Subaru Forester Quick Reference Manual
2012
Hide thumbs
Also See for Forester:
- Manual (397 pages) ,
- Owner's manual (42 pages) ,
- Quick reference manual (41 pages)
Related Manuals for Subaru Forester
Summary of Contents for Subaru Forester
- Page 1 2012 Forester, Impreza, Impreza WRX, Impreza WRX STI Navigation System Quick Reference Guide...
-
Page 2: Table Of Contents
Table of Contents Safety Navigation Introduction Emergency Screen 4 - 5 Finding an Address 6 - 9 Finding a Point of Interest 10 -11 Setting HOME as a Favorite 12 - 13 Notes... -
Page 3: Safety
Safety Your Navigation System will assist you in reaching your destination and, if used properly, can do so with speed and ease. To use the system as safely as possible, follow all safety directions. Before attempting to use this system while driving, learn how to use it. Make sure you read the entire Navigation System Owner’s Manual Supplement. -
Page 4: Navigation Introduction
Navigation Introduction Your Navigation System helps you find and store addresses, places and attractions based on your map location and more. Prior to using the system, be sure to read the entire Navigation System Owner’s Manual Supplement so you have a complete understanding of the system. For your convenience, this Quick Reference Guide offers a quick guide for regularly used features. -
Page 5: Emergency Screen
Emergency Screen (Where Am I?) From the map screen, touch the icon at upper right corner of screen, then touch WHERE AM I? This screen shows the latitude and latitude of your current position. Touch HELP NEARBY Select between CAR REPAIR POLICE HEALTH GAS STATION... - Page 6 Touch FILTER to help refine the search. A keyboard appears so you can input a specific location, such as “Subaru”. Touch to return to the map. BACK Find the item you want on the list, and then touch that item.
-
Page 7: Finding An Address
Finding an Address Touch the Map Hard Button to display the Map screen, then touch MENU to access the navigation menu screen. On the navigation menu, touch FIND Touch FIND ADDRESS... - Page 8 By default, the country and state for your current position are displayed. If necessary, touch , a keyboard appears and then COUNTRY OR STATE enter the first few letters of the country name. Type United States. As you type, look to the bottom right of the screen and touch RESULTS Touch the up/down arrows to the right to scroll up/down until you find the...
- Page 9 Finding an Address Touch . A keyboard appears. Type the city name or input the city zip CITY/ZIP CODE code if known. As you type the city name, touch at the lower right of the RESULTS screen and a list appears with possible city choices. Scroll to find the city name. When the correct city is found, touch and the city name is automatically transferred to DONE...
- Page 10 The map is displayed with the selected point at the center. Touch to set NEXT the destination, or touch to select another destination. BACK Note: If the destination will be used frequently, you can save it to favorites as follows before touching .
-
Page 11: Finding A Point Of Interest
Finding a Point of Interest You can also find addresses by using Find Places. You can use this in the event you do not have a specific address but can refer to a specific place, such as a gas station, restaurant, accommodation, etc. - Page 12 Find the item you want on the list, and then touch that item. The map is displayed with the selected point at the center. The name and address of the location are displayed in the black bar at the top of the screen. Note: touch to display the longitude and latitude about the selected spot.
-
Page 13: Setting Home As A Favorite
Setting HOME as a Favorite Follow steps 1 through 10 on pages 6-9 (Finding an Address) of this guide. Touch a keyboard will appear. Enter the name HOME for the ADD TO FAVORITES destination and then touch DONE . You are automatically returned to the map with the destination set. - Page 14 Choosing HOME from the destination list If the Map screen is displayed, touch , then touch and then touch MENU FIND . The destination list is displayed. FAVORITES Touch HOME to select it as the destination. The map is displayed in full-screen mode with HOME at the center.
-
Page 15: Notes
Notes... - Page 16 Your Subaru dealer is the best source for the most current information. For detailed operating and safety information, please consult your Owner’s Manual.
