAUTION . Do not let dust, oil or water get on or in the transmitter when repla- cing the battery.
Page 95: Replacing Lost Transmitters
head screwdriver. 2. Remove the old battery from the holder. Negative (−) side facing up 3. Replace with a new battery (type CR2025 or equivalent) making sure to install the new battery with the negative (−) side facing up. 4. Refit the removed half of the transmit- ter case.
Page 96 2-12 Keys and doors program the transmitter’s code (identifica- tion number) into the system. A label showing the code is affixed to the bag containing the transmitter, and another is affixed to the circuit board inside the transmitter. If there is no bag, open the transmitter case and make a note of the eight-digit number.
Page 97 NOTE . The electronic tone will stop sound- ing when you start entering the num- ber. . If you do not start entering the number using the lock switch before the electronic tone stops sounding, an error will occur. In this event, perform the registration steps again beginning with part 3 of the procedure.
Page 98: Alarm System
Your vehicle’s alarm system has been set for activation at the time of shipment from the factory. You can set the system for deactivation yourself or have it done by your SUBARU dealer. & System operation The alarm system will give the following alarms when triggered.
Page 99: Activating And Deactivating The Alarm System
“DOOR” position) The notifications regarding the dome light and the map lights are deactivated as the factory setting. A SUBARU dealer can activate the system. Contact your SUBARU dealer for details. & Activating and deactivating the alarm system To change the setting of your vehicle’s...
Page 100 2-16 Keys and doors : Press to Arm the system. : Press to Disarm the system. 6. Briefly press the “ ” button (for less than 2 seconds). All doors and the rear gate will lock, an electronic chirp will sound once, the turn signal lights will flash once, and the indicator lights will start flashing rapidly.
Page 101: Disarming The System
DOORS MUST BE MANUALLY LOCKED. ! To enter the passive mode If you wish to program the passive arming mode, have it done by your SUBARU dealer. ! Arming the system CAUTION In passive mode, the system will...
Page 102: Tripped Sensor Identification
2-18 Keys and doors LOCK 2. Turn the ignition switch from “ON” to “LOCK” position and remove the key from the ignition switch. 3. Open the doors and get out of the vehicle. 4. Before closing the doors, lock all doors with the inside door lock levers.
Page 103: Shock Sensors (Dealer Option)
30 seconds. If you desire, your SUBARU dealer can connect them and set them for activation or deactivation. NOTE . The shock sensors are not always...
Page 104: Windows
2-20 Keys and doors Windows & Power windows WARNING To avoid serious personal injury caused by entrapment, always con- form to the following instructions without exception. . When operating the power win- dows, be extremely careful to prevent anyone’s fingers, arms, neck or head from being caught in the window.
Page 105 held. ! Operating the passengers’ windows To open: Push the appropriate switch down and hold it until the window reaches the desired position. To close: Pull the switch up and hold it until the window reaches the desired position. ! Locking the passengers’ windows Lock Unlock Push the lock switch.
Page 106: Rear Gate
2-22 Keys and doors Rear gate The rear gate can be locked and unlocked using any of the following systems. . Power door locking switch: Refer to “Power door locking switches” F2-6. . Remote keyless entry system: Refer to “Remote keyless entry system” F2-7. To open: Unlock the rear gate and push the rear gate opener button to open the rear gate.
Page 107: Moonroof (If Equipped)
procedure, refer to “Rear gate – if the rear gate cannot be opened” F9-17. Moonroof (if equipped) WARNING Never let anyone’s hands, arms, head or any objects protrude from the moonroof. A person could be seriously injured if the vehicle stops suddenly or turns sharply or if the vehicle is involved in an accident.
Page 108: To Open The Moonroof
2-24 Keys and doors The moonroof operates only when the ignition switch is in the “ON” position. & To open the moonroof Pull the switch to the “OPEN” side and quickly release it to open the moonroof. The sun shade will also be opened together with the moonroof.
Page 109: Sun Shade
2-25 Keys and doors & Sun shade The sun shade can be slid forward or backward by hand while the moonroof is closed. If the moonroof is opened, the sun shade also moves back.
Page 110 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 111: Instruments And Controls
Ignition switch ... LOCK... Acc... ON... START ... Key reminder chime ... Ignition switch light ... Hazard warning flasher... Meters and gauges... Combination meter illumination ... Canceling the function for meter/gauge needle movement upon turning on the ignition switch... Speedometer... Odometer/Trip meter...
Page 112 Instruments and controls High/low beam change (dimmer)... Headlight flasher ... Daytime running light system (if equipped) ... Automatic headlight beam leveler (models with HID headlights) ... Turn signal lever ... 3-27 Illumination brightness control ... 3-28 Front fog light switch (if equipped) ... 3-28 Wiper and washer ...
Page 113: Ignition Switch
Ignition switch WARNING . Never turn the ignition switch to “LOCK” while the vehicle is being driven or towed because that will lock the steering wheel, preventing steering control. And when the engine is turned off, it takes a much greater effort than usual to steer.
Page 114: Acc
Instruments and controls The key can be turned from “Acc” to “LOCK” only when the selector lever is in the “P” position. ! Manual transmission models The key can be turned from “Acc” to “LOCK” only when the key is pushed in while turning it.
Page 115: Key Reminder Chime
contains an immobilizer transponder. . The key is near or touching another transmitter. & Key reminder chime The reminder chime sounds when the driver’s door opens and the key is in the “LOCK” or “Acc” position. The chime stops when the ignition switch is turned to the “ON”...
Page 116: Canceling The Function For Meter/Gauge Needle Movement Upon Turning On The Ignition Switch
Instruments and controls & Canceling the function for meter/gauge needle move- ment upon turning on the ignition switch It is possible to activate or deactivate the movement of the meter needles and gauge needles that takes place when the ignition switch is turned to the “ON” position.
Page 117 The display can be switched as shown below by pressing the trip knob. *: “ ” or “ ” cannot be displayed when the ignition switch is in the “ON” posi- tion. For the “ ” or “ ” indication, refer to “Canceling the function for meter/gauge needle movement upon turning on the ignition switch”...
Page 118: Tachometer
Instruments and controls & Tachometer The tachometer shows the engine speed in thousands of revolutions per minute. CAUTION Do not operate the engine with the pointer of the tachometer in the red zone. This may cause severe da- mage to the engine. NOTE (non-turbo models) To protect the engine while the selector lever is in the “P”...
Page 119: Warning And Indicator Lights
NOTE This light does not turn off unless the tank is replenished up to an internal fuel quantity of approximately 4.0 US gal (15 liters, 3.3 Imp gal). CAUTION Promptly put fuel in the tank when- ever the low fuel warning light illuminates.
Page 120: Seatbelt Warning Light And Chime
Instruments and controls lights) If any lights fail to illuminate, it indicates a burned-out bulb or a malfunction of the corresponding system. Consult your authorized SUBARU dealer for repair. & Seatbelt warning light and chime Your vehicle is equipped with a seatbelt warning device at the driver’s and front...
Page 121: Srs Airbag System Warning Light
If still the seatbelt warning device for front passenger’s seat does not function cor- rectly after taking relevant corrective ac- tions described above, immediately con- tact your SUBARU dealer for an inspec- tion. & SRS airbag system warning light When the ignition switch is turned to the “ON”...
Page 122: Front Passenger's Frontal Airbag On And Off Indicators
2 seconds. After that, one of the indicators illuminates depending on the status of the front passenger’s SRS frontal airbag determined by the SUBARU ad- vanced frontal airbag system monitoring. If the front passenger’s SRS frontal airbag is activated, the passenger’s frontal airbag ON indicator will illuminate while the OFF indicator will remain off.
Page 123: Coolant Temperature Low Indicator Light/Coolant
3-13 Instruments and controls After that, have the system checked by your nearest SUBARU dealer. Refer to “En- gine overheating” F9-12. – Blinking in RED and BLUE alternately: The electrical system may be malfunctioning. Contact your SUBARU dealer for an inspec- tion.
Page 124: Charge Warning Light
! Automatic transmission control system warning If the light flashes after the engine starts, it may indicate that the automatic transmis- sion control system is not working prop- erly. Contact your nearest SUBARU deal- er for service immediately.
Page 125: Models)
Should the warning light illuminate stea- dily after blinking for approximately one minute, have the system inspected by your nearest SUBARU dealer as soon as possible. WARNING If this light does not illuminate briefly after the ignition switch is...
Page 126: Abs Warning Light
This indicates the TPMS is unable to monitor all four road wheels. Contact your SUBARU dealer as soon as possible for tire and sensor replacement and/ or system resetting. If the light illuminates steadily after blinking...
Page 127 If the fluid level is below the “MIN” mark in the reservoir, do not drive the vehicle. Have the vehicle towed to the nearest SUBARU dealer for repair. ! Electronic Brake Force Distribution (EBD) system warning...
Page 128: Low Fuel Warning Light
Instruments and controls 6. If the brake fluid level is below the “MIN” mark, DO NOT drive the vehicle. Instead, have the vehicle towed to the nearest SUBARU dealer for repair. & Low fuel warning light The low fuel warning light illuminates when the tank is nearly empty approxi- mately 2.6 US gal (10.0 liters, or 2.2 Imp...
Page 129: Vehicle Dynamics Control Warning Light/Vehicle Dynamics Control Off Indicator Light
You will be safe while driving with this condition, but have your vehicle checked at a SUBARU dealer as soon as possible. NOTE If the warning light behavior is as...
Page 130: Security Indicator Light
If the security indicator light does not flash, the immobilizer system may not be func- tioning properly. If this occurs, contact your SUBARU dealer as soon as possible. In case an unauthorized key is used (e.g., an imitation key), the security indicator light illuminates.
Page 131: Selector Lever And Gear Position Indicator (At Models)
& Selector lever and gear posi- tion indicator (AT models) This indicator shows the position of the selector lever. When the manual mode is selected, the gear position indicator (which shows the current gear selection) and the upshift/ downshift indicator light up. Refer to “Automatic transmission”...
Page 132: Clock
3-22 Instruments and controls Clock The clock shows the time while the ignition switch is in the “Acc” or “ON” position. The time changes by 1 minute each time the “+” button or “−” button is pressed. Pressing the “+” button moves the dis- played time forward, while pressing the “−”...
Page 133: Outside Temperature Indicator
The fuel consumption display is linked with the odometer/trip meter display ac- cording to the following chart. Odometer/Trip Fuel consumption indicator meter A trip meter Average fuel consumption corresponding to the A trip meter Average fuel consumption corresponding to the B trip B trip meter meter Odometer...
Page 134: Current Fuel Consumption (If Equipped)
3-24 Instruments and controls “ON” position, the indication does not flash. NOTE The outside temperature indication may differ from the actual outside temperature. The road surface freeze warning indication should be treated only as a guide. Be sure to check the condition of the road surface before driving.
Page 135: Light Control Switch
tion indicator will automatically turn on when the battery voltage is discon- nected and then reconnected for bat- tery replacement or fuse replacement. Light control switch The light control switch only operates when the ignition key is inserted into the ignition switch.
Page 136: Headlights
