- Page 1 LCD Monitor User Manual - QES1500 Progressive & Interlace Monitor 17C3 A/D Board Series...
-
Page 2: Table Of Contents
Advance (Aspect Ratio needs to be set to “Full” to activate this adjustments) ............17 Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #2 of 26... - Page 3 1625 Westgate Road Eau Claire, WI 54703 Phone: 800-793-6862 Fax: 715-835-9440 715-835-2436 E-mail: sales@dynamicdisplay.com WEB: www.dynamicdisplay.com Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #3 of 26...
-
Page 4: Introduction
Touch Screen Option: Resistive, Capacitive and SAW (Surface Acoustic Wave) • Differential Video Input Options for long cable lengths and/or high-noise factory environments • Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #4 of 26... -
Page 5: Unpacking The Monitor
AC/DC adapter. Then plug the male end of the power cable into an AC outlet. Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #5 of 26... -
Page 6: Monitor Setup
DVI cable, connect it to the DVI (IN) connector of the monitor. The optional DVI graphics adapter and the DVI cable can be ordered by contacting Dynamic Displays. Connect Audio signal Cable (Optional): Connect Audio In connector of the LCD monitor and an Audio Out •... -
Page 7: Signal Input Connections
Horizontal and (Horizontal & Vertical) are on Vertical Sync individual cables as identified on the chart. Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #7 of 26... -
Page 8: Hdmi (High Definition Multimedia Interface) Connector Pin Out
PIN ASSIGNMENTS FOR S-VIDEO INPUT CONNECTOR MINI-DIN 4 CONNECTION GND (Y) GND (C) Y INTENSITY (LUMINANCE) C COLOR (CHROMINANCE) Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #8 of 26... -
Page 9: Cga 9 Pin D-Sub Connector (Optional)
No Connection No Connection No Connection Intensity Monochrome Video (TTL) HSYNC Horizontal Sync VSYNC Vertical Sync Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #9 of 26... -
Page 10: Card Edge 10 Pin Connector
Data Terminal Ready System Ground Data Set Ready Request to Send Clear to Send Ring Indicator Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #10 of 26... -
Page 11: Osd Controls & Functions
The monitor will enter “Auto Setup” automatically the first time the unit is first turned on. This option can be disable, see “PC Setting” section “Auto Adjust Enable”). Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #11 of 26... -
Page 12: Input Video Options Selection
Power Button: Push this button to turn the unit on or off. • MEMBRANE DIRECT KEYS ADJUSTMENTS: ➢ Left/Right Key Brightness: ➢ UP/Down Key Contrast: Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #12 of 26... -
Page 13: Osd Structure
In the case of monitors, the aspect ratio describes the correlation between width and height. Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #13 of 26... - Page 14 Cleans up block noise around outlines and mosquito noise on the background. i. Off ii. Low iii. Middle iv. High v. Default Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #14 of 26...
-
Page 15: Sound
0 to 100 Option a. OSD Language: Select the OSD language. i. English ii. Chinese Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #15 of 26... -
Page 16: Pc; (Available Only Vga1/Vga2)
Phase: Phase adjustment; the phase should be adjusted until the screen image is sharp. ADC Tune g. Auto Adjust Enable: On/Off Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #16 of 26... -
Page 17: Advance (Aspect Ratio Needs To Be Set To "Full" To Activate This Adjustments)
Active Amber Suspend Active Inactive Active Amber <1 Watt (19” LCD) Inactive Inactive Active Amber Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #17 of 26... -
Page 18: Troubleshooting
Adjust brightness and contrast by OSD. Irregular Image Check the signal connection between the computer and LCD monitor. Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #18 of 26... - Page 19 3. Flat Panel may have come unplugged from inverter. 4. Lamp in Flat Panel may have failed. * Contact Dynamic Displays, Inc. and return unit for repair if suggestion 1 or 2 does NOT fix the Dim Image. The timing is special and not programmed In the MCU.
-
Page 20: Cleaning Instructions
Contact the Sales department at Dynamic Displays, Inc. 800-793-6862. The timing is special and not programmed In the MCU. Characters Missing On Left Or Right Of Contact the Sales department at Dynamic Displays, Inc. Image 800-793-6862. CLEANING INSTRUCTIONS When cleaning, unplug the AC adapter from the LCD display and outlet for safety. -
Page 21: Universal Video Input Unit Option
Mounting the (UVI) Box hardware is determined by which Flat/ Panel monitor you have. The following list is • for Dynamic Displays Flat Panel systems: a. 15” Flat Panel Plastic Enclosure 8115061: Screw, Metric, Pan Head, Philips Head, Size M 4X8, Quantity of 4 8120030: Washer ,Locking, Number 8, Quantity of 4 b. -
Page 22: Universal Video Input Box Specification
VESA 75/100 Mounting Rugged for Industrial Applications Construction 1 Lb. Weight One Year Limited Warranty Warranty Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #22 of 26... -
Page 23: Factory Settings Mode
MIU Percentage (%) -------------------------- 1 d) LVDS Enable ------------------------------------ 1 / 0 e) LVDS(KHz) --------------------------------------- 30.0 KHz Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #23 of 26... - Page 24 Instructions, 17C3 MCU, Restore A/D Board Programming to Original Settings”. 6) VIF1 7) QMAP ADJUST 8) PEQ 9) OverScan Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #24 of 26...
- Page 25 OSD_25 ------------------------------------- 25 iii) OSD_50 ------------------------------------- 50 iv) OSD_75 ------------------------------------- 75 v) OSD_100 ------------------------------------ 100 Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #25 of 26...
- Page 26 OSD_50 ------------------------------------- 50 iv) OSD_75 ------------------------------------- 75 v) OSD_100 ------------------------------------ 100 Factory Name: 17C3_01202020_STD_G190EG02 Dynamic Displays, Inc. User Manual Doc: 0048070 1625 Westgate Road 17C3 A/D Series Rev 2 Eau Claire, WI 54073 Glee 17C3 Page #26 of 26...
