- Page 1 Dynamic Displays QUALITY EXCELLENCE SATISFACTION QES1500 Progressive & Interlace Units Industrial LCD Monitors User’s Manual Glee 17C2 Series...
-
Page 2: Table Of Contents
OSD Interface Controls; ............................12 TROUBLESHOOTING ............................16 CLEANING INSTRUCTIONS ..........................18 QES1508 SERIES 8.4-INCH LCD SPECIFICATION ..................19 QES1510 SERIES 12.1 INCH LCD SPECIFICATION ..................20 QES1512 SERIES 12.1-INCH LCD SPECIFICATION ..................21 QES1514 SERIES 14.1-INCH LCD SPECIFICATION ..................22 QES1515 SERIES 15-INCH LCD SPECIFICATION ................... -
Page 3: Introduction
4. Do not attempt to service this product yourself, since opening or removing the cover may expose you to potential electric shock. Only a qualified technician should service this product. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road... -
Page 4: Monitor Setup
• Touch Screen Option: Resistive, Capacitive and SAW (Surface Acoustic Wave) • Differential Video Input Options for long cable lengths and/or high-noise factory environments ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703... -
Page 5: Unpacking The Monitor
• AC Power Cord • VGA Cable • Users Manual Optional Items: These are optional items and can be ordered by contacting Dynamic Displays, Inc. • Composite Video Cable • 5 BNC to HD15 adaptor cable • Audio Cable •... -
Page 6: Connecting The Monitor
Connect DVI (Digital Video Interface) Cable (Optional): If you have a DVI digital graphics card adapter and a DVI cable, connect it to the DVI (IN) connector of the monitor. The optional DVI graphics adapter and the DVI cable can be ordered by contacting Dynamic Displays. •... -
Page 7: Signal Input Connections
Connect Horizontal and (Horizontal & Vertical) are Vertical Sync on individual cables as identified on the chart. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2 Page 7 of 29... -
Page 8: Dvi (Digital Visual Interface) Connector Pin Out
Pin Assignments for S-Video Input Connector CONNECTION Ground (Y) Ground (C) Y Intensity (Luminance) C Color (Chrominance) ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2 Page 8 of 29... -
Page 9: Cga 9 Pin D-Sub Connector (Optional)
Primary Blue SG/I Secondary Green / Intensity Secondary Blue HSYNC Horizontal Sync VSYNC Vertical Sync ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2 Page 9 of 29... -
Page 10: Mda 9 Pin D-Sub Connector (Optional)
Data Terminal Ready System Ground Data Set Ready Request to Send Clear to Send Ring Indicator ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2 Page 10 of 29... -
Page 11: Osd Controls & Functions
Adjust Buttons: ▲, ▼: These buttons used to navigate the OSD menu items from top to bottom or bottom to top. • Power Button: Push this button to turn the unit on or off. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B... -
Page 12: Osd Interface Controls
User 1.9.5. 3D NR – Only Available on S-Video or Composite Video. 1.9.5.1. 1.9.5.2. 1.9.5.3. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2 Page 12 of 29... - Page 13 2.5. Surround 2.5.1. 2.5.2. 3. SYSTEM 3.1. OSD – Language; Allows the user to select different OSD operating language. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2...
- Page 14 H-Position; Adjusts horizontal screen positioning. 5.2. V- Position; Adjusts vertical screen positioning. 5.3. Clock: Fine adjustment on horizontal position of video signals. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703...
- Page 15 6.5. Border Color 6.5.1. Black 6.5.2. Blue 6.6. Sound Source 6.6.1. Main 6.6.2. 6.7. Swap ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2 Page 15 of 29...
-
Page 16: Troubleshooting
Use OSD Image Menu to adjust H. Position and V. Appropriate Position. Check image size setting. Select Auto Adjust. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2... - Page 17 4. Lamp in Flat Panel may have failed. * Contact Dynamic Displays, Inc. and return unit for repair if suggestion 1 or 2 does NOT fix the Dim Image. The timing is special and not programmed In the MCU.
-
Page 18: Cleaning Instructions
Do not apply insecticides and other volatile items to the cabinet. Also do not leave rubber and vinyl products or such in contact with it for long hours. This can cause the surface quality to alter and the paint to peel off. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit... -
Page 19: Qes1508 Series 8.4-Inch Lcd Specification
QES1508 Series 8.4-inch LCD Specification Size/Technology 8.4 inch SVGA Color TFT LCD Module Viewing Area 170.4 mm x 127.8 mm Pixel Pitch 0.213 mm x 0.213 mm Native Resolution 800 x 600 Pixels Back Light 20,000 Hours Viewing Angle (H/V) 65°(Up) - 45°(Down) / 65°(Right) - 65°(Left) -
Page 20: Qes1510 Series 12.1 Inch Lcd Specification
Sunlight Readable Note (1) – With TTL Video Input Option. Note (2) – With Universal Video Input Option. Note (3) – With Video Connector Adaptor Option. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B... -
Page 21: Qes1512 Series 12.1-Inch Lcd Specification
Sunlight Readable Note (1) – With TTL Video Input Option. Note (2) – With Universal Video Input Option. Note (3) – With Video Connector Adaptor Option. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B... -
Page 22: Qes1514 Series 14.1-Inch Lcd Specification
Sunlight Readable Note (1) – With TTL Video Input Option. Note (2) – With Universal Video Input Option. Note (3) – With Video Connector Adaptor Option. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B... -
Page 23: Qes1515 Series 15-Inch Lcd Specification
Sunlight Readable Note (1) – With TTL Video Input Option Note (2) – With Universal Video Input Option. Note (3) – With Video Connector Adaptor Option. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B... -
Page 24: Qes1517 Series - 17" Rugged Modular Flat Panel Display
Sunlight Readable Note (1) – With TTL Video Input Option Note (2) – With Universal Video Input Option. Note (3) – With Video Connector Adaptor Option. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B... -
Page 25: Qes1519 Series 19-Inch Lcd Specification
Sunlight Readable Note (1) – With TTL Video Input Option Note (2) – With Universal Video Input Option. Note (3) – With Video Connector Adaptor Option. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B... -
Page 26: Qes1524 Series 24-In Lcd Specifications
Sunlight Readable Note (1) – With TTL Video Input Option Note (2) – With Universal Video Input Option. Note (3) – With Video Connector Adaptor Option. ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B... -
Page 27: Universal Video Input Unit Option
• Mounting the (UVI) Box hardware is determined by which Flat/ Panel monitor you have. The following list is for Dynamic Displays Flat Panel systems: a. 15” Flat Panel Plastic Enclosure 8115061: Screw, Metric, Pan Head, Philips Head, Size M 4X8, Quantity of 4 8120030: Washer ,Locking, Number 8, Quantity of 4 b. -
Page 28: Universal Video Input Box Specification
VESA 75/100 Mounting Rugged for Industrial Applications Construction 1 Lb. Weight One Year Limited Warranty Warranty ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2 Page 28 of 29... -
Page 29: Contact Information
Contact Information: Dynamic Displays, Inc 1625 Westgate Road Eau Claire, WI 54703 Phone: 800-793-6862 Fax: 715-835-2436 E-mail: sales@dynamicdisplay.com www.dynamicdisplay.com www.industrial-panels.com ____________________________________________________________________________________ Dynamic Displays, Inc Doc # 0048059 1625 Westgate Road QES1500 Progressive/Interlace Unit Rev: B Eau Claire WI, 54703 Glee 17C2...
