MONITOR SETUP

Unlike CRT displays, the LCD panel has a fixed pixel format over a set area. So for best performance, the "native
resolution" setting is always recommended. Use the following notes as a reference to setup your display.
•
For 8.4" and 12.1" monitors: The native resolution of the LCD panel is 800 X 600; Recommended resolution
is 800 X 600 @ 60 KHZ
•
For 14.1" and 15" monitors: The native resolution of the LCD panel is 1024 X 768; Recommended
resolution is 1024 X 768.@ 60 KHZ
•
For 17", 18.1" and 19" monitors: The native resolution of the LCD panel is 1280 X 1024; Recommended
resolution is 1280 X 1024 @ 60 KHZ or 1024 X 768 @ 60 Hz.
•
For 24" Monitors: The native resolution of the LCD panel is 1920 x 1200; recommended resolution is 1920 x
1200 @ 60 or 75 Hz.

Display Features

•
Analog RGB Sync On Green Capable
•
RS-170A and RS-343 Video Signal Capable (Interlace Formats)
•
VESA 75/100 Standard Mounting
•
DDC2B Plug & Play
•
Universal Power Supply with VESA Power Management
•
User Friendly OSD interface
•
High Brightness and Contrast
•
Wide Viewing Angle
•
Front Remote Controls on Specific Models
•
Tilt and Swivel Base on Specific Models
•
Heavy Duty Cold Roll Steel Chassis on Specific Models
•
3/4/5 Wire BNC Inputs Option
•
Anti-Reflective Protective Faceplate Option
•
RCA (NTSC/PAL) and 5 Pin Mini Din (S-video) Optional
•
Strengthen Anti-Reflective Protective Faceplate Optional
•
Sun Light Readable Option
•
TTL Input for EGA, CGA and MDA Timings Option
•
Touch Screen: Resistive, Capacitive and SAW Option

Unpacking The Monitor

Your LCD monitor package will consist of the following components listed on section 2.3 below. Open shipping
container and lay all the components on a flat clean surface. If any component is missing, please contact Dynamic
Displays as soon as possible.
NOTES:
•
We recommend you to keep the packing box for transportation.
•
In case of transporting and packing the unit in the packing box, carefully place it, in the packing box
keeping its panel from touching any objects