3-26 Instruments and controls & Headlights To turn on the headlights, turn the knob on the end of the turn signal lever. first position Instrument panel illumination, tail lights, front side marker lights and license plate lights are on. second position Headlights, instrument panel illumination, tail lights, front side marker lights, and license plate lights are on.
Page 137: Daytime Running Light System (If Equipped)
& Daytime running light system (if equipped) WARNING The brightness of the illumination of the high beam headlights is reduced by the daytime running light system. The light switch must always be turned to the “ ” position when it is dark outside.
Page 138: Illumination Brightness Control
3-28 Instruments and controls Illumination brightness con- trol The brightness of clock display, audio, air conditioner, information display and instru- ment panel illumination dims when the light switch is in the “ ” or “ positions. You can adjust brightness of the instrument panel illumination for better visibility.
Page 139: Wiper And Washer
. Use clean water if windshield washer fluid is unavailable. In areas where water freezes in winter, use SUBARU Windshield Washer Fluid or the equivalent. – CONTINUED –...
Page 140: Windshield Wiper And Washer Switches
3-30 Instruments and controls Refer to “Windshield washer fluid” F11-39. Also, when driving the vehicle when there are freezing tempera- tures, use non-freezing type wi- per blades. . Do not clean the wiper blades with gasoline or a solvent, such as paint thinner or benzine.
Page 141 ! Wiper intermittent time control When the wiper switch is in the “ ” position, turn the dial to adjust the operat- ing interval of the wiper. The operating interval can be adjusted continuously from the shortest interval to the longest. The operating interval can be adjusted in nine steps.
Page 142: Rear Window Wiper And Washer Switch
3-32 Instruments and controls & Rear window wiper and washer switch : Washer (accompanied by wiper operation) ON: Continuous INT: Intermittent OFF: Off : Washer ! Rear wiper To turn the rear wiper on, turn the knob on the end of the wiper control lever upward to the “INT”...
Page 143 ! Auto-dimming mirror/compass (if equipped) Left button Auto dimming indicator Photosensor Right button The auto-dimming mirror has an anti-glare feature which automatically reduces glare coming from headlights of vehicles behind you. It also contains a built-in compass. . By pressing and releasing the left button, the automatic dimming function is toggled on or off.
Page 144: Outside Mirrors
3-34 Instruments and controls ! Compass zone adjustment Compass calibration zones 1. The zone setting is factory preset to Zone 8. Refer to the “Compass calibration zone” map shown above or one attached to the end of this manual to verify that the compass zone setting is correct for your geographical location.
Page 145: Defogger And Deicer
! Power folding mirror switch (if equipped) The power folding mirror switch operates only when the ignition switch is in the “ON” or “Acc” position. To fold the outside mirrors, push the power folding mirror switch. To unfold the mirrors, push the switch again.
Page 146 . Models with genuine SUBARU navi- gation system: The defogger and deicer system setting can be changed for continuous operation using the navigation monitor.
Page 147: Tilt Steering Wheel (If Equipped)
CAUTION . To prevent the battery from being discharged, do not operate the defogger and deicer system con- tinuously for any longer than necessary. . Do not use sharp instruments or window cleaner containing abra- sives to clean the inner surface of the rear window.
Page 148: Tilt/Telescopic Steering Wheel (If Equipped)
3-38 Instruments and controls Tilt/telescopic steering wheel (if equipped) WARNING . Do not adjust the steering wheel tilt/telescopic position while driv- ing. This may cause loss of vehicle control and result in personal injury. . If the lever cannot be raised to the fixed position, adjust the steering wheel again.
Page 149 Ventilator... Air flow selection ... Center and side ventilators ... Manual climate control system (if equipped) ... Control panel ... Heater operation ... Air conditioner operation... Automatic climate control system (if equipped) ... Control panel ... To use as full-automatic climate control system...
Page 150: Climate Control
Climate control Ventilator & Air flow selection...
Page 151: Center And Side Ventilators
& Center and side ventilators ! Center ventilators Move the tab up and down or right and left to adjust the flow direction. ! Side ventilators Open Close Thumb-wheel Move the tab up and down or right and left to adjust the flow direction. To open or close the ventilator, turn the thumb-wheel up or down.
Page 152 Climate control ! Fan speed control dial The fan operates only when the ignition switch is turned to the “ON” position. The fan speed control dial is used to select four fan speeds. ! Air flow control dial This dial has the following five positions: : Air flows through the instrument panel outlets.
Page 153: Heater Operation
WARNING Continued operation with the air inlet selection button in the ON position may fog up the windows. Switch to the OFF position as soon as the outside dusty condition clears. & Heater operation ! Defrosting or defogging the wind- shield To direct warm air to the windshield and front door windows:...
Page 154 Climate control NOTE Warm air also comes out from the right and left air outlets. To stop warm air flow from these outlets, turn the corre- sponding thumb-wheel down. ! Heating To direct warm air toward the floor: 1. Set the air inlet selection button to the OFF position.
Page 155: Air Conditioner Operation
When driving on a dusty road, set the air inlet selection button to the “ON” position. WARNING Continued operation with the air inlet selection button in the ON position may fog up the windows. Switch to the OFF position as soon as the outside dusty condition clears.
Page 156: Automatic Climate Control System (If Equipped)
Climate control Automatic climate control system (if equipped) Although this climate control system can be used as a full-automatic climate control system, it can also, if desired, be used as a semi-automatic climate control system. When it is used as a full-automatic climate control system, the outlet air temperature, fan speed, air flow distribution, air inlet control, and air conditioner compressor...
Page 157: Fan Speed Control Dial
SUBARU recom- mends using the AUTO position. Other positions: The fan speed can be adjusted in 7 steps.
Page 158: Air Inlet Selection Button
To return to “AUTO” mode, turn the fan speed control dial or air flow control dial to a position other than the AUTO position. Then turn to “AUTO” mode. SUBARU recommends using the AUTO position. WARNING Continued operation in the ON posi- tion may fog up the windows.
Page 159: Temperature Sensors
To return to “AUTO” mode, turn the fan speed control dial or air flow control dial to a position other than the AUTO position. Then turn to “AUTO” mode. SUBARU recommends using the AUTO position. NOTE The air conditioner’s compressor does not operate with an outside tempera- ture of 328F (08C) or lower.
Page 160: Operating Tips For Heater And Air Conditioner
HFC134a. Therefore, the meth- od of adding, changing or checking the refrigerant is different from the method for CFC12 (freon). Consult your SUBARU dealer for service. Repairs needed as a result of using the wrong refrigerant are not covered under warranty.
Page 161: Air Filtration System
Under extremely dusty conditions, the filter should be replaced more frequently. It is recommended that you have your filter checked or replaced by your SUBARU dealer. For replacement, use only a genuine SUBARU air filter kit. Replacement schedule:...
Page 162 4-14 Climate control 3. Replace the air filter element with a new one. CAUTION The arrow mark on the filter must point UP. 4. Reinstall the glove box, and connect the damper shaft. 5. Close the glove box. 6. LABEL installation (1) Fill out the information on the service label (small).
Page 163 4-15 Climate control air filter as shown in the illustration.
Page 164 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 165: Audio
Antenna system ... Roof antenna ... FM reception ... satellite radio reception (if equipped)... Installation of accessories... Audio set ... Type A audio set (if equipped) ... Type B audio set (if equipped) ... Power and sound controls ... Power switch and volume control ... Sound control ...
Page 166: Antenna System
Audio Antenna system & Roof antenna CAUTION . Be sure to lower the antenna rod before entering garages, parking towers and other locations with low ceilings. . Remove the antenna rod before washing your car at a car wash. If the antenna rod is left attached, it may scratch the roof.
Page 167 You may experience problems in receiving satellite radio signals in the follow- ing situations. . If you are driving northward in a coastal area You will notice that the XM satellite radio antenna is fixed to the upper right hand corner of your windshield. The signal comes from the south and may not be able to reach the antenna in some circumstances when you are driving north.
Page 168: Installation Of Accessories
Audio Installation of accessories Always consult your SUBARU dealer before installing a citizen band radio or other transmitting device in your vehicle. Such devices may cause the electronic control system to malfunction if they are incorrectly installed or if they are not...
Page 169: Audio Set
Audio set Your SUBARU may be equipped with one of the following audio sets. See the pages indicated in this section for operating details. & Type A audio set (if equipped) Audio The audio set will operate only when the ignition switch is in the “Acc”...
Page 170: Type B Audio Set (If Equipped)
Audio & Type B audio set (if equipped) The audio set will operate only when the ignition switch is in the “Acc” or “ON” position. . Power and sound controls: refer to page 5-7 . Radio operation: refer to page 5-10 .
Page 171: Power And Sound Controls
Power and sound controls & Power switch and volume control The dial is used for both power (ON/OFF) and volume control. The radio is turned ON and OFF by pushing the dial, and the volume is controlled by turning the dial. &...
Page 172 Audio mately 5 seconds. ! SVC setting SVC (Speed Volume Control) is a function that automatically adjusts the volume according to the vehicle speed. As the vehicle speed increases, the audio vo- lume automatically increases to match the vehicle speed, in order to create a pleasant listening environment even as the driving noise increases.
Page 173: Adjustable Level Of Each Mode
& Adjustable level of each mode Mode Volume Volume control AUX volume control* Tone and balance Bass control Midrange control Treble control Balance Fader Other settings SPEED VOLUME BEEP CS Auto (type B audio) *: Only when an AUX audio product is connected. Range of levels Initial setting Turn counterclockwise...
Page 174: Fm/Am Radio Operation
5-10 Audio FM/AM radio operation & FM/AM selection Push the “FM AM” button when the radio is off to turn on the radio. Push the “FM AM” button when the radio is on to select FM1, FM2, FM3 or AM reception.
Page 175 ! Scan tuning (SCAN) If you press the “SCAN” button, the radio will switch to the scan mode. In this mode, the radio scans through the radio band until a station is found. The radio will stop at the station for 5 seconds while display- ing the frequency, after which scanning will continue until the entire band has been scanned.
Page 176: Displaying Radio Ps (Program Service Name) And Rt (Radio Text)
5-12 Audio ! Seek in PTY (Program type) group In the PTY selection mode, when the desired PTY group has been selected, pressing the “SEEK” button “ ” or “ seeks within that PTY group. Pressing “ ” seeks up. Pressing “ seeks down.
Page 177: Satellite Radio Operation (If Equipped)
FM3 stations each may be preset. Satellite radio operation (if equipped) To receive satellite radio, it is necessary to install the SUBARU genuine satellite receiver (optional equipment) and to enter into a contract. For details, please contact your SUBARU dealer.
Page 178: Band Selection
5-14 Audio you activate satellite radio and receive satellite radio customer support. The satellite radio ID can be found on the audio display by tuning the channel to “0”. Turn the “CH” dial to select the satellite radio channel. NOTE For Sirius, change the display to an indication mode other than the channel number after performing the above...
