Shore Power Connection - Formula Fastech Service Manual

FASTECH

Shore Power Connection

1
2
1. Shore Power Cord
2. Threaded Locking Collar
3. Boat Receptacle
Shore Power Connection
Figure 5-6
The shore power system requires a special,
marine grade three-conductor cable to make a
proper connection to the shore. Dockside
connections and the boat side connections are
plug-in. Boatside connections are also locked in
position with a threaded locking collar to prevent
accidental disconnection and to enhance water
resistance. Refer to Specifications, in Section 3,
for the location of your shore power receptacles.
! WARNING
Plugs and receptacles for different
systems are designed in non-
interchangeable configurations. A plug
from one system cannot fit into the
receptacle of another system. Do not
modify a shore power cable. Use only
commercially available adapters for
system modification.
To Connect:
1. Turn OFF the generator power switch on the
AC control panel. Move the lock over to
secure the switch in place.
2. Turn OFF the shore power switch on the AC
control panel.
Ensure Shore Power Inlet Breaker(s) (Figure 5-5)
is switched OFF.
5-6
3. If the outlet on the dock has a disconnect
4. Connect the shore power cable at the boat
5. Make sure the cable has more slack than the
6. Remove the cap from the outlet on the dock.
7. Turn ON the dock's outlet breaker(s). Turn ON
3
FOR078
8. Turn ON the shore power switch on the AC
9. Turn ON the respective branch circuit
To Disconnect:
1. Turn OFF the shore power switch.
2. If the shore outlet has a disconnect switch,
3. Disconnect the shore power cord at the shore
4. Disconnect the cable from the boat and close
Some marinas have been known to
"break" shore power ground circuits to
prevent electrolysis. Opening the ground
circuit creates a potentially dangerous
onboard shock hazard. Use caution when
using a "break" shore power ground
circuit.
For further information regarding your shore
power system, please contact your Formula
dealer.
FASTECH
switch, turn the switch OFF.
first.
mooring lines.
Connect the cable to the outlet.
the Shore Power Inlet Breaker(s).
control panel. If the reverse polarity light
remains ON, immediately turn OFF the shore
power switch and disconnect the shore power
cable at the shore outlet. Contact your
Formula dealer to service the system before
you use it.
breakers as needed.
turn it to the OFF position.
outlet.
the cap.
! WARNING
FORMULA
