SYSTEM OPERATION AND EQUIPMENT
Transom Shower—The optional transom wash-
down shower is located at the stern of the boat.
The shower model will vary depending on the
boat model. The 12 VDC WATER PUMP circuit
breaker switch must be ON for the unit to
function.
Transom Shower
Figure 5-10
Fresh Water Dockside Hookup
CAUTION
Monitor the fresh water dockside hookup
during the initial use. The boat is
connected to an unlimited supply of water.
Do not leave the boat unattended while
using this feature. Any major leak or break
in the system will allow continuous water
flow into the boat causing severe damage.
A fresh water dockside hookup is available in
some models, which allows usage of city water
while docked. Refer to Specifications, in Section
3, for location.
Water supplied through this hookup will not
replenish the fresh water supply in the on-board
tank. Consequently, the tank can only be filled at
the fresh water fill plate.
FORMULA
Fresh Water Dockside Hookup
To connect to city water:
1. Turn the 12 VDC WATER PUMP circuit
breaker OFF.
FOR250
2. Remove the plug from the boat's water inlet
fitting.
3. Attach the proper sanitary drinking water hose
to the dockside city water outlet. Turn on the
water and flush the hose before connecting it
to your boat.

GRAY WATER SYSTEM

In some models, the gray water from the sink
drains, shower drains and air conditioning
condensation drain flows into a shower sump box.
When the gray water in the sump box reaches a
predetermined level, a switch activates a pump.
The water is then evacuated overboard or, in the
case of boats with the "gray water" option, into the
waste holding tank.
Gray water from the head is also stored in the
waste tank. Refer to Specifications, in Section
3, for waste tank capacity.
FASTECH
Figure 5-11
FOR081
5-9