Page 179 ! Skip channel selection When in the SAT mode, press the “SEEK” button “ ” or “ ” continuously to change to the channel selection mode. Pressing the “SEEK” button “ ” changes the channel up by 10 steps each time. Pressing “...
Page 180: Channel Preset
5-16 Audio & Channel preset ! How to preset channels 1. Press the “SAT” button to select SAT1, SAT2 and SAT3 reception. 2. Select the desired channel. 3. Press one of the preset buttons for more than 1.5 seconds to store the channel.
Page 181: Cd Player Operation
CD player operation NOTE . Make sure to always insert a disc with the label side up. If a disc is inserted with the label side down, the player displays “CHECK DISC”. Refer to “When the following messages are displayed” F5-25. .
Page 182 5-18 Audio ! Inserting a disc in a desired posi- tion 1. Briefly press the “LOAD” button. If the magazine in the player has an idle position where you can insert a disc, the disc number indicator associated with the idle position will blink.
Page 183: How To Play Back A Cd
start playback of the discs, beginning with the one inserted first. If you fail to insert any disc during each 15 seconds interval, the full disc loading mode will be canceled, and the player will start playback of the disc inserted first. &...
Page 184: Fast-Forwarding And Fast-Reversing
5-20 Audio ! Backward direction Turn the “TRACK” dial counterclockwise to skip to the beginning of the current track/file (track). Each time the dial is turned, the indicated track/file (track) number will decrease. NOTE In an MP3 or WMA folder, skipping past the first track/file (track) will take you to the last track/file (track) in the folder.
Page 185: Repeating
& Repeating To repeat a track/file (track), briefly press the “RPT” button while the track/file (track) is playing. Each time you briefly press the button, the mode changes in the following se- quences. Type A audio: Type B audio: NOTE .
Page 186: Scan
5-22 Audio format CD is playing. . The “F-RDM” indication refers to the random playback in the folder. It ran- domly repeats the tracks in the folder. It is possible to select the function when an MP3/WMA format track is playing. .
Page 187: Folder Selection
For CD-DA: For MP3/WMA: ! Page (track/folder title) scroll If you press the “TEXT” button again for at least 0.5 second, the title will be scrolled so you can see all of it. NOTE The display is designed to show titles for up to 24 characters.
Page 188: How To Eject Cds From The Player (Type B)
5-24 Audio & How to eject CDs from the player (type B) ! Ejecting a CD from the player Of the discs loaded, you can select and remove only one disc. 1. Use the disc select button to select the disc to be ejected.
Page 189: When The Following Messages Are Displayed
CD player, determine the cause based on the follow- ing information. If you cannot clear those messages, please contact your SUBARU dealer. ! When “PUSH EJECT” is displayed Press the eject button to unload the disc.
Page 190: Audio Control Buttons (If Equipped)
Refer to the Owner’s Manual of the portable audio player. NOTE . The AUX jacks of the models with the genuine SUBARU navigation sys- tem are the RCA type. For detailed information, refer to the Owner’s Man- ual supplement for the navigation sys- tem.
Page 191 waveband will be displayed. *2: Only when a CD is in the player. *3: Only when with an auxiliary audio product is connected. ! “ ” and “ ” buttons ! With radio mode selected Press the “ ” button or “ ”...
Page 192: Precautions To Observe When Handling A Compact Disc
5-28 Audio Precautions to observe when handling a compact disc Use only compact discs (CDs, CD-Rs and CD-RWs) that have the mark shown in the following. Also, some compact discs cannot be played. . You cannot use a DualDisc in the CD player.
Page 193 5-29 Audio there are deposits, wipe the disc surface from the center outward with a dry, soft cloth. Be sure not to use a hard cloth, thinner, benzine, alcohol, etc. . Do not use any disc that is scratched, deformed, or cracked. Also, do not use any disc that has a non-standard shape (for example, a heart shape).
Page 194 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 195 Interior lights ... Dome light ... Cargo area light ... Map light... Sun visors ... Vanity mirror ... Storage compartment ... Glove box ... Center console... Overhead console ... Rear seat center table (if equipped) ... Coin tray... Cup holders ... Front passenger cup holder...
Page 196: Interior Equipment
The setting can be changed using the navigation monitor. For details, please refer to the Owner’s Manual supplement for the navigation system. Also, the setting can be changed by a SUBARU dealer. Contact your SUBARU dealer for details. . Models without genuine SUBARU navigation system: The setting can be changed by a SUBARU dealer.
Page 197: Cargo Area Light
& Cargo area light DOOR The cargo area light switch has the following three positions. DOOR: The light illuminates when the rear gate is opened. The light remains illumi- nated for several seconds and turns off after the rear gate is closed. OFF: The light remains off.
Page 198: Sun Visors
The setting can be changed using the navigation monitor. For details, please refer to the Owner’s Manual supplement for the navigation system. Also, the setting can be changed by a SUBARU dealer. Contact your SUBARU dealer for details. . Models without genuine SUBARU navigation system: The setting can be changed by a SUBARU dealer.
Page 199: Vanity Mirror
& Vanity mirror CAUTION Keep the vanity mirror cover closed while the car is being driven to avoid being temporarily blinded by the glare of bright light. To use the vanity mirror, swing down the sun visor and open the vanity mirror cover. Storage compartment CAUTION .
Page 200 Interior equipment To use as an armrest: 1. Tip the console top forward from its vertical position. 2. Push the armrest part of the console top forward to the desired position. Adjust the position of the armrest to suit your driving position.
Page 201: Overhead Console
& Overhead console To open the console, push on the console lid lightly and the lid will automatically open. CAUTION When your vehicle is in the sun or on a warm day, the inside of the overhead console heats up. Avoid storing plastic or other heat-vulner- able or flammable articles such as a lighter in the overhead console.
Page 202: Cup Holders
Interior equipment Cup holders CAUTION Take care to avoid spills. Beverages, if hot, might burn you or your passengers. Spilled beverages may also damage upholstery, carpets or audio equipment. & Front passenger cup holder CAUTION Do not pick up a cup from the cup holder or put a cup in the holder while you are driving, as this may distract you and lead to an accident.
Page 203: Bottle Holders
Bottle holders CAUTION . Do not pick up a bottle from the bottle holder or put a bottle in the holder while you are driving, as this may distract you and lead to an accident. . When placing a beverage in a door pocket, make sure it is capped.
Page 204 6-10 Interior equipment Power outlet in the cargo area Accessory power outlets are provided below the climate controls, in the center console and in the cargo area. Electrical power (12V DC) from the battery is available at any of the outlets when the ignition switch is in either the “Acc”...
Page 205: Use With A Cigarette Lighter (Dealer Option)
A cigarette lighter plug is available from your SUBARU dealer. The cigarette lighter operates only when the ignition switch is in the “ON” or “Acc” position. To use the cigarette lighter, push in the knob and wait a few moments.
Page 206: Floor Mat
6-12 Interior equipment tray’s inner lid. Clean them off using a toothbrush or another narrow-ended implement. Floor mat A retaining pin is located on the driver’s side floor. The floor mat is secured using the built-in grommets, by placing the grommets over the pins and pushing them downward.
Page 207: Coat Hook
Coat hook A coat hook is attached to each side of the cargo area. CAUTION Never hang anything on the coat hook that might obstruct the driver’s view or that could cause injury in sudden stops or in a collision. Do no hang items on the coat hook that weigh 6 lbs (3 kg) or more.
Page 208: To Remove The Cover
6-14 Interior equipment of gas from the stays, which may result in their inability to hold the rear gate open. . If the vehicle is equipped with a reclining rear seatback feature, when reclining the rear seatback, move the front cover backward so that the cover is not damaged.
Page 209: Cargo Tie-Down Hooks
both ends of the sleeve into the recesses of the retainers. Cargo tie-down hooks The cargo area is equipped with four tie- down hooks so that cargo can be secured with a cargo net or ropes. When using the tie-down hooks, turn them down out of the storing recesses.
Page 210: Under-Floor Storage Compartment (If Equipped)
6-16 Interior equipment Under-floor storage compart- ment (if equipped) The storage compartment is located under the floor of the cargo area, and it can be used to store small items. To open the lid, pull the tab up. CAUTION . Always keep the lids closed while driving to reduce the risk of injury in the event of a sudden stop or an accident.
Page 211: Starting And Operating
Fuel ... Fuel requirements ... Fuel filler lid and cap... State emission testing (U.S. only)... Preparing to drive ... Starting the engine... Manual transmission model ... Automatic transmission model ... Stopping the engine... 7-10 Remote engine start system (dealer option) ... Starting your vehicle ...
Page 212: Starting And Operating
Starting and operating Cruise control indicator light ... 7-39 Cruise control set indicator light ... 7-39...
Page 213: Fuel
Do not be concerned if your vehicle sometimes knocks lightly when you drive up a hill or when you accelerate. Contact your SUBARU dealer if you use a fuel with the specified octane rating and your vehicle knocks heavily or persistently.
Page 214: Fuel Filler Lid And Cap
SUBARU. In addition, some gasoline suppliers are now producing reformulated gasolines, which are designed to reduce vehicle emissions. SUBARU approves the use of reformulated gasoline. If you are not sure what the fuel contains, you should ask your service station...
Page 215 1. To open the fuel filler lid, pull the lid release lever up. The lever is on the floor at the left of the driver’s seat. WARNING Before opening the fuel filler cap, first touch the vehicle body or a metal portion of the fuel pump or similar object to discharge any static electricity that may be present...
Page 216 Paint damage caused by spilled fuel is not covered under the SUBARU Limited Warranty. . Always use a genuine SUBARU fuel filler cap. If you use the wrong cap, it may not fit or have proper venting and your fuel tank and emission control system may be damaged.
Page 217: State Emission Testing (U.s. Only)
State emission testing (U.S. only) At state inspection time, remember to tell your inspection or service station in advance not to place your SUBARU AWD vehicle on a two-wheel dynam- ometer. Otherwise, serious transmis- sion damage will result. Some states have started using dynam-...
Page 218: Preparing To Drive
. Owners of rejected or failing vehicles should contact their SUBARU Dealer for service. Preparing to drive You should perform the following checks and adjustments every day before you start driving.
Page 219: Automatic Transmission
“START” position without depressing the accelerator pedal. (4) If the engine still refuses to start, contact your nearest SUBARU dealer for assistance. 6. Confirm that all warning and indicator lights have gone off after the engine has started.
Page 220: Stopping The Engine
7-10 Starting and operating (4) If the engine still refuses to start, contact your nearest SUBARU dealer for assistance. 6. Confirm that all warning and indicator lights have gone out after the engine has started. The fuel injection system auto- matically lowers the idle speed as the engine warms up.
Page 221: Remote Engine Start System (Dealer Option)
Remote engine start system (dealer option) WARNING . Do not remote start a vehicle in an enclosed environment (e.g., in a closed garage). Prolonged op- eration of a motor vehicle in an enclosed environment can cause a harmful build-up of Carbon Monoxide.
Page 222: Entering The Vehicle While It Is Running Via Remote Start
7-12 Starting and operating & Entering the vehicle while it is running via remote start 1. Unlock the vehicle doors using the keyless entry system. If the vehicle’s doors are unlocked manually using the key, the vehicle’s alarm system will trigger and the remote engine start system will turn off.
Page 223: System Maintenance
