MONITOR SETUP

Unlike CRT displays, the LCD panel has a fixed pixel format over a set area. So for best performance,
the "native resolution" setting is always recommended. Use the following notes as a reference to setup
your display.
•
8.4", 10.4" and 12.1" monitors: The native resolution of the LCD panel is 800 X 600;
Recommended resolution is 800 X 600 @ 60 KHZ
•
14.1" and 15" monitors: The native resolution of the LCD panel is 1024 X 768; Recommended
resolution is 1024 X 768.@ 60 KHZ
•
17", 18.1" and 19" monitors: The native resolution of the LCD panel is 1280 X 1024;
Recommended resolution is 1280 X 1024 @ 60 KHZ or 1024 X 768 @ 60 Hz.
•
24" Monitors: The native resolution of the LCD panel is 1920 x 1200; Recommended resolution
is 1920 x 1200 @ 60 or 75 Hz.

Display Features

•
Analog RGB Sync On Green (SOG) Capable
•
DVI-D Digital Input Signal Capable
•
RS-170A and RS-343 Video Signal Capable (Interlace Formats)
•
VESA 75/100 Standard Mounting – Specific Models.
•
DDC2B Plug & Play
•
Universal Power Supply with VESA Power Management
•
User Friendly OSD interface
•
High Brightness and Contrast
•
Wide Viewing Angle
•
Front Remote Controls on Specific Models
•
Tilt and Swivel Base on Specific Models
•
Heavy Duty Cold Roll Steel Chassis on Specific Models

Display Options

•
TTL Input for EGA, CGA and MDA Timings Option
•
RCA (NTSC/PAL) and 4 Pin Mini Din (S-video) Optional
•
3/4/5 Wire BNC Inputs Option
•
Universal Video Input Box Option
•
Wireless Remote Control Option
•
Anti-Reflective Protective Faceplate Option
•
Strengthen Anti-Reflective Protective Faceplate Optional
•
Sunlight Readable Option
•
Touch Screen Option: Resistive, Capacitive and SAW (Surface Acoustic Wave)
•
Differential Video Input Options for long cable lengths and/or high-noise factory environments
