PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
____________________________________________________________________________________
Dynamic Displays, Inc
1625 Westgate Road
Eau Claire WI, 54703

DVI (Digital Visual Interface) Connector Pin Out

Pin Assignments for DVI Input Connector
CONNECTION
TMDS Data 2−
TMDS Data 2+
TMDS Data 2/4 Shield
NC
NC
DVI DDC SCL
DVI DDC SDA
Analog Vertical Sync
TMDS Data 1−
TMDS Data 1+
TMDS Data 1/3 Shield
NC
NC
DDC +5 V
Gnd

S- Video 4 Pin connector (Optional).

Pin Assignments for S-Video Input Connector
PIN
1
Ground (Y)
2
Ground (C)
3
Y Intensity (Luminance)
4
C Color (Chrominance)
QES1500 Progressive/Interlace Unit
Glee 17C2
PIN
CONNECTION
16
Hot Plug detect
TMDS Data 0−
17
18
TMDS Data 0+
19
TMDS Data 0/5 shield
20
NC
21
NC
22
TMDS Clock Shield
23
TMDS Clock+
TMDS Clock−
24
C1
Analog Red
C2
Analog Green
C3
Analog Blue
C4
Analog Horizontal Sync
C5
Analog Return Gnd
CONNECTION
Doc # 0048059
Rev: B
Page 8 of 29