feature programming can be adjusted using the following procedure. 1. Open the driver’s door (the driver’s door must remain opened throughout the entire process). 2. Insert the key into the vehicle’s ignition switch and turn to the “ON” position. 3. Locate the small black programming button behind the fuse box cover, on the driver’s side left under the dashboard panel.
Page 224 7-14 Starting and operating 1. Carefully pry the remote control halves apart using a small flat-head screwdriver. 2. Remove the circuit board from the bottom half of the case and slide the white plastic battery holder out from under the battery tab releasing the batteries.
Page 225: Manual Transmission
Manual transmission The manual transmission is a fully syn- chromeshed, 5-forward-speed and 1-re- verse-speed transmission. The shift pattern is shown on the shift lever knob. When shifting from 5th gear to reverse gear, first return the shift lever to the neutral position then shift into reverse gear.
Page 226: Driving Tips
7-16 Starting and operating Never exceed the posted speed limit. WARNING When shifting down a gear, ensure that the vehicle is not travelling at a speed exceeding the Maximum Al- lowable Speed for the gear which is about to be selected. Failure to observe this precaution can lead to engine over-revving and this in turn can result in engine damage.
Page 227: Selector Lever
“R” position or vice versa until the vehicle has completely stopped. Such shifting may cause damage to the transmis- sion. . When parking the vehicle, first securely apply the parking brake and then place the selector lever in the “P” position. Avoid parking for a long time with the selector lever in any other position as doing so could result in a dead...
Page 228: Selector Lever Reverse Inhibiting Function
7-18 Starting and operating transmission is neutral; the vehicle will roll freely, even on the slightest incline unless the parking brake or foot brake is on. Avoid coasting with the transmission in neutral. During coasting, there is no engine brak- ing effect.
Page 229: Selection Of Manual Mode
“P” position. If the selector lever reverse inhibiting function fails, have the vehicle inspected by the nearest SUBARU dealer. 7-19 Starting and operating & Selection of manual mode With the vehicle either moving or station- ary, move the selector lever from the “D”...
Page 230: Maximum Speeds
7-20 Starting and operating Upshift indicator Downshift indicator Gear position indicator When manual mode is selected, the gear position indicator and upshift indicator and/or downshift indicator on the combi- nation meter illuminate. The gear position indicator shows the currently selected gear in the 1st-to-4th-gear range.
Page 231: Driving Tips
In addition, sudden application of engine braking caused by down shifting when the vehicle is travel- ling on a slippery surface can lead to wheel locking; as a consequence, control of the vehicle may be lost and the risk of an accident in- creased.
Page 232: Shift Lock Release
“P” to the “N” position. 6. Remove the screwdriver from the hole. Depress the brake pedal and start the engine. Take your vehicle to the nearest SUBARU dealer immediately to have the system repaired.
Page 233: Power Steering
Power steering The power steering system operates only when the engine is running. If you lose power steering assist because the engine stops or the system fails to function, you can steer but it will take much more effort. CAUTION Do not hold the steering wheel at the fully locked position left or right for more than 5 seconds.
Page 234: Disc Brake Pad Wear Warning Indicators
If a squeaking or scraping noise is heard from the disc brakes while braking, im- mediately have your vehicle checked by your SUBARU dealer. ABS (Anti-lock Brake Sys- tem) The ABS system prevents the lock-up of...
Page 235: Abs System Self-Check
8 mph (12 km/h). . The warning light illuminates dur- ing driving. If these occur, have the ABS system repaired at the first available oppor- tunity by your SUBARU dealer. – CONTINUED –...
Page 236: Electronic Brake Force Distribution (Ebd) System
7-26 Starting and operating NOTE If the warning light behavior is as described below, the ABS system may be considered normal. . The warning light illuminates right after the engine is started but turns off immediately, remaining off. . The warning light remains on after the engine has been started, but it turns off when the vehicle speed reaches approximately 8 mph (12...
Page 237: Vehicle Dynamics Control System
3. Release the parking brake. If both warning lights turn off, the EBD system may be malfunctioning. Drive carefully to the nearest SUBARU dealer and have the system inspected. 4. If both warning lights illuminate again and stay illuminated after the engine has...
Page 238: Vehicle Dynamics Con Trol Operation Indicator
Vehicle Dynamics Control system, have an inspection of that system performed by an authorized SUBARU dealer. . The following precautions should be observed in order to ensure that the Vehicle Dynamics Con- trol system is operating properly: –...
Page 239: Vehicle Dynamics Control System Monitor
The following two situations could indicate a malfunction of the Vehicle Dynamics Control system; if either should occur, have an authorized SUBARU dealer carry out an inspection of that system at the first available opportunity. . The indicator light does not illuminate...
Page 240 SUBARU dealer carry out an inspection of those systems at the first available oppor- tunity. NOTE...
Page 241: Vehicle Dynamics Control Off Switch
minutes have passed to allow the engine to heat up sufficiently. & Vehicle Dynamics Control OFF switch Pressing the switch to deactivate the Vehicle Dynamics Control system can facilitate the following operations: . a standing start on a steeply sloping road with a snowy, gravel-covered, or otherwise slippery surface .
Page 242: Tire Pressure Monitoring System (Tpms) (U.s.-Spec. Models)
Do not inject any tire liquid or aerosol tire sealant into the tires, as this may cause a malfunction of the tire pressure sensors. If the light illuminates steadily after blinking for approximately 1 minute, promptly contact a SUBARU dealer to have the system inspected.
Page 243: Parking Your Vehicle
CAUTION Do not place metal film or any metal parts in the cargo room/trunk. This may cause poor reception of the signals from the tire pressure sen- sors, and the tire pressure monitor- ing system will not function prop- erly. NOTE This device complies with Part 15 of the FCC Rules and with RSS-210 of...
Page 244 7-34 Starting and operating When parking on a hill, always turn the steering wheel. When the vehicle is headed up the hill, the front wheels should be turned away from the curb. When facing downhill, the front wheels should be turned into the curb. WARNING .
Page 245: Hill Start Assist System (Mt Vehicles)
Hill start assist system (MT vehicles) CAUTION The Hill start assist system is a device only for helping the driver to START the vehicle on an uphill grade. To prevent accidents when the vehicle is parked on a slope, be sure to firmly set the parking brake.
Page 246: Hill Start Assist Warning Light
Hill start assist system control, the warning light will illuminate. If the warning light illuminates, have the vehicle in- spected by your SUBARU dealer. Cruise control Cruise control enables you to maintain a constant vehicle speed without holding...
Page 247: To Temporarily Cancel The Cruise Control
2. Depress the accelerator pedal until the vehicle reaches the desired speed. 3. Push the “SET/COAST” button and release it. Then release the accelerator pedal. At this time, the “ ” indicator light on the combination meter will illuminate. The vehicle will maintain the desired speed.
Page 248: To Turn Off The Cruise Control
7-38 Starting and operating & To turn off the cruise control There are two ways to turn off the cruise control: . Push the “CRUISE” main switch button again. . Turn the ignition switch to the “Acc” or “LOCK” position (but only when the vehicle is completely stopped).
Page 249 “ON” position. . If this indicator light and the CHECK ENGINE warning light/malfunction in- dicator lamp flash simultaneously dur- ing driving, have the vehicle checked by your nearest SUBARU dealer. 7-39 Starting and operating & Cruise control set indicator light...
Page 250 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 251: Driving Tips
New vehicle break-in driving – the first 1,000 miles (1,600 km) ... Fuel economy hints ... Engine exhaust gas (carbon monoxide)... Catalytic converter ... Periodic inspections ... Driving in foreign countries ... Driving tips for AWD models... On-pavement and off-road driving ... Winter driving ...
Page 252: New Vehicle Break-In Driving - The First 1,000 Miles (1,600 Km)
Driving tips New vehicle break-in driving – the first 1,000 miles (1,600 The performance and long life of your vehicle are dependent on how you handle and care for your vehicle while it is new. Follow these instructions during the first 1,000 miles (1,600 km): .
Page 253: Catalytic Converter
(misfiring, back- firing or incomplete combustion), have your vehicle checked and repaired by an authorized SUBARU dealer. . Do not apply undercoating or rust prevention treatment to the heat shield of catalytic converter and the exhaust sys- tem.
Page 254: Periodic Inspections
Driving tips operates at very high tempera- tures. . Keep everyone and flammable materials away from the exhaust pipe while the engine is running. The exhaust gas is very hot. Periodic inspections To keep your vehicle in the best condition at all times, always have the recom- mended maintenance services listed in the maintenance schedule in the “War-...
Page 255: Driving Tips For Awd Models
By shifting power between the front and rear wheels, SUBARU AWD can also provide added traction during acceleration and added engine braking force during deceleration.
Page 256: On-Pavement And Off-Road Driving
If you do take your SUBARU off-road, certain common sense precautions such as those in the following list should be taken. . Make certain that you and all of your passengers are wearing seatbelts.
Page 257 “Warranty and Mainte- nance Booklet”. Remember that damage done to your SUBARU while operating it off-road and not using common sense precautions such as those listed above is not eligible for warranty coverage.
Page 258: Winter Driving
Do not use engine antifreeze or other substitutes because they may damage the paint of the vehicle. SUBARU Windshield Washer Fluid con- tains 58.5% methyl alcohol and 41.5% surfactant, by volume. Its freezing tem- perature varies according to how much it is diluted, as indicated in the following table.
Page 259: Driving On Snowy And Icy Roads
If your SUBARU is not going to be used for an extended period, it is best to have the fuel tank filled to capacity.
Page 260: Corrosion Protection
8-10 Driving tips CAUTION Avoid prolonged continuous driving in snowstorms. Snow will enter the engine’s intake system and may hinder the air flow, which could result in engine shutdown or even breakdown. ! Wiper operation when snowing Before driving in cold weather, make sure the wiper blades are not frozen to the windshield or rear window.
Page 261: Tire Chains
to an accident. Your vehicle is equipped with “all season tires” as original equipment, which are designed to provide an adequate measure of traction, handling and braking perfor- mance in year-round driving. In winter, it may be possible to enhance performance through use of tires designed specifically for winter driving conditions.
Page 262: Vehicle Capacity Weight
8-12 Driving tips WARNING . When you carry something inside the vehicle, secure it whenever you can to prevent it from being thrown around inside the vehicle during sudden stops, sharp turns or in an accident. . Do not pile heavy loads on the roof.
Page 263: Gvwr And Gawr (Gross Vehicle Weight Rating And Gross Axle Weight Rating)
& GVWR and GAWR (Gross Vehicle Weight Rating and Gross Axle Weight Rating) The certification label attached to the driver’s side doorjamb shows GVWR (Gross Vehicle Weight Rating) and GAWR (Gross Axle Weight Rating). The GVW (Gross Vehicle Weight) must never exceed the GVWR.
Page 264: Roof Molding And Crossbar (If Equipped)
8-14 Driving tips roof rail must be used together with the roof rack and any appro- priate carrying attachment that may be needed. The roof rail must never be used alone to carry cargo. Otherwise, damage to the roof or paint or a danger- ous road hazard due to loss of cargo could result.
Page 265: Trailer Hitch (Dealer Option)
! Installing carrying attachments on the crossbars When installing any carrying attachment such as a bike carrier, ski carrier, kayak carrier, cargo basket, etc. on the cross- bars, follow the manufacturer’s instruc- tions and make sure that the attachment is securely fixed to the crossbars.
Page 266: Connecting A Trailer
. The standard bumper beam must be installed after you remove the trailer hitch. Consult a SUBARU dealer for purchase of a standard bumper beam if you do not have the original.
Page 267: When You Do Not Tow A Trailer
Seek the advice of your SUBARU dealer to assist you in purchasing a hitch and other necessary towing equipment appropriate for your vehicle. In addition, be sure to follow the...
Page 268: Maximum Load Limits
8-18 Driving tips (Refer to “Maintenance schedule under severe driving conditions” in the “Warranty and Maintenance Booklet”.) Under no circumstances should a trailer be towed with a new vehicle or a vehicle with any new powertrain component (en- gine, transmission, differential, wheel bearings, etc.) for the first 1,000 miles (1,600 km) of driving.
Page 269 ! Gross Vehicle Weight (GVW) and Gross Vehicle Weight Rating (GVWR) Gross Vehicle Weight The Gross Vehicle Weight (GVW) must never exceed the Gross Vehicle Weight Rating (GVWR). Gross Vehicle Weight (GVW) is the combined total of the weight of the vehicle, driver, passengers, luggage, trailer hitch, trailer tongue load and any other optional equipment installed on your vehicle.
Page 270 8-20 Driving tips ! Tongue load Tongue load Ensure that the trailer tongue load is from 8 to 11 percent of the total trailer weight and does not exceed the maximum value of 200 lbs (90 kg). Jack Bathroom scale The tongue load can be weighed with a bathroom scale as shown in the illustration above.
Page 271: Trailer Hitches
Choose a proper hitch for your vehicle and trailer. The use of a genuine SUBARU trailer hitch is recommended. A genuine SUBARU hitch is available from your SUBARU dealer. If use of a non-genuine hitch is unavoid- able, be sure the hitch is suited to your vehicle and trailer.
Page 272 To ensure the trailer lights are connected properly, please consult your SUBARU dealer. Check for proper operation of the brake lights and turn signal lights each time you hitch up. ! Tires...
Page 273: Trailer Towing Tips
Trailer tire condition, size, load rating and proper inflation pressure should be in accordance with the trailer manufacturer’s specifications. In the event your vehicle gets a flat tire when towing a trailer, ask a commercial road service to repair the flat tire. If you carry a regular size spare tire in your vehicle or trailer as a precaution against getting a flat tire, be sure that the spare...
Page 274 . If the ABS warning light illuminates while the vehicle is in motion, stop towing the trailer and have repairs performed immediately by the nearest SUBARU dealer. ! Driving on grades . Before going down a steep hill, slow...
Page 275: In Case Of Emergency
If you park your vehicle in case of an emergency ... Temporary spare tire (if equipped) ... Precautions for AWD models with automatic transmission ... Maintenance tools ... Tool bag... Under the cargo area... Flat tires... Changing a flat tire... Tire pressure monitoring system (TPMS) (U.S.-spec.
Page 276: Temporary Spare Tire (If Equipped)
This indicates the tire pressure monitoring system (TPMS) is unable to monitor all four road wheels. Contact your SUBARU dealer as soon as possible for tire and sensor replacement and/or sys- tem resetting.
Page 277: Precautions For Awd Models With Automatic Transmission
install the conventional tire as soon as possible because the spare tire is de- signed only for temporary use. Check the inflation pressure of the tem- porary spare tire periodically to keep the tire ready for use. The correct pressure is 60 psi (420 kPa, 4.2 kg/cm When using the temporary spare tire, note the following.
Page 278: Maintenance Tools
In case of emergency Spare fuse FWD connector 3. Put a spare fuse inside the FWD connector located in the cabin and confirm that the All-Wheel Drive warning light “ ” illuminates. The All-Wheel-Drive capability of the vehicle has now been deactivated.
Page 279: Under The Cargo Area
& Under the cargo area Under-floor storage compartment (if equipped) (Refer to “Under-floor storage compartment” F6-16) Jack handle Tool bucket Spare tire Wheel nut wrench Hex-head wrench (only vehicles with moonroof) Screwdriver Jack Towing hook (eye bolt) The jack handle is stored under the cargo In case of emergency floor.
Page 280: Flat Tires
In case of emergency Flat tires If you have a flat tire while driving, never brake suddenly; keep driving straight ahead while gradually reducing speed. Then slowly pull off the road to a safe place. & Changing a flat tire WARNING .
Page 281 Notch Valve hole 7. If your vehicle has wheel covers, insert a wheel cover remover into the notch on the opposite side of the valve hole and pry the wheel cover to remove it. 8. Loosen the wheel nuts using the wheel nut wrench but do not remove the nuts.
Page 282 In case of emergency 12. Before putting the spare tire on, clean the mounting surface of the wheel and hub with a cloth. 13. Put on the spare tire. Replace the wheel nuts. Tighten them by hand. WARNING Do not use oil or grease on the wheel studs or nuts when the spare tire is installed.
Page 283: Tire Pressure Monitoring System (Tpms) (U.s.-Spec. Models)
This indicates the TPMS is unable to monitor all four road wheels. Contact your SUBARU dealer as soon as possible for tire and sensor replacement and/ or system resetting. Do not inject any tire liquid or...
Page 284: Jump Starting
9-10 In case of emergency Jump starting WARNING . Battery fluid is SULFURIC ACID. Do not let it come in contact with the eyes, skin, clothing or the vehicle. If battery fluid gets on you, thoroughly flush the exposed area with water immediately. Get medical help if the fluid has entered your eyes.
Page 285 9-11 In case of emergency (1) Connect one jumper cable to the positive (+) terminal on the discharged battery. (2) Connect the other end of the jumper cable to the positive (+) term- inal of the booster battery. (3) Connect one end of the other cable to the negative (−) terminal of the booster battery.
Page 286: Engine Overheating
Towing If towing is necessary, it is best done by your SUBARU dealer or a commercial towing service. Observe the following procedures for safety. WARNING Never tow AWD models (both AT and...
Page 287: Towing And Tie-Down Hooks
& Towing and tie-down hooks The towing hooks should be used only in an emergency (e.g., to free a stuck vehicle from mud, sand or snow). CAUTION . Use only the specified towing hook and tie-down hook. Never use suspension parts or other parts of the body for towing or tie-down purposes.
Page 288 To install the rear towing hook, the standard bumper beam must be installed on the vehicle at a SUBARU dealer. Consult a SUBARU dealer for details. Use a hitch ball and follow the instructions below when towing. . The weight of the object being towed must be less than the weight of the vehicle.
Page 289: Using A Flat-Bed Truck
Front tie-down hooks: The front tie-down hooks are located between each of the front tires and the front bumper. Rear tie-down hooks: The rear tie-down hooks are located near each of the jack-up reinforcements. WARNING Use the rear tie-down hooks only for downward anchoring.
Page 290: Towing With All Wheels On The Ground
9-16 In case of emergency CAUTION If your vehicle has a front under- spoiler and rear underspoiler (both optional), be careful not to scrape them when placing the vehicle on the carrier and when removing the vehicle from the carrier. &...
Page 291: Rear Gate - If The Rear Gate Cannot Be Opened
Rear gate – if the rear gate cannot be opened In the event that you cannot open the rear gate by operating the power door locking switches or the remote keyless entry system, you can open it from inside the cargo area.
Page 292 9-18 In case of emergency 2. Insert a hex-head wrench in the end of the motor shaft. To close the moonroof, turn the wrench counterclockwise. Have your vehicle checked and repaired by an authorized SUBARU dealer.
Page 293: Appearance Care
Exterior care ... 10-2 Washing... Waxing and polishing ... Cleaning aluminum wheels ... Corrosion protection... 10-4 Most common causes of corrosion ... To help prevent corrosion... Appearance care Cleaning the interior... 10-2 Seat fabric ... 10-3 Leather seat materials... 10-3 Synthetic leather upholstery...
Page 294: Exterior Care
10-2 Appearance care Exterior care & Washing CAUTION . When washing the vehicle, the brakes may get wet. As a result, the brake stopping distance will be longer. To dry the brakes, drive the vehicle at a safe speed while lightly pressing the brake pedal to heat up the brakes.
Page 295: Waxing And Polishing
When in doubt, it is always best to contact your SUBARU dealer or an auto paint specia- list. NOTE Be careful not to block the windshield washer nozzles with wax when waxing the vehicle.
Page 296: Corrosion Protection
Contact your SUBARU dealer to perform this kind of maintenance and treatment if you need assistance. Repair chips and scratches in the paint as soon as you find them.
Page 297: Cleaning The Interior
If your SUBARU is to be parked for a long time in bright sunlight, it is recommended that the seats and headrests be covered, or the windows shaded, to prevent fading or shrinkage.
Page 298: Navigation Monitor (If Equipped)
10-6 Appearance care & Navigation monitor (if equipped) To clean the navigation monitor, wipe it with a silicone cloth or with a soft cloth. If the navigation monitor is extremely dirty, clean it with a soft cloth moistened with neutral detergent then carefully wipe off any remaining detergent.
Page 299: Maintenance And Service
Maintenance schedule ... Maintenance precautions... Before checking or servicing in the engine compartment... When you do checking or servicing in the engine compartment while the engine is running... Engine hood ... Engine compartment overview... Non-turbo models ... Turbo models ... Engine oil...
Page 300 Maintenance and service Tire pressure monitoring system (TPMS) (U.S.-spec. models) ... Tire inspection ... Tire pressures and wear ... Wheel balance... Wear indicators ... Tire rotation direction mark ... Tire rotation ... Tire replacement ... Wheel replacement... Wheel covers (if equipped) ... Aluminum wheels...
Page 301: Maintenance Schedule
Maintenance precautions When maintenance and service are re- quired, it is recommended that all work be done by an authorized SUBARU dealer. If you perform maintenance and service by yourself, you should familiarize yourself with the information provided in this section on general maintenance and service for your SUBARU.
Page 302: Before Checking Or Servicing In The Engine Compartment
NEVER use a circuit tester for this wiring. If your SRS airbag or seatbelt preten- sioner needs service, consult your nearest SUBARU dealer. & Before checking or servicing in the engine compartment WARNING . Always stop the engine and set the parking brake firmly to pre- vent the vehicle from moving.
Page 303: Engine Hood
Engine hood To open the hood: 1. If the wiper blades are lifted off the windshield, return them to their original position. 2. Pull the hood release knob under the instrument panel. 3. Release the secondary hood release by moving the lever between the front grille and the hood toward the left.
Page 304: Fuse Box (Page
11-6 Maintenance and service Engine compartment overview & Non-turbo models Power steering fluid reservoir (page 11- Manual transmission oil level gauge (MT) (page 11-19) or Differential gear oil level gauge (AT) (page 11-21) Clutch fluid reservoir (page 11-26) Automatic transmission fluid level gauge (page 11-20) Brake fluid reservoir (page 11-25) Fuse box (page 11-45)
Page 305: Turbo Models
& Turbo models 11-7 Maintenance and service Power steering fluid reservoir (page 11-24) Manual transmission oil level gauge (MT) (page 11-19) or Differential gear oil level gauge (AT) (page 11-21) Clutch fluid reservoir (page 11-26) Automatic transmission fluid level gauge (page 11-20) Brake fluid reservoir (page 11-25) Fuse box (page 11-45)
Page 306: Engine Oil
. If the oil consumption rate seems abnormally high after the break-in period, for example more than 1 quart per 1,200 miles or 1 liter per 2,000 kilometers, contact your SUBARU deal- & Checking the oil level Check the engine oil level at each fuel stop.
Page 307: Changing The Oil And Oil Filter
pipe, be sure to wipe it off. If you check the oil level just after stopping the engine, wait a few minutes for the oil to drain back into the oil pan before checking the level. Just after driving or while the engine is warm, the engine oil level reading may be in a range between the upper level and the notch mark.
Page 308 11-10 Maintenance and service Turbo models 7. Remove the oil filter with an oil filter wrench. 8. Before installing a new oil filter, apply a thin coat of engine oil to the seal. 9. Clean the rubber seal seating area of the bottom of engine and install the oil filter by hand turning.
Page 309: Recommended Grade And Viscosity
When adding oil, different brands may be used together as long as they are the same API classification and SAE viscosity as those recommended by SUBARU. 11-11 Maintenance and service SAE viscosity No. and applicable tempera- ture 5W-30 is preferred.
Page 310: Recommended Grade And Viscosity Under Severe Driving Conditions
, u s e o n l y SUBARU Super Coolant. If the SUBARU Super Coolant is diluted with another brand or type, the maintenance interval is shortened to that of the mixing coolant.
Page 311: Engine Coolant
Always add genuine SUBARU cooling system conditioner whenever the coolant is replaced. Change the engine coolant and add genuine SUBARU cooling system condi- tioner using the following procedures according to the maintenance schedule.
Page 312 Fill up to this level 5. Slowly pour the coolant and fill up to just below the filler neck, allowing enough room to add genuine SUBARU cooling system conditioner in the radiator. Add genuine SUBARU cooling system condi- tioner until the coolant level reaches the filler neck.
Page 313: Air Cleaner Element
CAUTION When replacing the air cleaner ele- ment, use a genuine SUBARU air cleaner element. If it is not used, there is the possibility of causing a negative effect to the engine.
Page 314: Replacing The Air Cleaner Element
Replace the air cleaner element according to the maintenance schedule in the “Warranty and Maintenance Booklet”. Un- der extremely dusty conditions, replace it more frequently. It is recommended that you always use genuine SUBARU parts. ! Non-turbo models Connector Clip Clamp...
Page 315 ! Turbo models 1. Use a screwdriver to undo the clips on the air intake duct, then remove the air intake duct. Connector Clip 2. Unplug the connector that is attached to the top of the air cleaner case. 3. Unsnap the two clips holding the air cleaner case cover.
Page 316: Spark Plugs
It may be difficult to replace the spark plugs. It is recommended that you have the spark plugs replaced by your SUBARU dealer. The spark plugs should be replaced according to the maintenance schedule in the “Warranty and Maintenance Book- let”.
Page 317: Manual Transmission Oil
(98 N, 10 kgf) midway between the pulleys by using a spring scale. The belt deflec- tion should be the amount specified. If the front side belt is loose, cracked or worn, contact your SUBARU dealer. in (mm) Deflection New belt Used belt 0.28 –...
Page 318: Recommended Grade And Viscosity
11-20 Maintenance and service & Recommended grade and viscosity Each oil manufacturer has its own base oils and additives. Never use different brands together. Oil grade: API classification GL-5 SAE viscosity No. and applicable tempera- ture Automatic transmission fluid & Checking the fluid level The automatic transmission fluid expands largely as its temperature rises;...
Page 319: Recommended Fluid
& Recommended fluid Use one of the following types of auto- matic transmission fluid. SUBARU ATF IDEMITSU ATF HP NOTE Using any non-specified type of auto- matic transmission fluid could result in damage inside the transmission.
Page 320: Recommended Grade And Viscosity
11-22 Maintenance and service Upper level Lower level 3. Pull out the level gauge again and check the oil level on it. If it is below the lower level, add oil to bring the level up to the upper level. CAUTION Be careful not to spill front differ- ential gear oil when adding it.
Page 321: Recommended Grade And Viscosity
. If the vehicle requires frequent refilling, there may be an oil leak. If you suspect a problem, have the vehicle checked at your SUBARU dealer. 11-23 Maintenance and service & Recommended grade and viscosity Each oil manufacturer has its own base oils and additives.
Page 322: Power Steering Fluid
“MIN” and “MAX” line. If the fluid level is extremely low, it may indicate possible leakage. Consult your SUBARU dealer for an inspection. WARNING Be careful not to burn yourself because the fluid may be hot.
Page 323: Recommended Fluid
. If the vehicle requires frequent refilling, there may be a leak. If you suspect a problem, have the vehicle checked at your SUBARU dealer. CAUTION . When adding brake fluid, be care- ful not to allow any dirt into the reservoir.
Page 324: Recommended Brake Fluid
. If the vehicle requires frequent refilling, there may be a leak. If you suspect a problem, have the vehicle checked at your SUBARU dealer. . Never use different brands of clutch fluid together. . When clutch fluid is added, be careful not to allow any dirt into the tank.
Page 325: Brake Booster
Brake booster If the brake booster does not operate as described in the following, have it checked by your SUBARU dealer. 1. With the engine off, depress the brake pedal several times, applying the same pedal force each time. The distance the pedal travels should not vary.
Page 326: Brake Pedal
2 lbf (10 N, 1 kgf). If the free play is not within proper specification, contact your SUBARU deal- & Checking the brake pedal reserve distance More than 2.56 in (65 mm)
Page 327: Checking The Clutch Pedal Free Play
If you hear this scraping noise each time you apply the brake pedal, have the brake pads serviced by your SUBARU dealer as soon as possible. CAUTION If you continue to drive despite the...
Page 328: Breaking-In Of New Brake Pads And Linings
& Breaking-in of new brake pads and linings When replacing the brake pad or lining, use only genuine SUBARU parts. After replacement, the new parts must be broken in as follows. ! Brake pad and lining...
Page 329: Tires And Wheels
Tires and wheels & Types of tires You should be familiar with type of tires present on your vehicle. The factory-fitted tires are all-season tires. ! All season tires All season tires are designed to provide an adequate measure of traction, handling and braking performance in year-round driving including snowy and icy road conditions.
Page 330 In this event, go to a SUBARU dealer to have the system inspected as soon as possible. While the vehicle is driven, friction be- tween tires and the road surface causes the tires to warm up.
Page 331: Tire Inspection
This indicates the TPMS is unable to monitor all four road wheels. Contact your SUBARU dealer as soon as possible for tire and sensor replacement and/ or system resetting. If the light illuminates steadily after blinking for approximately one minute, promptly contact a SUBARU dealer to have the system inspected.
Page 332 11-34 Maintenance and service NOTE . The air pressure in a tire increases by approximately 4.3 psi (30 kPa, 0.3 kgf/cm ) when the tire becomes warm. . The tires are considered cold when the vehicle has been parked for at least 3 hours or has been driven less than 1 mile (1.6 km).
Page 333: Wheel Balance
If you suspect that the wheels are not correctly balanced, have them checked and adjusted by your SUBARU dealer. Also have them adjusted after tire repairs and after tire rotation. NOTE...
Page 334: Tire Rotation Direction Mark
11-36 Maintenance and service cause the vehicle to hydroplane. The resulting loss of vehicle control can lead to an accident. NOTE For safety, inspect tire tread regularly and replace the tires before their tread wear indicators become visible. & Tire rotation direction mark Example of tire rotation direction mark Front If the tire has the rotation direction...
Page 335: Tire Replacement
You are advised to replace the tires with new ones that are identical to those fitted as standard equip- ment. For safe vehicle operation, SUBARU recommends replacing all four tires at the same time. WARNING . All four tires must be the same in...
Page 336: Wheel Covers (If Equipped)
. Never let the wheel rub against sharp protrusions or curbs. . When wheel nuts, balance weights, or the center cap is replaced, be sure to replace them with genuine SUBARU parts designed for aluminum wheels.
Page 337: Windshield Washer Fluid
In areas where water freezes in winter, use an anti-freeze type windshield washer fluid. SUBARU Windshield Washer Fluid contains 58.5% methyl alcohol and 41.5% surfactant, by volume. Its freezing tem- perature varies according to how much it is diluted, as indicated in the following table.
Page 338: Replacement Of Wiper Blades
11-40 Maintenance and service a different concentration from the one used previously, purge the old fluid from the piping between the reservoir tank and washer nozzles by operating the washer for a certain period of time. Otherwise, if the concentration of the fluid remaining in the piping is too low for the outside temperature, it may freeze and block the nozzles.
Page 339: Windshield Wiper Blade Assembly
& Windshield wiper blade as- sembly 1. Raise the wiper arm off the windshield. Open the cover Pull down the wiper blade 2. Remove the wiper blade assembly by opening the cover and pulling it down in the direction shown in the illustration. 3.
Page 340: Rear Window Wiper Blade Assembly
11-42 Maintenance and service grooves in the rubber and slide the blade rubber assembly into the support until it locks. Claw Stopper 4. Be sure to position the claws at the end of the support between the stoppers on the rubber as shown. If the rubber is not retained properly, the wiper blade may scratch the windshield.
Page 341: Rear Window Wiper Blade Rubber
& Rear window wiper blade rubber 1. Pull out the end of the blade rubber assembly to unlock it from the plastic support. 2. Pull the blade rubber assembly out of the plastic support. Metal spines 3. If the new blade rubber is not provided with two metal spines, remove the metal spines from the old blade rubber and install them in the new blade rubber.
Page 342: Battery
11-44 Maintenance and service ends. If the rubber is not retained properly, the wiper may scratch the rear window glass. Battery WARNING . Before beginning work on or near any battery, be sure to extinguish all cigarettes, matches, and light- ers.
Page 343 Upper level Lower level It is unnecessary to periodically check the battery fluid level or periodically refill with distilled water. However, if the battery fluid level is below the lower level, remove the cap. Fill to the upper level with distilled water. CAUTION Never use more than 10 amperes when charging the battery because...
Page 344: Main Fuse
6. If the same fuse blows again, this indicates that its system has a problem. Contact your SUBARU dealer for repairs. Main fuse Main fuse box The main fuses are designed to melt...
Page 345: Installation Of Accessories
Installation of accessories Always consult your SUBARU dealer before installing fog lights or any other electrical equipment in your vehicle. Such accessories may cause the electronic system to malfunction if they are incor- rectly installed or if they are not suited for the vehicle.
Page 346 11-48 Maintenance and service NOTE . If headlight aiming is required, con- sult your SUBARU dealer for proper adjustment of the headlight aim. . It may be difficult to replace the bulbs. Have the bulbs replaced by your SUBARU dealer if necessary.
Page 347 4. Disconnect the electrical connector from the bulb. 5. Remove the bulb from the headlight assembly by turning it counterclockwise. 6. Replace the bulb with a new one. At this time, do not touch the bulb surface. 7. To install the bulb to the headlight assembly, turn it clockwise until it clicks.
Page 348: Position Light
3. Install the bulb socket by turning it clockwise. & Front turn signal light It may be difficult to replace the bulbs. Have the bulbs replaced by your SUBARU dealer if necessary. & Rear combination lights 1. Using a Phillips screwdriver, remove the upper and lower screws that secure the rear combination light assembly.
Page 349: License Plate Light
3. Remove the bulb socket from the rear combination light assembly by turning it counterclockwise. 4. Pull the bulb out of the bulb socket and replace it with a new one. 5. Set the bulb socket into the rear combination light assembly and turn it clockwise until it locks.
Page 350: Other Bulbs
2. Pull the bulb out of the socket. Install a new bulb. 3. Reinstall the lens. & Other bulbs Other bulbs may be difficult to replace. Have the bulbs replaced by your SUBARU dealer if necessary.
Page 351 Specifications ... 12-2 Dimensions... Engine ... Electrical system... Capacities ... Tires ... Wheel alignment ... Fuses and circuits ... 12-2 Fuse panel located in the passenger compartment ... 12-3 Fuse panel located in the engine 12-3 compartment ... 12-4 Bulb chart... 12-5 Vehicle identification ...
Page 352 12-2 Specifications Specifications These specifications are subject to change without notice. & Dimensions Item Overall length Overall width Overall height without roof rail with roof rail Wheel base Tread Front Rear Ground clearance* *1: Measured with vehicle empty Non-turbo models 179.5 (4,560) 70.1 (1,780) 65.9 (1,675)
Page 353: Specifications
& Engine Engine model Engine type Displacement cc (cu-in) Bore 6 Stroke in (mm) Compression ratio Firing order & Electrical system Battery type and capacity (5HR) Alternator Non-turbo models Turbo models Non-turbo engine Spark plugs Turbo engine AT: Automatic transmission MT: Manual transmission EJ253 (2.5-liter, SOHC, non-turbo)
Page 354: Capacities
12-4 Specifications & Capacities Fuel tank Engine oil Transmission oil (MT models) Transmission fluid (AT models) Front differential gear oil (AT models) Rear differential gear oil Power steering fluid Engine coolant Non-turbo models Turbo models AT: Automatic transmission MT: Manual transmission Each quantity indicated above is only a guideline.
Page 355: Tires
& Tires Tire size Wheel size Pressure Front Rear Rear when towing trailer Temporary Size spare tire Pressure NOTE For the Latin American models, there is a conventional tire installed under the floor of the cargo area. & Wheel alignment Front Rear Camber...
Page 356: Fuses And Circuits
12-6 Specifications Fuses and circuits & Fuse panel located in the passenger compartment Fuse Fuse Circuit panel rating Trailer Empty Door locking Front wiper deicer relay Combination meter 7.5A Remote control rear view mirrors Seat heater relay Combination meter Integrated unit Stop light Front wiper deicer 7.5A...
Page 357 Fuse Fuse Circuit panel rating Illumination Seat heaters Back-up light Empty Accessory power outlet (instrument panel) 7.5A Starter relay Air conditioner Rear window defogger relay coil Rear wiper Rear window washer Audio unit Clock SRS airbag system 7.5A Power window relay Radiator main fan relay Tail and illumination re- Blower fan...
Page 358: Fuse Panel Located In The Engine Compartment
12-8 Specifications & Fuse panel located in the engine compartment Main fuse Fuse Fuse Circuit panel rating ABS unit Vehicle Dynamics Con- trol unit Main fan Secondary air combina- tion valve (turbo models) Sub fan Empty Audio Headlight (low beam) Headlight (high beam) Back-up Horn...
Page 359 Fuse Fuse Circuit panel rating Headlight (right hand) Headlight (left hand) 12-9 Specifications...
Page 360: Specifications
12-10 Specifications Bulb chart A: The high mount stop light is the LED (Light Emitting Diode) type. Consult your SUBARU dealer for replacement.
Page 361 – Do not remove/restore the 12V-21W (WY21W) 12V-21W 7440 12V-5W 168 (W5W) – Do not remove any headlight- For replacement, contact your SUBARU dealer. 12-11 Specifications WARNING bulbs (both low beam and high beam) by yourself. headlight assemblies by your- self. assembly components by yourself.
Page 362 12-12 Specifications CAUTION Replace any bulb only with a new bulb of the specified wattage. Using a bulb of different wattage could result in a fire.
Page 363: Vehicle Identification
Vehicle identification 12-13 Specifications Vehicle identification number Emission control label Tire inflation pressure label Certification label Vehicle identification number plate Model number label Fuel label Air conditioner label...
Page 364 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 365 Consumer information and Reporting safety defects For U.S.A..13-2 Tire information ... 13-2 Tire labeling ... Recommended tire inflation pressure... Glossary of tire terminology ... Tire care – maintenance and safety p ractices... Vehicle load limit – how to determine... Determining compatibility of tire and vehicle load capacities ...
Page 366: Consumer Information And Reporting Safety Defects
13-2 Consumer information and Reporting safety defects For U.S.A. The following information has been compiled according to Code of Federal Regulations “Title 49, Part 575”. Tire information & Tire labeling Many markings (e.g. Tire size, Tire Identification Number or TIN) are placed on the sidewall of a tire by tire manufacturers.
Page 367 Example: (6) Load Index: A numerical code which specifies the maximum load a tire can carry at the speed indicated by its speed symbol, at maximum inflation pressure. For example, “90” means 1,323 lbs (600 kg), “89” means 1,278 lbs (580 kg).
Page 368 13-4 Consumer information and Reporting safety defects ! Maximum load rating The load rating at the maximum permissible weight load for this tire. For example, “MAX. LOAD 580 kg (1279 LBS) @ 300 kPa (44 PSI) MAX. PRESS.” WARNING Maximum load rating applies only to the tire, not to the vehicle.
Page 369: Recommended Tire Inflation Pressure
& Recommended tire inflation pressure ! Recommended cold tire inflation pressure Recommended cold tire inflation pressure for your vehicle’s tires is as follows. Tire size Wheel size Pressure Front Rear Rear when towing trailer Temporary Size spare tire Pressure Consumer information and Reporting safety defects P215/65R16 96H 16 6 6 16 6 6...
Page 370 13-6 Consumer information and Reporting safety defects ! Vehicle placard The vehicle placard is affixed to the driver’s side B-pillar. Example: U.S.-spec. models Canada-spec. models The vehicle placard shows original tire size, recommended cold tire inflation pressure on each tire at maximum loaded vehicle weight, seating capacity and loading infor- mation.
Page 371: Glossary Of Tire Terminology
& Glossary of tire terminology Accessory weight The combined weight (in excess of those standard items which may be replaced) of automatic transmis- sion, power steering, power brakes, power windows, power seats, radio, and heater, to the extent that these items are available as factory-in- stalled equipment (whether in- stalled or not).
Page 372 13-8 Consumer information and Reporting safety defects ing on a vehicle. Light truck (LT) tire A tire designated by its manufac- turer as primarily intended for use on lightweight trucks or multipur- pose passenger vehicles. Load rating The maximum load that a tire is rated to carry for a given inflation pressure.
Page 373 sory weight, including heavy duty brakes, ride levelers, roof rack, heavy duty battery, and special trim. Radial ply tire A pneumatic tire in which the ply cords that extend to the beads are laid at substantially 90 degrees to the centerline of the tread. Recommended inflation pres- sure The cold inflation pressure recom-...
Page 374 13-10 Consumer information and Reporting safety defects accessory weight, and normal oc- cupant weight (distributed in accor- dance with Table 1 that is ap- pended to the end of this section) and dividing by 2. Wheel-holding fixture The fixture used to hold the wheel and tire assembly securely during testing.
Page 375: Tire Care - Maintenance And Safety Practices
& Tire care – maintenance and safety practices Check on a daily basis that the tires are free from serious damage, nails, and stones. At the same time, check the tires for abnormal wear. Inspect the tire tread regularly and replace the tires before their tread wear indicators become visi- ble.
Page 376 13-12 Consumer information and Reporting safety defects Example 1A Vehicle capacity weight of the vehicle is 900 lbs (408 kg), which is indicated on the vehicle placard with the statement “The combined weight of occupants and cargo should never exceed 900 lbs or 408 kg”.
Page 377 Calculate the available load ca- pacity. The total weight now exceeds the capacity weight by 92 lbs (42 kg), so the cargo weight must be reduced by 92 lbs (42 kg) or more. Example 2A Vehicle capacity weight of the vehicle is 900 lbs (408 kg), which is indicated on the vehicle placard Consumer information and Reporting safety defects...
Page 378: Determining Compatibility Of Tire And Vehicle Load Capacities
13-14 Consumer information and Reporting safety defects occupants to three), and a child restraint system weighing 11 lbs (5 kg) is installed in the vehicle for the child to use, the calculations are as follows. Calculate the total weight. Calculate the available load ca- pacity.
Page 379: Steps For Determining Correct Load Limit
Suspension, bearings, axles and other body parts could break or experience accelerated wear that will shorten vehicle life. Tires could fail. Tread separation could occur. Tire could separate from its rim. & Steps for Determining Cor- rect Load Limit Locate the statement “The com- bined weight of occupants and cargo should never exceed XXX pounds”...
Page 380: Treadwear
13-16 Consumer information and Reporting safety defects form to Federal Safety Require- ments in addition to these grades. & Treadwear The treadwear grade is a compara- tive rating based on the wear rate of the tire when tested under con- trolled conditions on a specified government test course.
Page 381: Reporting Safety Defects (U.s.a.)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Subaru of America, Inc. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-9153); go to http://www.safercar.gov;...
Page 382 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 383: Index
Index...
Page 384 14-2 Index ABS (Anti-lock Brake System) ... 7-24 Warning light ... 3-16, 7-25 Accessories... 5-4, 11-47 Accessory power outlet... 6-9 Active head restraint... 1-5 Air cleaner element ... 11-15 Air conditioner ... 4-7, 4-10 Air filtration system... 4-13 Air flow selection... 4-2 Alarm system ...
Page 385 Replacing... 11-47 Capacities ... 12-4 Cargo area Cover ... 6-13 Light... 6-3 Tie-down hooks ... 6-15 Catalytic converter ... 8-3 Center Console ... 6-5 Ventilators ... 4-3 Center and side ventilators... 4-3 Changing Flat tire ... 9-6 Oil and oil filter ... 11-9 Charge warning light ...
Page 386 14-4 Index Daytime running light system... 3-27 Defogger... 3-35 Deicer ... 3-35 Differential gear oil Front ... 11-21 Rear... 11-22 Dimensions ... 12-2 Disarming the alarm system ... 2-17 Disc brake pad wear warning indicators ... 7-24 Dome light ... 6-2 Door Locks ...
Page 387 Front seats Forward and backward adjustment ... 1-3 Power seat... 1-4 Reclining... 1-3 Seat height adjustment (driver’s seat) ... 1-4 Fuel ... 7-3 Consumption indicator ... 3-22 Economy hints... 8-2 Filler lid and cap ... 7-4 Gauge ... 3-8 Requirements ... 7-3 Fuses ...
Page 388 14-6 Index Interior lights ... 6-2 Jack and jack handle... 9-5 Jack-up point... 9-6 Jump starting... 9-10 Number ... 2-2 Reminder chime... 3-5 Replacement ... 2-4 Keyless entry system ... 2-7 Keys ... 2-2 Leather seat materials ... 10-5 License plate light ... 11-51 Light Cargo area...
Page 389 Manual transmission... 11-19 Rear differential ... 11-22 Oil pressure warning light... 3-14 On-pavement and off-road driving ... 8-6 Outside Mirror defogger ... 3-35 Mirrors ... 3-34, 3-35 Temperature indicator ... 3-23 Overhead console ... 6-7 Overheating engine ... 9-12 Parking Brake ...
Page 390 14-8 Index Wiper blades ... 11-40 Replacing Air cleaner element ... 11-16 Battery (remote keyless entry system) ... 2-10 Lost transmitters (remote keyless entry system) ... 2-11 Replacing bulbs ... 11-47 Cargo area light ... 11-51 Dome light ... 11-51 Door step light ...
Page 391 Tilt ... 3-37 Tilt/telescopic... 3-38 Stopping the engine ... 7-10 Storage compartment ... 6-5 Sun shade ... 2-25 Sun visors... 6-4 Supplemental Restraint System airbag (SRS) ... 1-34 Synthetic leather upholstery ... 10-5 Tachometer ... 3-8 Temperature warning light AT OIL TEMP ... 3-14 Temporary spare tire ...
Page 392 14-10 Index System ... 7-27 Warning light ... 3-19, 7-29 Ventilator ... 4-2 Warning and indicator lights ... 3-9 Warning light ABS ... 3-16, 7-25 All-Wheel Drive... 3-18 AT OIL TEMP ... 3-14 Automatic headlight beam leveler... 3-18 Brake system ... 3-17 Charge ...
Page 393 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 394 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 395 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 396 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 397 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 398 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 399 — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — — —...
Page 400 134...

This manual is also suitable for:

Forester

Subaru 2010 Forester Manual

Table of Contents

Table of Contents

Front Seats

Seat Heater (if Equipped)

Rear Seats

Seatbelts

Front Seatbelt Pretensioners

Child Restraint Systems

SRS Airbag (Supplemental Restraint System Airbag)

Keys and Doors

Keys

Immobilizer

Door Locks

Power Door Locking Switches

Remote Keyless Entry System

Alarm System

Child Safety Locks

Windows

Rear Gate

Moonroof (if Equipped)

Instruments and Controls

Ignition Switch

Meters and Gauges

Hazard Warning Flasher

Warning and Indicator Lights

Clock

Information Display

Light Control Switch

Turn Signal Lever

Illumination Brightness Control

Front Fog Light Switch (if Equipped)

Wiper and Washer

Mirrors

Defogger and Deicer

Tilt Steering Wheel (if Equipped)

Horn

Tilt/Telescopic Steering Wheel (if Equipped)

Climate Control

Ventilator

Manual Climate Control System (if Equipped)

Automatic Climate Control System (if Equipped)

Operating Tips for Heater and Air Conditioner

Air Filtration System

Audio

Antenna System

XM TM Satellite Radio Reception (if Equipped)

Installation of Accessories

Audio Set

Power and Sound Controls

FM/AM Radio Operation

Satellite Radio Operation (if Equipped)

CD Player Operation

AUX Unit Operation

Audio Control Buttons (if Equipped)

Precautions to Observe When Handling a Compact Disc

Interior Equipment

Starting and Operating

Quick Links

Chapters

Related Manuals for Subaru 2010 Forester

Summary of Contents for Subaru 2010 Forester
